Swingarm replacement parts for 2025 Honda GL1800DA

OEM Parts Honda 2025 Honda GL1800DA Swingarm

SWINGARM Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 32
001	SHAFT, ASSEMBLY, PROPELLER Part #: 40200-MKC-A00 Required per assembly: 1 $557.49 $464.83 - + Add to cart
002	SPRING, PROP, SHAFT Part #: 40216-MKC-A00 Required per assembly: 1 $4.79 $4.35 - + Add to cart
003	RING, STOPPER Part #: 40221-MKC-A00 Required per assembly: 1 $4.11 $3.74 - + Add to cart
004	BOOT, JOINT Part #: 52104-MKC-A00 Required per assembly: 1 $30.28 $24.52 - + Add to cart
005	COLLAR, SWINGARM, PIVOT Part #: 52141-MKC-A00 Required per assembly: 1 $12.81 $10.67 - + Add to cart
006	NUT, SWINGARM, PIVOT Part #: 52142-MKC-A00 Required per assembly: 1 $63.54 $52.97 - + Add to cart
007	GROMMET, SWINGARM Part #: 52175-MGE-000 Required per assembly: 2 $3.96 $3.60 - + Add to cart
008	SWINGARM SUB-ASSEMBLY (TYPE3) Part #: 52200-MKC-A00ZC Required per assembly: 1 $1,716.16 $1,414.17 - + Add to cart
009	COLLAR, B, CUSHION, ARM Part #: 52462-MKC-A00 Required per assembly: 1 $17.73 $14.79 - + Add to cart
010	CAP, RR., CARRIER Part #: 81212-GF4-000 Required per assembly: 1 $5.53 $5.03 - + Add to cart
011	BOLT, R., SWINGARM, PIVOT Part #: 90141-MKC-A00 Required per assembly: 1 $50.75 $41.08 - + Add to cart
012	BOLT, L., SWINGARM, PIVOT Part #: 90142-MKC-A00 Required per assembly: 1 $36.32 $29.41 - + Add to cart
013	NUT, FLANGE, (12MM) Part #: 90309-375-003 Required per assembly: 4 $9.98 $8.58 - + Add to cart
014	WASHER, PLAIN, (12MM) Part #: 90440-GT4-970 Required per assembly: 4 $3.64 $3.31 - + Add to cart
015	BEARING (28X35X16) Part #: 91021-MGZ-J01 Required per assembly: 1 $12.38 $10.70 - + Add to cart
016	BEARING (28X56X15) Part #: 91051-MFL-003 Required per assembly: 1 $39.51 $32.94 - + Add to cart
017	BEARING (20X26X20) Part #: 91072-MY1-005 Required per assembly: 2 $21.46 $17.89 - + Add to cart
018	DUST SEAL (28X37X4) Part #: 91202-MR7-003 Required per assembly: 1 $7.64 $6.68 - + Add to cart
019	DUST SEAL Part #: 91251-MFL-003 Required per assembly: 1 $8.14 $7.10 - + Add to cart
020	DUST SEAL Part #: 91254-KS6-003 Required per assembly: 2 $10.65 $9.13 - + Add to cart
021	CIRCLIP (INNER) (56MM) Part #: 94520-56000 Required per assembly: 1 $3.44 $3.13 - + Add to cart
