Speedometer replacement parts for 2025 Honda CRF300LA

OEM Parts Honda 2025 Honda CRF300LA Speedometer

SPEEDOMETER Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 02
001	SWITCH, ASSEMBLY, RR., ABS, CANCEL Part #: 35240-K1T-E11 Required per assembly: 1 ~~$50.49~~ $43.10 - + Add to cart
002	CLAMP, A, ABS, CANCEL, SWITCH Part #: 35241-KZZ-J80 Required per assembly: 1 $7.32 - + Add to cart
003	CLAMP, B, ABS, CANCEL, SWITCH Part #: 35242-KZZ-J80 Required per assembly: 1 $7.53 - + Add to cart
004	METER ASSEMBLY, COMBINATION (MPH/KPH) Part #: 37100-K1T-AP1 Required per assembly: 1 ~~$212.78~~ $169.61 - + Add to cart
005	CASE ASSEMBLY (UPPER) Part #: 37110-K1T-A11 Required per assembly: 1 ~~$53.60~~ $48.71 - + Add to cart
006	CASE ASSEMBLY (LOWER) Part #: 37120-K26-G01 Required per assembly: 1 ~~$21.64~~ $20.39 - + Add to cart
007	METER, LCD (MPH/KPH) Part #: 37130-K1T-AP1 Required per assembly: 1 ~~$145.60~~ $116.06 - + Add to cart
008	KEY, TOP Part #: 37205-K26-G01 Required per assembly: 2 ~~$2.21~~ $1.59 - + Add to cart
010	RUBBER, METER, SETTING Part #: 37215-MKK-D00 Required per assembly: 4 $5.52 - + Add to cart
011	STAY, METER Part #: 61315-K1T-ER0 Required per assembly: 1 ~~$52.00~~ $41.45 - + Add to cart
012	COVER, CONNECTOR Part #: 61329-K1T-ER0 Required per assembly: 1 $2.77 - + Add to cart
013	STAY, ABS, CANCEL, SWITCH Part #: 61335-K1T-E10 Required per assembly: 1 $6.12 - + Add to cart
014	SCREW, TAP, (3X14) Part #: 90101-KY6-008 Required per assembly: 5 ~~$3.64~~ $3.55 - + Add to cart
015	SCREW (5X12) Part #: 90112-MJK-N20 Required per assembly: 1 ~~$3.21~~ $3.07 - + Add to cart
016	RIVET, PUSH, (6MM) Part #: 90116-K0A-E11 Required per assembly: 2 ~~$2.26~~ $1.79 - + Add to cart
017	SCREW, SPECIAL, (5X14) Part #: 90124-MKN-D50 Required per assembly: 1 ~~$2.40~~ $1.85 - + Add to cart
018	BOLT, FLANGE, (8X20) Part #: 90163-GHB-650 Required per assembly: 2 ~~$2.17~~ $1.52 - + Add to cart
019	NUT, CLIP, (5MM) Part #: 90677-KAN-T00 Required per assembly: 1 ~~$1.72~~ $0.89 - + Add to cart
020	HARNESS CLIP Part #: 90683-MGC-920 Required per assembly: 2 $4.10 - + Add to cart
021	CLIP, HARNESS Part #: 90684-ZA0-601 Required per assembly: 1 $4.71 - + Add to cart
022	SCREW, TAP, (5X14) Part #: 93913-25380 Required per assembly: 4 ~~$1.95~~ $1.35 - + Add to cart
023	WASHER, PLAIN, (5MM) Part #: 94103-05700 Required per assembly: 4 ~~$1.98~~ $1.31 - + Add to cart
