Front Fork replacement parts for 2025 Yamaha WR450F

OEM Parts Yamaha 2025 Yamaha WR450F Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSY (L.H) Part #: BNK-23102-00-00 Required per assembly: 1 ~~$1,099.99~~ $896.88 - + Add to cart
2	TUBE, OUTER, (RIGHT) Part #: 33D-23136-00-00 Required per assembly: 1 $727.36 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
4	INNER TUBE COMP2 Part #: BNK-23120-00-00 Required per assembly: 1 ~~$384.99~~ $376.67 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
8	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 ~~$24.98~~ $22.79 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
10	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 ~~$19.48~~ $18.90 - + Add to cart
11	SEAL, DUST Part #: BHR-23144-00-00 Required per assembly: 1 ~~$24.98~~ $21.69 - + Add to cart
12	CYLINDER, COMP, FRONT, FORK Part #: BNK-23170-00-00 Required per assembly: 1 ~~$384.99~~ $376.67 - + Add to cart
13	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
14	SEAT, SPRING, UPPER Part #: BR9-23142-01-00 Required per assembly: 1 ~~$63.99~~ $51.51 - + Add to cart
15	VALVE COMP Part #: BNK-2316A-00-00 Required per assembly: 1 ~~$219.99~~ $216.20 - + Add to cart
16	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $9.01 - + Add to cart
17	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
18	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.85 - + Add to cart
19	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
20	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
21	SPRING, FRONT, FORK, (K=4.8) Part #: BR9-23141-50-00 Required per assembly: 1 $125.00 - + Add to cart
22	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
23	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
24	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
25	CAP Part #: BHR-2319W-00-00 Required per assembly: 1 $13.28 - + Add to cart
26	SCREW Part #: 1MC-23119-10-00 Required per assembly: 1 ~~$2.60~~ $1.85 - + Add to cart
27	FRONT FORK ASSY (R.H) Part #: BNK-23103-00-00 Required per assembly: 1 ~~$1,099.99~~ $896.88 - + Add to cart
28	TUBE, OUTER, (RIGHT) Part #: 33D-23136-00-00 Required per assembly: 1 $727.36 - + Add to cart
29	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
30	INNER TUBE COMP1 Part #: BNK-23110-00-00 Required per assembly: 1 ~~$384.99~~ $376.67 - + Add to cart
31	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
32	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
33	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
34	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 ~~$24.98~~ $22.79 - + Add to cart
35	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
36	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 ~~$19.48~~ $18.90 - + Add to cart
37	SEAL, DUST Part #: BHR-23144-00-00 Required per assembly: 1 ~~$24.98~~ $21.69 - + Add to cart
38	CYLINDER, COMP, FRONT, FORK Part #: BNK-23170-00-00 Required per assembly: 1 ~~$384.99~~ $376.67 - + Add to cart
39	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
40	SEAT, SPRING, UPPER Part #: BR9-23142-01-00 Required per assembly: 1 ~~$63.99~~ $51.51 - + Add to cart
41	VALVE COMP Part #: BNK-2316A-00-00 Required per assembly: 1 ~~$219.99~~ $216.20 - + Add to cart
42	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $9.01 - + Add to cart
43	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
44	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.85 - + Add to cart
45	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
46	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
47	SPRING, FRONT, FORK, (K=4.8) Part #: BR9-23141-50-00 Required per assembly: 1 $125.00 - + Add to cart
48	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
49	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
50	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
51	CAP Part #: BHR-2319W-00-00 Required per assembly: 1 $13.28 - + Add to cart
52	SCREW Part #: 1MC-23119-10-00 Required per assembly: 1 ~~$2.60~~ $1.85 - + Add to cart
53	UNDER BRACKET COMP. Part #: B7R-23340-00-00 Required per assembly: 1 ~~$628.99~~ $572.91 - + Add to cart
54	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 4 $3.48 - + Add to cart
55	PROTECTOR 2 Part #: 17D-2315J-J0-00 Required per assembly: 1 $19.50 - + Add to cart
56	PROTECTOR 1 Part #: B7R-2315H-20-00 Required per assembly: 1 ~~$34.99~~ $33.66 - + Add to cart
57	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.87 - + Add to cart
58	CLAMP Part #: B7R-23466-00-00 Required per assembly: 1 ~~$29.98~~ $24.49 - + Add to cart
59	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-05028-00 Required per assembly: 2 ~~$9.49~~ $8.46 - + Add to cart
60	BRACKET 1 Part #: B7R-83955-00-00 Required per assembly: 1 ~~$58.99~~ $49.25 - + Add to cart
61	PIN, DOWEL Part #: 93603-07073-00 Required per assembly: 2 ~~$9.49~~ $5.74 - + Add to cart
62	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08045-00 Required per assembly: 2 $3.25 - + Add to cart
63	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 2 $3.48 - + Add to cart
64	FORK SEALS KIT Part #: BHR-W003B-00-00 Required per assembly: 1 ~~$61.99~~ $59.94 - + Add to cart
