OEM Parts Kawasaki 2025 Kawasaki Elektrode 20 Frame

2025 Kawasaki Elektrode 20 KSK050-ASFNN - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
130

BOLT-FLANGED, 6X100

Part #: 130CA06100 Required per assembly: 1
$4.47
$4.06
-
+
Add to cart
482

CIRCLIP-TYPE-E, 10MM

Part #: 482EA0100 Required per assembly: 2 Note: Sold in multiples of 10 only
$1.10
$0.89
-
+
Add to cart
11058

BRACKET

Part #: 11058-1393 Required per assembly: 1
$5.00
$3.91
-
+
Add to cart
11058A

BRACKET, RR, STEP, LH

Part #: 11058-1571 Required per assembly: 1
$19.64
$16.37
-
+
Add to cart
11058B

BRACKET, RR, STEP, RH

Part #: 11058-1572 Required per assembly: 1
$19.64
$16.37
-
+
Add to cart
14094

COVER, FRAME, BOTTOM

Part #: 14094-0031 Required per assembly: 1
$45.63
$41.80
-
+
Add to cart
34003

HOLDER-STEP, RR, BLACK

Part #: 34003-0207-10 Required per assembly: 2
$14.61
$12.30
-
+
Add to cart
34003A

HOLDER-STEP, RR, L.GREEN

Part #: 34003-0207-710 Required per assembly: 2
$14.61
$12.30
-
+
Add to cart
34027

STEP-ASSY

Part #: 34027-0030 Required per assembly: 1
$27.15
$24.75
-
+
Add to cart
34028

STEP, RR, LH

Part #: 34028-0413 Required per assembly: 1
$23.73
$19.81
-
+
Add to cart
34028A

STEP, RR, RH

Part #: 34028-0414 Required per assembly: 1
$23.73
$19.81
-
+
Add to cart
44011

FORK-FRONT, BLACK

Part #: 44011-0748-10 Required per assembly: 1
$580.33
-
+
Add to cart
58029

PLATE-NUMBER, L.GREEN

Part #: 58029-0015-290 Required per assembly: 1
$18.94
$15.81
-
+
Add to cart
58029A

PLATE-NUMBER, EBONY

Part #: 58029-0015-6C Required per assembly: 1
$18.94
$15.81
-
+
Add to cart
92015

NUT, FLANGED, 6MM

Part #: 92015-1367 Required per assembly: 1
$3.79
$2.66
-
+
Add to cart
92015A

NUT, WELL, 5MM

Part #: 92015-1757 Required per assembly: 4
$7.52
$6.54
-
+
Add to cart
92037

CLAMP, SPEED, L=43

Part #: 92037-1290 Required per assembly: 1
$7.57
$6.59
-
+
Add to cart
92043

PIN, 12X42.5

Part #: 92043-0026 Required per assembly: 2
$5.72
$4.45
-
+
Add to cart
92071

GROMMET, 11X23X7

Part #: 92071-0762 Required per assembly: 1
$1.48
$1.15
-
+
Add to cart
92071A

GROMMET

Part #: 92071-1136 Required per assembly: 1
$7.61
$6.62
-
+
Add to cart
92071B

GROMMET

Part #: 92071-1152 Required per assembly: 1
$4.39
$3.46
-
+
Add to cart
92138

BEARING-COMP

Part #: 92138-0005 Required per assembly: 1
$97.54
$89.19
-
+
Add to cart
92145

SPRING

Part #: 92145-2240 Required per assembly: 2
$1.41
$1.09
-
+
Add to cart
92154

BOLT, SOCKET, 5X16

Part #: 92154-4294 Required per assembly: 4
$2.84
$2.05
-
+
Add to cart
92154A

BOLT, SOCKET, 8X20

Part #: 92154-7330 Required per assembly: 6
$2.66
$1.92
-
+
Add to cart
92173

CLAMP

Part #: 92173-2194 Required per assembly: 2
$1.90
$1.42
-
+
Add to cart
92200

WASHER, 8.5X18X2.3

Part #: 92200-2481 Required per assembly: 2
$0.93
$0.78
-
+
Add to cart
