Frame replacement parts for 2025 Honda TRX520FM6

OEM Parts Honda 2025 Honda TRX520FM6 Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 46
001	FRAME Part #: 50100-HR6-BF0 Required per assembly: 1 Note: Area: 3AC $1,066.12 - + Add to cart
001	FRAME Part #: 50100-HR6-MF0 Required per assembly: 1 Note: Area: 3A $1,490.00 - + Add to cart
002	FRAME, RR., (LOWER) Part #: 50200-HR6-A60 Required per assembly: 1 $1,894.38 - + Add to cart
003	RUBBER Part #: 50201-HP5-600 Required per assembly: 1 $12.69 - + Add to cart
004	RUB, ENGINE, MOUNTING Part #: 50202-HP0-A50 Required per assembly: 2 ~~$29.21~~ $25.13 - + Add to cart
005	DUST SEAL Part #: 50203-HM7-003 Required per assembly: 4 ~~$23.64~~ $22.27 - + Add to cart
006	RUBBER, C, MOUNTING Part #: 50204-HP5-600 Required per assembly: 6 $9.57 - + Add to cart
007	COLLAR, ENG, HGR Part #: 50304-HN8-000 Required per assembly: 2 $7.59 - + Add to cart
008	STAY, CONNECTOR Part #: 50340-HR6-A60 Required per assembly: 1 $10.08 - + Add to cart
009	BRKT, FR., GEAR, CASE Part #: 50350-HR3-A20 Required per assembly: 1 $9.77 - + Add to cart
010	BRACKET, HEAD, HANGER Part #: 50351-HP5-600 Required per assembly: 1 $13.07 - + Add to cart
011	SKID, RR., GEAR, CASE Part #: 50355-HR6-A60 Required per assembly: 1 $34.07 - + Add to cart
012	GUARD, ENGINE, NH1, (BLACK) Part #: 50360-HR3-A20ZA Required per assembly: 1 $317.81 - + Add to cart
013	STAY, CONNECTOR Part #: 50370-HR3-A20 Required per assembly: 1 $27.12 - + Add to cart
014	HITCH, TRAILER Part #: 50810-HN8-000 Required per assembly: 1 ~~$75.42~~ $60.12 - + Add to cart
015	BOLT (12X70) Part #: 52101-HR3-A20 Required per assembly: 2 ~~$2.90~~ $2.56 - + Add to cart
016	NUT, SPECIAL, (6X7) Part #: 61304-958-003 Required per assembly: 2 $4.80 - + Add to cart
017	BOLT, ENGINE, HANGER Part #: 90103-147-000 Required per assembly: 2 $15.45 - + Add to cart
018	BOLT, FLG, (12X193) Part #: 90106-MEJ-000 Required per assembly: 1 $19.95 - + Add to cart
019	BOLT, FLANGE, (6MM) Part #: 90111-147-000 Required per assembly: 8 $3.91 - + Add to cart
020	BOLT, FLANGE, (6MM) Part #: 90111-187-000 Required per assembly: 4 $11.55 - + Add to cart
021	BOLT, FLANGE, (10X50) Part #: 90120-HC4-000 Required per assembly: 2 $9.11 - + Add to cart
022	NUT (10MM) Part #: 90305-HC0-770 Required per assembly: 2 $4.45 - + Add to cart
023	NUT (12MM) Part #: 90305-HC4-000 Required per assembly: 3 $6.12 - + Add to cart
024	BAND, WIRE, (165MM) Part #: 90651-KV6-003 Required per assembly: 3 $5.96 - + Add to cart
025	JOINT, BREATHER, TUBE Part #: 90652-HF7-003 Required per assembly: 1 Note: Area: 3A $12.42 - + Add to cart
026	CLIP, SPLASH, GUARD, (EACH) Part #: 90653-HC4-900 Required per assembly: 3 ~~$1.67~~ $1.52 - + Add to cart
027	CLIP, HARN, (6MM) Part #: 90654-SA4-003 Required per assembly: 1 ~~$1.32~~ $0.31 - + Add to cart
028	BAND, SUCTION, HOSE Part #: 90679-SG9-E01 Required per assembly: 2 $4.86 - + Add to cart
029	CLIP, HARNESS Part #: 90684-ZA0-601 Required per assembly: 1 $4.71 - + Add to cart
030	CLIP, CONNECTOR Part #: 91535-STK-003 Required per assembly: 2 $9.40 - + Add to cart
031	CLIP, CONNECTOR Part #: 91535-TF0-003 Required per assembly: 1 $3.99 - + Add to cart
032	CLIP, WIRE, HARNESS Part #: 91556-SK7-003 Required per assembly: 1 $8.44 - + Add to cart
033	CLIP, WIRE, HARNESS Part #: 91558-SD5-003 Required per assembly: 1 $11.33 - + Add to cart
034	NUT, FLANGE, (10MM) Part #: 94050-10000 Required per assembly: 3 ~~$2.60~~ $2.47 - + Add to cart
035	BOLT, FLANGE, (8X16) Part #: 95701-08016-08 Required per assembly: 2 ~~$2.79~~ $2.41 - + Add to cart
036	BOLT, FLANGE, (8X22) Part #: 95701-08022-00 Required per assembly: 2 ~~$3.14~~ $2.88 - + Add to cart
037	BOLT, FLANGE, (10X60) Part #: 95701-10060-00 Required per assembly: 1 ~~$3.01~~ $2.71 - + Add to cart
