Steering replacement parts for 2025 Yamaha Wolverine RMAX2 1000 XT R

OEM Parts Yamaha 2025 Yamaha Wolverine RMAX2 1000 XT R Steering

STEERING Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	STEERING ASSY Part #: B4J-F3400-03-00 Required per assembly: 1 ~~$255.99~~ $211.35 - + Add to cart
2	STEERING PINION SET Part #: B4J-F38G0-01-00 Required per assembly: 1 ~~$70.98~~ $50.49 - + Add to cart
3	SEAL Part #: B4J-F3844-00-00 Required per assembly: 1 ~~$11.49~~ $7.12 - + Add to cart
4	COVER, ADJUST Part #: 1XD-F387G-00-00 Required per assembly: 1 ~~$3.14~~ $3.11 - + Add to cart
5	SPRING, PRESSURE Part #: 1XD-F387K-00-00 Required per assembly: 1 ~~$2.21~~ $2.01 - + Add to cart
6	PAD, PRESSURE Part #: 1XD-F387F-00-00 Required per assembly: 1 ~~$15.49~~ $12.02 - + Add to cart
7	RING, STOPPER Part #: B4J-F387J-00-00 Required per assembly: 1 ~~$1.39~~ $1.18 - + Add to cart
8	SEAL, SET, 1 Part #: 1XD-F1208-00-00 Required per assembly: 1 ~~$22.98~~ $17.09 - + Add to cart
9	BAND Part #: 1XD-F3489-00-00 Required per assembly: 2 ~~$3.04~~ $2.45 - + Add to cart
10	RACK END SET Part #: B4J-F38H0-00-00 Required per assembly: 2 ~~$93.98~~ $76.72 - + Add to cart
11	LOCK ASSEMBLY Part #: 1XD-F178K-00-00 Required per assembly: 1 ~~$2.60~~ $2.49 - + Add to cart
12	WASHER, FELT Part #: 1XD-F3165-00-00 Required per assembly: 1 ~~$2.10~~ $2.00 - + Add to cart
13	CLIP Part #: 1XD-F3447-00-00 Required per assembly: 2 ~~$2.10~~ $1.54 - + Add to cart
14	BOLT, FLANGE Part #: 95812-12040-00 Required per assembly: 4 ~~$3.45~~ $2.84 - + Add to cart
15	JOINT, UNIVERSAL, 1 Part #: 2HC-23841-00-00 Required per assembly: 2 ~~$115.98~~ $110.75 - + Add to cart
16	NUT 1 Part #: 2HC-F3833-00-00 Required per assembly: 2 ~~$4.79~~ $3.99 - + Add to cart
17	STEERING SHAFT ASSY Part #: B4J-F3840-03-00 Required per assembly: 1 ~~$123.98~~ $92.99 - + Add to cart
18	BOLT, SOCKET Part #: 91317-08030-00 Required per assembly: 2 ~~$9.49~~ $6.05 - + Add to cart
19	WASHER, PLATE(3XP) Part #: 90201-083P5-00 Required per assembly: 2 ~~$6.49~~ $5.53 - + Add to cart
20	COLUMN, STEERING, 2 Part #: BKP-23813-00-00 Required per assembly: 1 Not Available
21	POWER STRG. ACTUATOR ASSY Part #: BKP-238B0-03-00 Required per assembly: 1 ~~$3,052.95~~ $2,775.41 - + Add to cart
22	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-08020-00 Required per assembly: 4 ~~$0.60~~ $0.45 - + Add to cart
23	BOLT, FLANGE Part #: 90105-08142-00 Required per assembly: 4 ~~$6.49~~ $4.81 - + Add to cart
24	TOP MOUNT COMP. Part #: BKP-F33B0-00-00 Required per assembly: 1 Not Available
25	BUSH, SOLID Part #: 90381-15088-00 Required per assembly: 4 ~~$23.98~~ $20.53 - + Add to cart
26	COLLAR Part #: 90387-10111-00 Required per assembly: 2 ~~$7.99~~ $6.47 - + Add to cart
27	COVER, THRUST, 1 Part #: 1UY-23517-01-00 Required per assembly: 4 ~~$7.49~~ $6.27 - + Add to cart
28	BOLT, FLANGE Part #: 90105-10267-00 Required per assembly: 2 ~~$10.49~~ $7.61 - + Add to cart
29	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 2 ~~$2.70~~ $2.25 - + Add to cart
30	SPRING, DAMPER Part #: B4J-F3855-02-00 Required per assembly: 1 ~~$91.98~~ $66.56 - + Add to cart
31	BOLT Part #: 90109-06255-00 Required per assembly: 2 ~~$2.54~~ $1.57 - + Add to cart
32	NUT, NYLON Part #: 95707-06300-00 Required per assembly: 2 ~~$3.75~~ $3.14 - + Add to cart
33	HANDLE Part #: B4J-F4812-00-00 Required per assembly: 1 ~~$17.48~~ $12.41 - + Add to cart
34	NUT, CASTLE Part #: 90171-12001-00 Required per assembly: 2 ~~$3.54~~ $2.80 - + Add to cart
35	WASHER, PLATE Part #: 90201-12045-00 Required per assembly: 2 ~~$6.49~~ $5.50 - + Add to cart
36	PIN, COTTER Part #: 91490-20025-00 Required per assembly: 2 ~~$1.99~~ $1.29 - + Add to cart
37	WHEEL, STEERING Part #: 2HC-F3838-02-00 Required per assembly: 1 ~~$133.99~~ $112.26 - + Add to cart
38	NUT, SELF-LOCKING Part #: 90185-12007-00 Required per assembly: 1 ~~$11.49~~ $8.77 - + Add to cart
39	WASHER, PLAIN Part #: 92990-12200-00 Required per assembly: 1 ~~$9.49~~ $6.05 - + Add to cart
40	COVER, STEERING Part #: 2HC-F3818-00-00 Required per assembly: 1 ~~$4.00~~ $3.61 - + Add to cart
41	TUNING FORK MARK Part #: 1XD-F175B-01-00 Required per assembly: 1 ~~$15.49~~ $12.93 - + Add to cart
42	NUT, SPRING, (JA3) Part #: 90183-06071-00 Required per assembly: 2 ~~$0.80~~ $0.53 - + Add to cart
