OEM Parts Yamaha 2024 Yamaha YZF R1M Front Fork

2024 Yamaha YZF-R1M YZFR1MR D464 - Front Fork

FRONT FORK Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

FRONT FORK ASSY (L.H)

Part #: B4S-23102-12-00 Required per assembly: 1
$3,014.52
-
+
Add to cart
2

FORK SEAL COVER KIT

Part #: 2KS-231E0-00-00 Required per assembly: 1
$143.99
$124.04
-
+
Add to cart
3

OUTER TUBE COMP.

Part #: B4S-23106-00-00 Required per assembly: 1
$498.99
$479.38
-
+
Add to cart
4

BOLT, CAP

Part #: B4S-23111-00-00 Required per assembly: 1
$598.99
$588.59
-
+
Add to cart
5

O-RING

Part #: 93210-41N50-00 Required per assembly: 1
$9.49
$8.44
-
+
Add to cart
6

NUT, HEXAGON

Part #: 90170-12060-00 Required per assembly: 1
$10.87
-
+
Add to cart
7

LABEL, WARNING

Part #: 1MC-22259-11-00 Required per assembly: 1
$9.65
-
+
Add to cart
8

FRONT FORK ASSY (R.H)

Part #: B4S-23103-12-00 Required per assembly: 1
$3,014.52
-
+
Add to cart
9

FORK SEAL COVER KIT

Part #: 2KS-231E0-00-00 Required per assembly: 1
$143.99
$124.04
-
+
Add to cart
10

OUTER TUBE COMP.

Part #: B4S-23106-00-00 Required per assembly: 1
$498.99
$479.38
-
+
Add to cart
11

BOLT, CAP

Part #: B4S-23111-00-00 Required per assembly: 1
$598.99
$588.59
-
+
Add to cart
12

O-RING

Part #: 93210-41N50-00 Required per assembly: 1
$9.49
$8.44
-
+
Add to cart
13

NUT, HEXAGON

Part #: 90170-12060-00 Required per assembly: 1
$10.87
-
+
Add to cart
14

LABEL, WARNING

Part #: 1MC-22259-11-00 Required per assembly: 1
$9.65
-
+
Add to cart
15

UNDER BRACKET COMP.

Part #: 2CR-23340-00-00 Required per assembly: 1
$596.99
$566.07
-
+
Add to cart
16

BOLT, HEXAGON, SOCKET, HEAD

Part #: 91314-08030-00 Required per assembly: 4
$3.25
-
+
Add to cart
17

PROTECTOR

Part #: 5PW-23472-00-00 Required per assembly: 1
$16.48
$14.83
-
+
Add to cart
18

FORK SEALS KIT

Part #: BW8-W003B-00-00 Required per assembly: 1
Not Available
