Electrical 3 replacement parts for 2025 Yamaha Wolverine RMAX4 1000 XT R

OEM Parts Yamaha 2025 Yamaha Wolverine RMAX4 1000 XT R Electrical 3

ELECTRICAL 3 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SENSOR, OXYGEN Part #: 1WS-8592A-10-00 Required per assembly: 1 ~~$242.99~~ $211.09 - + Add to cart
2	PLATE Part #: B4J-E4255-00-00 Required per assembly: 1 ~~$2.20~~ $1.83 - + Add to cart
3	GASKET Part #: B4J-11198-00-00 Required per assembly: 1 ~~$4.45~~ $4.05 - + Add to cart
4	WIRE, MINUS, LEAD Part #: BYP-82116-00-00 Required per assembly: 1 ~~$155.99~~ $145.97 - + Add to cart
5	WIRE HARNESS ASSY Part #: BYP-82590-00-00 Required per assembly: 1 ~~$1,685.84~~ $1,532.58 - + Add to cart
6	FUSE (30A-BL) Part #: 5JJ-82151-60-00 Required per assembly: 2 ~~$8.49~~ $6.29 - + Add to cart
7	FUSE (15A) Part #: 67F-82151-50-00 Required per assembly: 4 Note: (15A) (15A) ~~$4.15~~ $3.93 - + Add to cart
8	FUSE (75A-BL) Part #: 5JJ-82151-00-00 Required per assembly: 5 ~~$7.49~~ $6.29 - + Add to cart
9	FUSE (10A) Part #: 67F-82151-40-00 Required per assembly: 2 Note: (10A) ~~$7.49~~ $6.94 - + Add to cart
10	CIRCUIT BREAKER ASSEMBLY Part #: 5B4-82180-00-00 Required per assembly: 1 ~~$47.99~~ $40.22 - + Add to cart
11	THERMO SWITCH ASSEMBLY Part #: 5B4-82560-00-00 Required per assembly: 1 ~~$61.99~~ $48.22 - + Add to cart
12	FUSE (20A-BL) Part #: 5JJ-82151-20-00 Required per assembly: 2 ~~$8.49~~ $6.29 - + Add to cart
13	FUSE Part #: BDW-82151-D0-00 Required per assembly: 1 ~~$11.49~~ $8.89 - + Add to cart
14	FUSE (50A) Part #: BMG-82151-B0-00 Required per assembly: 1 ~~$4.09~~ $3.43 - + Add to cart
15	BOLT, FLANGE Part #: 90105-06831-00 Required per assembly: 1 ~~$2.29~~ $1.72 - + Add to cart
16	CLAMP Part #: 90464-48800-00 Required per assembly: 6 Note: Sold in multiples of 100 only ~~$4.90~~ $3.46 - + Add to cart
17	CLAMP (2TV) Part #: 90464-10112-00 Required per assembly: 8 Note: Sold in multiples of 5 only ~~$9.49~~ $6.06 - + Add to cart
18	CLAMP Part #: 90464-12830-00 Required per assembly: 3 ~~$1.49~~ $1.03 - + Add to cart
19	CLAMP Part #: 90464-51800-00 Required per assembly: 1 ~~$16.48~~ $11.66 - + Add to cart
20	CLAMP Part #: 90464-36008-00 Required per assembly: 3 ~~$4.00~~ $2.69 - + Add to cart
21	CLAMP Part #: 1NS-F1338-00-00 Required per assembly: 42 ~~$3.60~~ $3.14 - + Add to cart
22	CLAMP Part #: 90464-31827-00 Required per assembly: 2 ~~$3.70~~ $2.59 - + Add to cart
23	CLAMP Part #: 90464-40825-00 Required per assembly: 5 ~~$3.04~~ $1.72 - + Add to cart
24	CLAMP Part #: 90464-10009-00 Required per assembly: 1 ~~$4.95~~ $4.13 - + Add to cart
25	CLAMP Part #: 90464-40825-00 Required per assembly: 1 ~~$3.04~~ $1.72 - + Add to cart
26	SWITCH Part #: BKP-H2917-00-00 Required per assembly: 1 ~~$145.99~~ $108.53 - + Add to cart
27	CONNECTOR Part #: B4J-82378-10-00 Required per assembly: 1 ~~$5.99~~ $4.52 - + Add to cart
28	CONNECTOR Part #: 8CR-82378-00-00 Required per assembly: 1 Note: (8EJ2) ~~$13.49~~ $11.25 - + Add to cart
29	WIRE, LEAD Part #: BYP-H2117-00-00 Required per assembly: 1 ~~$182.99~~ $171.08 - + Add to cart
30	CONNECTOR Part #: BYP-82378-00-00 Required per assembly: 2 ~~$3.89~~ $3.24 - + Add to cart
31	CONNECTOR Part #: BKP-82378-10-00 Required per assembly: 1 ~~$10.49~~ $8.83 - + Add to cart
32	CLAMP Part #: 90464-40825-00 Required per assembly: 1 ~~$3.04~~ $1.72 - + Add to cart
33	CLAMP (2TV) Part #: 90464-10112-00 Required per assembly: 2 Note: Sold in multiples of 5 only ~~$9.49~~ $6.06 - + Add to cart
