Other replacement parts for 2025 Kawasaki Teryx KRX 1000 Lifted Edition

OEM Parts Kawasaki 2025 Kawasaki Teryx KRX 1000 Lifted Edition Other

Other Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

130	BOLT-FLANGED, 6X12 Part #: 130BA0612 Required per assembly: 2 Note: Sold in multiples of 5 only ~~$1.79~~ $1.32 - + Add to cart
130A	BOLT-FLANGED Part #: 130CA1025 Required per assembly: 2 ~~$1.90~~ $1.42 - + Add to cart
130B	BOLT-FLANGED, 10X40 Part #: 130CA1040 Required per assembly: 4 ~~$2.92~~ $2.08 - + Add to cart
11057	BRACKET, WINCH Part #: 11057-3707 Required per assembly: 1 ~~$118.34~~ $116.03 - + Add to cart
11057A	BRACKET, WINCH, RELAY Part #: 11057-3729 Required per assembly: 1 ~~$46.04~~ $42.06 - + Add to cart
13070	GUIDE, FAIRLEAD Part #: 13070-1447 Required per assembly: 1 ~~$147.04~~ $144.76 - + Add to cart
13272	PLATE, FAIRLEAD Part #: 13272-2847 Required per assembly: 1 ~~$7.86~~ $6.80 - + Add to cart
26011	WIRE-LEAD, BLUE Part #: 26011-2451 Required per assembly: 1 ~~$49.97~~ $45.54 - + Add to cart
26011A	WIRE-LEAD, YELLOW Part #: 26011-2452 Required per assembly: 1 ~~$48.86~~ $44.57 - + Add to cart
26011B	WIRE-LEAD, RED Part #: 26011-2453 Required per assembly: 1 ~~$31.10~~ $28.32 - + Add to cart
26011C	WIRE-LEAD, BLACK Part #: 26011-2454 Required per assembly: 1 ~~$28.61~~ $25.98 - + Add to cart
26031	HARNESS, REMOTE Part #: 26031-2842 Required per assembly: 1 ~~$31.94~~ $29.06 - + Add to cart
26031A	HARNESS, CONTACTOR Part #: 26031-2843 Required per assembly: 1 ~~$51.22~~ $46.65 - + Add to cart
27010	SWITCH, REMOTE Part #: 27010-0820 Required per assembly: 1 ~~$129.74~~ $128.14 - + Add to cart
27010A	SWITCH, ON/OFF Part #: 27010-0942 Required per assembly: 1 ~~$51.74~~ $47.11 - + Add to cart
27034	RELAY, CONTROLLER Part #: 27034-0018 Required per assembly: 1 ~~$198.30~~ $194.30 - + Add to cart
49006	BOOT Part #: 49006-0601 Required per assembly: 6 ~~$2.72~~ $1.95 - + Add to cart
53045	HOOK ASSEMBLY Part #: 53045-0028 Required per assembly: 1 ~~$25.20~~ $20.93 - + Add to cart
54040	WINCH, VRX45-S Part #: 54040-0010 Required per assembly: 1 $735.07 - + Add to cart
92022	WASHER, 8.2X19X2 Part #: 92022-1533 Required per assembly: 4 ~~$5.66~~ $4.40 - + Add to cart
92072	BAND Part #: 92072-3509 Required per assembly: 10 ~~$2.19~~ $1.60 - + Add to cart
92154	BOLT, 8X20 Part #: 92154-1876 Required per assembly: 4 ~~$2.75~~ $1.99 - + Add to cart
92154A	BOLT, SOCKET, 10X20 Part #: 92154-1877 Required per assembly: 2 ~~$3.64~~ $2.83 - + Add to cart
92154B	BOLT, 5X20 Part #: 92154-1879 Required per assembly: 2 ~~$2.99~~ $2.14 - + Add to cart
92200	WASHER, 6, LOCK Part #: 92200-1776 Required per assembly: 4 ~~$1.06~~ $0.88 - + Add to cart
92200A	WASHER, 5, LOCK Part #: 92200-1777 Required per assembly: 2 ~~$1.06~~ $0.88 - + Add to cart
92200B	WASHER Part #: 92200-1778 Required per assembly: 2 ~~$0.96~~ $0.80 - + Add to cart
92200C	WASHER, 6.4X12X1.8 Part #: 92200-2358 Required per assembly: 2 ~~$0.54~~ $0.51 - + Add to cart
92210	NUT, LOCK, FLANGED, 10MM Part #: 92210-1080 Required per assembly: 2 ~~$10.56~~ $9.00 - + Add to cart
92210A	NUT, LOCK, M10 Part #: 92210-1432 Required per assembly: 2 $21.22 - + Add to cart
92210B	NUT, M6X1.00 Part #: 92210-1434 Required per assembly: 4 $21.72 - + Add to cart
92210C	NUT, M5X0.80 Part #: 92210-1435 Required per assembly: 2 ~~$1.19~~ $0.95 - + Add to cart
92210D	NUT, 6MM Part #: 92210-1792 Required per assembly: 2 ~~$3.06~~ $2.19 - + Add to cart
