Front Fork replacement parts for 2025 Yamaha YZ85

OEM Parts Yamaha 2025 Yamaha YZ85 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSY (L.H) Part #: B4B-23102-02-00 Required per assembly: 1 $712.35 - + Add to cart
2	TUBE, OUTER, 2 Part #: B4B-23136-00-00 Required per assembly: 1 ~~$489.99~~ $473.94 - + Add to cart
3	INNER TUBE COMP.2 Part #: B4B-23120-00-00 Required per assembly: 1 ~~$244.99~~ $240.77 - + Add to cart
4	PISTON, FRONT, FORK Part #: 5PA-23171-00-00 Required per assembly: 1 Note: (5PA1) ~~$33.99~~ $26.77 - + Add to cart
5	METAL, SLIDE, 1 Part #: 5PA-23125-00-00 Required per assembly: 1 Note: (5PA1) ~~$21.98~~ $19.40 - + Add to cart
6	WASHER, SPRING, UPPER Part #: 5K5-23149-00-00 Required per assembly: 1 $9.85 - + Add to cart
7	OIL SEAL Part #: 4ES-23145-00-00 Required per assembly: 1 ~~$24.98~~ $21.10 - + Add to cart
8	RING, SNAP Part #: 4A1-23156-00-00 Required per assembly: 1 $6.59 - + Add to cart
9	SEAL, DUST Part #: 4ES-23144-00-00 Required per assembly: 1 ~~$26.98~~ $21.85 - + Add to cart
10	CYLINDER, COMP, FRONT, FORK Part #: B4B-23170-01-00 Required per assembly: 1 ~~$244.99~~ $240.77 - + Add to cart
11	VALVE COMP. Part #: B4B-2316A-01-00 Required per assembly: 1 ~~$174.99~~ $171.96 - + Add to cart
12	O-RING Part #: 4DA-23147-L1-00 Required per assembly: 1 $7.94 - + Add to cart
13	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
14	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
15	SEAT, SPRING, UPPER Part #: B4B-23142-01-00 Required per assembly: 1 ~~$32.99~~ $28.23 - + Add to cart
16	NUT Part #: 3XJ-23357-L0-00 Required per assembly: 1 $1.42 - + Add to cart
17	SPRING, FRONT, FORK Part #: 4ES-23141-80-00 Required per assembly: 1 ~~$56.99~~ $47.13 - + Add to cart
18	WASHER, SPRING, UPPER Part #: 5PA-23149-00-00 Required per assembly: 1 Note: (5PA1) $6.55 - + Add to cart
19	BOLT, CAP Part #: BR8-23111-01-00 Required per assembly: 1 ~~$181.99~~ $156.39 - + Add to cart
20	O-RING Part #: 4V4-23188-L1-00 Required per assembly: 1 $6.55 - + Add to cart
21	PLUG, HOLE Part #: 3JD-2312G-L1-00 Required per assembly: 1 $5.55 - + Add to cart
22	FRONT FORK ASSY (R.H) Part #: B4B-23103-02-00 Required per assembly: 1 $712.35 - + Add to cart
23	TUBE, OUTER, 2 Part #: B4B-23136-00-00 Required per assembly: 1 ~~$489.99~~ $473.94 - + Add to cart
24	INNER TUBE COMP.1 Part #: B4B-23110-00-00 Required per assembly: 1 ~~$244.99~~ $240.77 - + Add to cart
25	PISTON, FRONT, FORK Part #: 5PA-23171-00-00 Required per assembly: 1 Note: (5PA1) ~~$33.99~~ $26.77 - + Add to cart
26	METAL, SLIDE, 1 Part #: 5PA-23125-00-00 Required per assembly: 1 Note: (5PA1) ~~$21.98~~ $19.40 - + Add to cart
27	WASHER, SPRING, UPPER Part #: 5K5-23149-00-00 Required per assembly: 1 $9.85 - + Add to cart
28	OIL SEAL Part #: 4ES-23145-00-00 Required per assembly: 1 ~~$24.98~~ $21.10 - + Add to cart
29	RING, SNAP Part #: 4A1-23156-00-00 Required per assembly: 1 $6.59 - + Add to cart
30	SEAL, DUST Part #: 4ES-23144-00-00 Required per assembly: 1 ~~$26.98~~ $21.85 - + Add to cart
31	CYLINDER, COMP, FRONT, FORK Part #: B4B-23170-01-00 Required per assembly: 1 ~~$244.99~~ $240.77 - + Add to cart
32	VALVE COMP. Part #: B4B-2316A-01-00 Required per assembly: 1 ~~$174.99~~ $171.96 - + Add to cart
33	O-RING Part #: 4DA-23147-L1-00 Required per assembly: 1 $7.94 - + Add to cart
34	GASKET Part #: 276-23114-02-00 Required per assembly: 1 $4.52 - + Add to cart
35	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
36	SEAT, SPRING, UPPER Part #: B4B-23142-01-00 Required per assembly: 1 ~~$32.99~~ $28.23 - + Add to cart
37	NUT Part #: 3XJ-23357-L0-00 Required per assembly: 1 $1.42 - + Add to cart
38	SPRING, FRONT, FORK Part #: 4ES-23141-80-00 Required per assembly: 1 ~~$56.99~~ $47.13 - + Add to cart
39	WASHER, SPRING, UPPER Part #: 5PA-23149-00-00 Required per assembly: 1 Note: (5PA1) $6.55 - + Add to cart
40	BOLT, CAP Part #: BR8-23111-01-00 Required per assembly: 1 ~~$181.99~~ $156.39 - + Add to cart
41	O-RING Part #: 4V4-23188-L1-00 Required per assembly: 1 $6.55 - + Add to cart
42	PLUG, HOLE Part #: 3JD-2312G-L1-00 Required per assembly: 1 $5.55 - + Add to cart
43	UNDER BRACKET COMP. Part #: BR8-23340-00-00 Required per assembly: 1 $667.15 - + Add to cart
44	BOLT 1 Part #: 5PA-23346-00-00 Required per assembly: 4 $7.13 - + Add to cart
45	GUIDE, CABLE Part #: BR8-2331E-00-00 Required per assembly: 1 ~~$27.98~~ $22.90 - + Add to cart
46	BEARING TAPRD Part #: 93332-00079-00 Required per assembly: 1 ~~$75.98~~ $62.48 - + Add to cart
47	PROTECTOR 1 Part #: B4B-2315H-20-00 Required per assembly: 1 $20.69 - + Add to cart
48	PROTECTOR 2 Part #: B4B-2315J-20-00 Required per assembly: 1 $20.69 - + Add to cart
49	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.87 - + Add to cart
50	CLAMP Part #: 17D-23466-00-00 Required per assembly: 1 ~~$18.98~~ $18.90 - + Add to cart
51	CLAMP Part #: 17D-23467-00-00 Required per assembly: 1 ~~$27.98~~ $23.64 - + Add to cart
52	BOLT Part #: 90109-06232-00 Required per assembly: 2 $4.87 - + Add to cart
53	GUIDE, CABLE Part #: 5TJ-23389-80-00 Required per assembly: 1 ~~$12.99~~ $12.27 - + Add to cart
54	BOLT, SOCKET Part #: 91317-05016-00 Required per assembly: 1 ~~$3.54~~ $3.50 - + Add to cart
55	COLLAR Part #: 90387-05065-00 Required per assembly: 1 ~~$3.95~~ $3.61 - + Add to cart
