Ignition Switch replacement parts for 2025 Kawasaki KLX300SM

OEM Parts Kawasaki 2025 Kawasaki KLX300SM Ignition Switch

Ignition Switch Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

132	BOLT-FLANGED-SMALL, 6X12 Part #: 132BB0612 Required per assembly: 1 Note: Sold in multiples of 5 only $2.24 - + Add to cart
411	WASHER-PLAIN, 6.5X13X1 Part #: 411AA0600 Required per assembly: 2 $3.08 - + Add to cart
11058	BRACKET, REFLECTOR, FR, LH Part #: 11058-0865 Required per assembly: 1 $4.79 - + Add to cart
11058A	BRACKET, REFLECTOR, FR, RH Part #: 11058-1055 Required per assembly: 1 ~~$68.84~~ $62.58 - + Add to cart
14091	COVER, SIDE, STAND, SWITCH Part #: 14091-1553 Required per assembly: 1 $9.09 - + Add to cart
21007	ROTOR, LOCK, TANK, CAP Part #: 21007-5015 Required per assembly: 1 ~~$60.27~~ $53.86 - + Add to cart
27005	SWITCH-ASSY-IGNITION Part #: 27005-0697 Required per assembly: 1 ~~$151.87~~ $147.09 - + Add to cart
27008	KEY-LOCK, BLANK Part #: 27008-1170 Required per assembly: 1 Note: (OPTION) ~~$18.30~~ $18.22 - + Add to cart
27010	SWITCH, SIDE, STAND Part #: 27010-0097 Required per assembly: 1 ~~$119.84~~ $116.79 - + Add to cart
27010A	SWITCH, REAR, BRAKE Part #: 27010-1489 Required per assembly: 1 ~~$47.68~~ $42.85 - + Add to cart
27048	SWITCH-ASSY Part #: 27048-5315 Required per assembly: 1 ~~$197.80~~ $190.83 - + Add to cart
28012	REFLECTOR-REFLEX Part #: 28012-0002 Required per assembly: 2 ~~$24.56~~ $22.70 - + Add to cart
28012A	REFLECTOR-REFLEX, FR Part #: 28012-016 Required per assembly: 2 Note: (CN ONLY) ~~$23.67~~ $22.04 - + Add to cart
28012B	REFLECTOR-REFLEX Part #: 28012-1077 Required per assembly: 1 ~~$23.67~~ $22.04 - + Add to cart
46123	SPRING-COMP, REAR, BRAKE, SWITCH Part #: 46123-0008 Required per assembly: 1 $6.39 - + Add to cart
92002	BOLT, 6X25 Part #: 92002-1582 Required per assembly: 1 $5.26 - + Add to cart
92015	NUT, FLANGED, 5MM Part #: 92015-1259 Required per assembly: 2 $4.48 - + Add to cart
92143	COLLAR Part #: 92143-1331 Required per assembly: 1 $4.52 - + Add to cart
92153	BOLT, TORX, 6X16 Part #: 92153-1426 Required per assembly: 2 $4.46 - + Add to cart
92210	NUT, FLANGED, 5MM Part #: 92210-0007 Required per assembly: 3 Note: Sold in multiples of 5 only $2.84 - + Add to cart
