OEM Parts Kawasaki 2025 Kawasaki Mule PRO FXT 1000 LE Fuel Pump

2025 Kawasaki Mule PRO-FXT 1000 LE KAT1000-ASSNL - Fuel Pump

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
670

O RING

Part #: 670E5090 Required per assembly: 1
$31.35
$28.61
-
+
Add to cart
13272

PLATE

Part #: 13272-2500 Required per assembly: 1
$20.16
-
+
Add to cart
14092

COVER

Part #: 14092-1044 Required per assembly: 1
$31.19
$28.47
-
+
Add to cart
16073

INSULATOR

Part #: 16073-0129 Required per assembly: 2
$6.16
$4.77
-
+
Add to cart
32155

PIPE, FUEL

Part #: 32155-7380 Required per assembly: 1
$73.45
$67.81
-
+
Add to cart
49019

FILTER-FUEL

Part #: 49019-0013 Required per assembly: 1
$17.84
-
+
Add to cart
49033

NOZZLE-INJECTION

Part #: 49033-0040 Required per assembly: 2
$138.26
$136.62
-
+
Add to cart
49040

PUMP-FUEL

Part #: 49040-0832 Required per assembly: 1
$842.80
-
+
Add to cart
49056

PIPE-INJECTION

Part #: 49056-0566 Required per assembly: 1
$44.05
$40.40
-
+
Add to cart
51044

TUBE-ASSY, TANK-PIPE

Part #: 51044-1260 Required per assembly: 1
$206.47
$203.43
-
+
Add to cart
51044A

TUBE-ASSY, PIPE-ENGINE

Part #: 51044-1261 Required per assembly: 1
$161.88
$159.36
-
+
Add to cart
51072

CHAMBER-FUEL

Part #: 51072-0003 Required per assembly: 1
$46.89
$42.92
-
+
Add to cart
92055

RING-O, INJECTION, NOZZLE

Part #: 92055-0937 Required per assembly: 2
$10.20
$8.71
-
+
Add to cart
92153

BOLT, FLANGED, 5MM

Part #: 92153-0361 Required per assembly: 2
$4.31
$3.40
-
+
Add to cart
92154

BOLT, FUEL, PUMP

Part #: 92154-1326 Required per assembly: 6 Note: Sold in multiples of 5 only
$1.02
$0.85
-
+
Add to cart
92173

CLAMP, FUEL, PIPE

Part #: 92173-1213 Required per assembly: 6 Note: Sold in multiples of 5 only
$1.55
$1.20
-
+
Add to cart
92173A

CLAMP

Part #: 92173-2551 Required per assembly: 1
$3.29
$2.32
-
+
Add to cart
