Deck Hatch 2 replacement parts for 2025 Yamaha 252XE

OEM Parts Yamaha 2025 Yamaha 252XE Deck Hatch 2

DECK HATCH 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ENGINE HATCH COMP. Part #: F4Y-U516A-00-00 Required per assembly: 1 $3,181.68 $3,142.44 - + Add to cart
2	HINGE 1 Part #: F4Y-U2816-00-00 Required per assembly: 2 $155.03 $120.93 - + Add to cart
3	SCREW, COUNTERSUNK Part #: 90152-14S16-00 Required per assembly: 8 $0.51 $0.38 - + Add to cart
4	WASHER, FENDER, (1/4", X, 1") Part #: 90209-14SA2-00 Required per assembly: 6 $2.02 $0.60 - + Add to cart
5	NUT, SELF-LOCKING Part #: 90185-14S00-00 Required per assembly: 6 $5.08 $0.68 - + Add to cart
6	BRACKET, HATCH, SUPPORT, 2 Part #: F4A-U2899-00-00 Required per assembly: 2 $60.17 $49.88 - + Add to cart
7	BRACKET Part #: F5N-U1794-00-00 Required per assembly: 1 Not Available
8	STUD, JOINT, BALL Part #: F3M-U146E-00-00 Required per assembly: 2 $18.35 $14.35 - + Add to cart
9	NUT, SELF-LOCKING Part #: 90185-15S00-00 Required per assembly: 2 $0.45 $0.42 - + Add to cart
10	SCREW, TAPPING Part #: 90167-14S40-00 Required per assembly: 3 $0.92 $0.76 - + Add to cart
11	SCREW, TAPPING Part #: 90167-14S24-00 Required per assembly: 3 $5.08 $0.91 - + Add to cart
12	SUPPORT, HATCH, 2 Part #: F4Y-U2896-00-00 Required per assembly: 1 $227.44 $178.39 - + Add to cart
13	SCREW, COUNTERSUNK Part #: 90152-14S40-00 Required per assembly: 4 $0.97 $0.76 - + Add to cart
14	WASHER Part #: 90209-14SA6-00 Required per assembly: 8 $6.11 $1.59 - + Add to cart
15	WASHER, 1/4", FL Part #: 90201-14S00-00 Required per assembly: 4 $7.12 $1.66 - + Add to cart
16	NUT Part #: 90179-14SA2-00 Required per assembly: 4 $4.07 $0.53 - + Add to cart
17	PIN Part #: GP1-U3774-10-00 Required per assembly: 2 Not Available
18	WASHER, 7/16X1, 1/2 Part #: 90209-17SA5-00 Required per assembly: 6 $6.11 $1.97 - + Add to cart
19	WASHER, SPECIAL Part #: GP1-U5194-01-00 Required per assembly: 2 $18.35 $12.84 - + Add to cart
20	NUT, M10-1.5, NYLOX Part #: 95680-10100-00 Required per assembly: 2 $7.12 $2.86 - + Add to cart
21	SEAL Part #: F4Y-U3262-41-00 Required per assembly: 1 $110.15 $87.68 - + Add to cart
22	PLATE 2 ASSEMBLY Part #: F2D-U273A-00-00 Required per assembly: 1 $33.64 $26.43 - + Add to cart
23	SCREW, COUNTERSUNK Part #: 90161-08SA4-00 Required per assembly: 4 $5.08 $0.91 - + Add to cart
24	STERN HATCH ASSEMBLY Part #: F4Y-U518A-00-00 Required per assembly: 1 $993.89 - + Add to cart
25	HINGE 5 Part #: F2A-U2826-00-00 Required per assembly: 2 $45.89 $37.77 - + Add to cart
26	SCREW, COUNTERSUNK Part #: 90161-08SA4-00 Required per assembly: 12 $5.08 $0.91 - + Add to cart
27	LOCK ASSEMBLY Part #: F3H-U5540-10-00 Required per assembly: 2 $43.85 $33.23 - + Add to cart
28	LEVER, HATCH, LOCK Part #: F3H-U2844-10-00 Required per assembly: 1 $5.59 $4.31 - + Add to cart
29	BRACKET, HATCH, SUPPORT, 2 Part #: F1C-U2899-00-00 Required per assembly: 1 $12.23 $6.86 - + Add to cart
30	SCREW, #10, X, 1/2&QUO Part #: 90167-10S08-00 Required per assembly: 6 $5.08 $0.83 - + Add to cart
31	BRACKET, HATCH, SUPPORT, 2 Part #: F3F-U2899-00-00 Required per assembly: 1 $12.23 $9.06 - + Add to cart
32	SCREW, #10, X, 1/2&QUO Part #: 90167-10S08-00 Required per assembly: 2 $5.08 $0.83 - + Add to cart
33	SUPPORT, HATCH, 2 Part #: F1C-U2896-10-00 Required per assembly: 1 $64.25 $54.42 - + Add to cart
34	LATCH KEEPER Part #: GP1-U4848-01-00 Required per assembly: 2 $18.35 $12.08 - + Add to cart
35	SCREW, 10-24X3/4&QUO Part #: 90157-10S12-00 Required per assembly: 4 $5.08 $0.68 - + Add to cart
