Front Fork replacement parts for 2025 Yamaha YZ250X

OEM Parts Yamaha 2025 Yamaha YZ250X Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSY (L.H) Part #: DF4-23102-00-00 Required per assembly: 1 $1,317.54 - + Add to cart
2	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 ~~$649.99~~ $617.68 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
4	INNER TUBE COMP.2 Part #: BCR-23120-00-00 Required per assembly: 1 ~~$349.99~~ $343.72 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
8	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 ~~$24.98~~ $22.79 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
10	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 ~~$19.48~~ $18.90 - + Add to cart
11	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 ~~$24.98~~ $21.65 - + Add to cart
12	CYLINDER, COMP, FRONT, FORK Part #: BRY-23170-00-00 Required per assembly: 1 ~~$349.99~~ $343.72 - + Add to cart
13	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
14	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 ~~$80.98~~ $67.44 - + Add to cart
15	VALVE COMP Part #: DF4-2316A-00-00 Required per assembly: 1 ~~$344.99~~ $338.41 - + Add to cart
16	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $9.01 - + Add to cart
17	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.63 - + Add to cart
18	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
19	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.85 - + Add to cart
20	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
21	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
22	SPRING, FRONT, FORK, (K=4.3) Part #: B3J-23141-30-00 Required per assembly: 1 ~~$120.98~~ $103.42 - + Add to cart
23	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
24	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
25	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
26	CAP Part #: BHR-2319W-00-00 Required per assembly: 1 $13.28 - + Add to cart
27	SCREW Part #: 1MC-23119-10-00 Required per assembly: 1 ~~$2.60~~ $1.85 - + Add to cart
28	FRONT FORK ASSY (R.H) Part #: DF4-23103-00-00 Required per assembly: 1 $1,317.54 - + Add to cart
29	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 ~~$649.99~~ $617.68 - + Add to cart
30	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
31	INNER TUBE COMP.1 Part #: BCR-23110-00-00 Required per assembly: 1 ~~$349.99~~ $343.72 - + Add to cart
32	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
33	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
34	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
35	OIL SEAL Part #: B29-23145-00-00 Required per assembly: 1 ~~$24.98~~ $22.79 - + Add to cart
36	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
37	SCRAPER Part #: B29-4381D-00-00 Required per assembly: 1 ~~$19.48~~ $18.90 - + Add to cart
38	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 ~~$24.98~~ $21.65 - + Add to cart
39	CYLINDER, COMP, FRONT, FORK Part #: BRY-23170-00-00 Required per assembly: 1 ~~$349.99~~ $343.72 - + Add to cart
40	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
41	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 ~~$80.98~~ $67.44 - + Add to cart
42	VALVE COMP Part #: DF4-2316A-00-00 Required per assembly: 1 ~~$344.99~~ $338.41 - + Add to cart
43	O-RING Part #: 1C3-23188-L2-00 Required per assembly: 1 $9.01 - + Add to cart
44	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.63 - + Add to cart
45	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
46	O-RING Part #: 1AE-23147-01-00 Required per assembly: 2 $5.85 - + Add to cart
47	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
48	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
49	SPRING, FRONT, FORK, (K=4.3) Part #: B3J-23141-30-00 Required per assembly: 1 ~~$120.98~~ $103.42 - + Add to cart
50	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
51	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
52	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
53	CAP Part #: BHR-2319W-00-00 Required per assembly: 1 $13.28 - + Add to cart
54	SCREW Part #: 1MC-23119-10-00 Required per assembly: 1 ~~$2.60~~ $1.85 - + Add to cart
55	UNDER BRACKET COMP. Part #: 1SS-23340-10-00 Required per assembly: 1 $630.78 - + Add to cart
56	BEARING (4SR) Part #: 93332-00081-00 Required per assembly: 1 $63.99 - + Add to cart
57	BOLT, FLANGE, DEEP, RECESS Part #: 95E34-08035-00 Required per assembly: 8 $3.48 - + Add to cart
58	GUIDE, CABLE Part #: BF1-23389-00-00 Required per assembly: 1 $8.67 - + Add to cart
59	BOLT, FLANGE, DEEP, RECESS Part #: 95E32-06016-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
60	COLLAR Part #: 90387-06104-00 Required per assembly: 1 $1.90 - + Add to cart
61	PROTECTOR 2 Part #: 17D-2315J-J0-00 Required per assembly: 1 $19.50 - + Add to cart
62	PROTECTOR 1 Part #: 17D-2315H-J0-00 Required per assembly: 1 $19.50 - + Add to cart
63	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.87 - + Add to cart
64	CLAMP Part #: 17D-23466-00-00 Required per assembly: 1 ~~$18.98~~ $18.90 - + Add to cart
65	CLAMP Part #: 17D-23467-00-00 Required per assembly: 1 ~~$27.98~~ $23.64 - + Add to cart
66	BOLT, FLANGE Part #: 90105-06170-00 Required per assembly: 2 $5.85 - + Add to cart
67	FORK SEALS KIT Part #: BCR-W003B-00-00 Required per assembly: 1 $75.21 - + Add to cart
