Fuel Tank replacement parts for 2025 Yamaha Kodiak 700 EPS SE

OEM Parts Yamaha 2025 Yamaha Kodiak 700 EPS SE Fuel Tank

FUEL TANK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL TANK COMP. Part #: B16-F4110-00-00 Required per assembly: 1 ~~$232.99~~ $208.51 - + Add to cart
2	FUEL PUMP COMP. Part #: BDW-13907-00-00 Required per assembly: 1 ~~$693.99~~ $626.53 - + Add to cart
3	BRACKET, FUEL, PUMP Part #: 3B4-24491-00-00 Required per assembly: 1 ~~$22.98~~ $18.64 - + Add to cart
4	O-RING Part #: 1S3-24486-00-00 Required per assembly: 1 ~~$18.98~~ $16.37 - + Add to cart
5	NUT (CROWN) Part #: 95380-06800-00 Required per assembly: 6 ~~$9.49~~ $6.61 - + Add to cart
6	CAP ASSY Part #: BVG-24610-00-00 Required per assembly: 1 ~~$32.99~~ $26.75 - + Add to cart
7	HOSE (L495) Part #: 90445-09841-00 Required per assembly: 1 ~~$16.48~~ $10.72 - + Add to cart
8	CLIP Part #: 90467-090A2-00 Required per assembly: 2 ~~$4.75~~ $2.45 - + Add to cart
9	ROLL OVER VALVE ASSEMBLY Part #: BFE-F4180-00-00 Required per assembly: 1 ~~$22.98~~ $15.65 - + Add to cart
10	CLAMP Part #: 90464-15014-00 Required per assembly: 1 ~~$3.64~~ $1.87 - + Add to cart
11	SCREW, BINDING Part #: 98907-05012-00 Required per assembly: 1 ~~$9.49~~ $6.06 - + Add to cart
12	BRACKET, CANISTOR Part #: BFE-F419F-00-00 Required per assembly: 1 ~~$9.49~~ $5.50 - + Add to cart
13	BOLT, HEXAGON, DEEP, RECESS Part #: 97D95-06016-00 Required per assembly: 1 ~~$2.75~~ $1.87 - + Add to cart
14	NUT, SPRING Part #: 90183-061A3-00 Required per assembly: 1 ~~$9.49~~ $6.99 - + Add to cart
15	HOSE (L380) Part #: 90445-09840-00 Required per assembly: 1 ~~$8.49~~ $5.35 - + Add to cart
16	CLIP Part #: 90467-090A2-00 Required per assembly: 1 ~~$4.75~~ $2.45 - + Add to cart
17	GROMMET Part #: 90480-18290-00 Required per assembly: 1 ~~$9.49~~ $6.88 - + Add to cart
18	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-06035-00 Required per assembly: 1 ~~$0.30~~ $0.28 - + Add to cart
19	GROMMET Part #: 90480-01400-00 Required per assembly: 3 ~~$14.49~~ $9.89 - + Add to cart
20	COLLAR Part #: 90387-07021-00 Required per assembly: 2 ~~$8.49~~ $6.15 - + Add to cart
21	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-06035-00 Required per assembly: 3 ~~$0.30~~ $0.28 - + Add to cart
22	DAMPER, LOCATING, 2 Part #: B16-F4182-04-00 Required per assembly: 1 Not Available
23	DAMPER, LOCATING, 1 Part #: B16-F4181-00-00 Required per assembly: 1 ~~$2.29~~ $1.69 - + Add to cart
24	PROTECTOR, FUEL, TANK Part #: B16-F4141-00-00 Required per assembly: 1 $19.37 - + Add to cart
25	PIPE, FUEL, 1 Part #: B16-13971-01-00 Required per assembly: 1 ~~$103.98~~ $87.35 - + Add to cart
26	CLAMP Part #: 90464-14004-00 Required per assembly: 1 ~~$8.49~~ $5.29 - + Add to cart
27	WASHER, PLATE Part #: 90201-06036-00 Required per assembly: 2 ~~$9.49~~ $6.15 - + Add to cart
28	DAMPER 1 Part #: 2PA-21541-00-00 Required per assembly: 1 ~~$2.79~~ $1.74 - + Add to cart
29	CLAMP Part #: 90464-25003-00 Required per assembly: 1 ~~$1.44~~ $1.22 - + Add to cart
30	CLAMP Part #: 90464-32801-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$6.11~~ $1.36 - + Add to cart
31	COLLAR Part #: 90387-06M19-00 Required per assembly: 2 ~~$3.89~~ $3.70 - + Add to cart
