Rear Suspension replacement parts for 2025 Kawasaki Teryx KRX 1000 eS

OEM Parts Kawasaki 2025 Kawasaki Teryx KRX 1000 eS Rear Suspension

Rear Suspension Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

130	BOLT-FLANGED, 12X25 Part #: 130CA1225 Required per assembly: 4 ~~$7.97~~ $6.91 - + Add to cart
130A	BOLT-FLANGED, 12X60 Part #: 130CA1260 Required per assembly: 4 ~~$4.73~~ $3.71 - + Add to cart
481	CIRCLIP-TYPE-C Part #: 481J7500 Required per assembly: 2 ~~$5.63~~ $4.37 - + Add to cart
670	O, RING, 18MM Part #: 670B2018 Required per assembly: 4 Note: Sold in multiples of 10 only ~~$1.48~~ $1.14 - + Add to cart
11065	CAP Part #: 11065-1305 Required per assembly: 4 ~~$2.16~~ $1.60 - + Add to cart
13272	PLATE Part #: 13272-2728 Required per assembly: 2 ~~$3.06~~ $2.19 - + Add to cart
14093	COVER, RR, SHOCK, LH Part #: 14093-0955 Required per assembly: 1 ~~$20.94~~ $17.38 - + Add to cart
14093A	COVER, RR, SHOCK, RH Part #: 14093-0956 Required per assembly: 1 ~~$20.94~~ $17.38 - + Add to cart
14093B	COVER, TRAILING, ARM, LH Part #: 14093-0994 Required per assembly: 1 ~~$5.28~~ $4.11 - + Add to cart
14093C	COVER, TRAILING, ARM, RH Part #: 14093-0995 Required per assembly: 1 ~~$5.28~~ $4.11 - + Add to cart
39007	ARM-SUSP, TRAILING, LH, BLACK Part #: 39007-0468-10 Required per assembly: 1 $573.17 - + Add to cart
39007A	ARM-SUSP, TRAILING, RH, BLACK Part #: 39007-0469-10 Required per assembly: 1 $588.17 - + Add to cart
39007B	ARM-SUSP, CONTROL, RR, UPP, BEIGE Part #: 39007-0470-75K Required per assembly: 2 ~~$232.28~~ $227.77 - + Add to cart
39007C	ARM-SUSP, CONTROL, RR, LWR, BEIGE Part #: 39007-0471-75K Required per assembly: 2 ~~$356.83~~ $352.23 - + Add to cart
39007D	ARM-SUSP, CONTROL, FR, P.W.BEIGE Part #: 39007-0472-75K Required per assembly: 2 ~~$301.55~~ $294.95 - + Add to cart
39186	KNUCKLE, RR, LH Part #: 39186-0325 Required per assembly: 1 $245.68 - + Add to cart
39186A	KNUCKLE, RR, RH Part #: 39186-0326 Required per assembly: 1 $245.68 - + Add to cart
42036	SLEEVE, 12.1X22X147 Part #: 42036-0837 Required per assembly: 2 ~~$57.95~~ $52.74 - + Add to cart
46102	ROD, STABILIZER Part #: 46102-0638 Required per assembly: 2 ~~$49.52~~ $45.26 - + Add to cart
59266	JOINT-BALL Part #: 59266-0747 Required per assembly: 10 ~~$18.39~~ $15.30 - + Add to cart
59266A	JOINT-BALL Part #: 59266-0748 Required per assembly: 4 ~~$27.94~~ $23.30 - + Add to cart
59437	STABILIZER, RR Part #: 59437-0024 Required per assembly: 1 $217.83 - + Add to cart
92009	SCREW Part #: 92009-1166 Required per assembly: 14 ~~$5.66~~ $4.40 - + Add to cart
92015	NUT, FLANGED, 12MM Part #: 92015-1433 Required per assembly: 16 ~~$9.10~~ $7.83 - + Add to cart
92033	RING-SNAP Part #: 92033-0802 Required per assembly: 10 Note: Sold in multiples of 5 only ~~$1.42~~ $1.11 - + Add to cart
92033A	RING-SNAP Part #: 92033-0803 Required per assembly: 4 Note: Sold in multiples of 5 only ~~$1.42~~ $1.11 - + Add to cart
92045	BEARING-BALL, 40X74X42 Part #: 92045-0920 Required per assembly: 2 ~~$102.52~~ $93.60 - + Add to cart
92139	BUSHING Part #: 92139-0938 Required per assembly: 4 ~~$9.18~~ $7.90 - + Add to cart
92152	COLLAR, 6.3X9.5X4.1 Part #: 92152-1571 Required per assembly: 14 ~~$6.16~~ $4.77 - + Add to cart
92154	BOLT, FLANGED, 12X55 Part #: 92154-0289 Required per assembly: 2 ~~$10.16~~ $8.68 - + Add to cart
92154A	BOLT, FLANGED, 12X117 Part #: 92154-0867 Required per assembly: 2 ~~$13.07~~ $11.05 - + Add to cart
92154B	BOLT, FLANGED, 12X68 Part #: 92154-3927 Required per assembly: 2 ~~$8.01~~ $6.94 - + Add to cart
92154C	BOLT, FLANGED, 12X175 Part #: 92154-3928 Required per assembly: 2 ~~$18.39~~ $15.36 - + Add to cart
92154D	BOLT, FLANGED, 12X86 Part #: 92154-3929 Required per assembly: 4 ~~$9.00~~ $7.74 - + Add to cart
92161	DAMPER Part #: 92161-2414 Required per assembly: 2 ~~$4.79~~ $3.76 - + Add to cart
92200	WASHER, 10.3X23X1.6 Part #: 92200-0724 Required per assembly: 2 ~~$3.85~~ $2.99 - + Add to cart
92210	NUT, LOCK, FLANGED, 10MM Part #: 92210-1080 Required per assembly: 4 ~~$10.56~~ $9.00 - + Add to cart
