OEM Parts Kawasaki 2025 Kawasaki KLR650 Engine Mount

2025 Kawasaki KLR650 KL650-FSFNN - Engine Mount

Engine Mount Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
13272

PLATE

Part #: 13272-3910 Required per assembly: 2
$4.49
$3.54
-
+
Add to cart
32190

BRACKET-ENGINE, LWR

Part #: 32190-0858 Required per assembly: 2
$24.40
$20.48
-
+
Add to cart
32190A

BRACKET-ENGINE, UPP

Part #: 32190-0859 Required per assembly: 2
$22.96
$19.18
-
+
Add to cart
32190B

BRACKET-ENGINE

Part #: 32190-0860 Required per assembly: 2
$13.68
$11.54
-
+
Add to cart
92001

BOLT, 10X75

Part #: 92001-4021 Required per assembly: 1
$9.10
$7.83
-
+
Add to cart
92002

BOLT, 10X145

Part #: 92002-1348 Required per assembly: 1
$18.91
$15.79
-
+
Add to cart
92015

NUT, FLANGED, 8MM

Part #: 92015-1406 Required per assembly: 2
$4.58
$3.60
-
+
Add to cart
92015A

NUT, FLANGED, 10MM

Part #: 92015-1415 Required per assembly: 2
$4.82
$3.79
-
+
Add to cart
92150

BOLT, 8X80

Part #: 92150-1162 Required per assembly: 2
$6.78
$5.22
-
+
Add to cart
92151

BOLT, 8X50

Part #: 92151-1463 Required per assembly: 2
$5.47
$4.25
-
+
Add to cart
92154

BOLT, FLANGED, 8X45

Part #: 92154-3733 Required per assembly: 1
$3.05
$2.19
-
+
Add to cart
92210

NUT, FLANGED, LOCK, 8MM

Part #: 92210-0159 Required per assembly: 2
$12.26
$10.39
-
+
Add to cart
92210A

NUT, PLATE, 8MM

Part #: 92210-0608 Required per assembly: 1
$5.19
$4.05
-
+
Add to cart
