Front Fork replacement parts for 2026 Honda CB650RAC

OEM Parts Honda 2026 Honda CB650RAC Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 11
001	FORK ASSEMBLY, R. FR. Part #: 51400-MKY-E21 Required per assembly: 1 ~~$569.87~~ $465.84 - + Add to cart
002	SPRING, R. FR. FORK Part #: 51401-MKY-E01 Required per assembly: 1 ~~$37.44~~ $29.84 - + Add to cart
003	COLLAR, SPRING Part #: 51402-MKY-E01 Required per assembly: 1 $2.39 - + Add to cart
004	JOINT, SPRING Part #: 51404-MKP-DN1 Required per assembly: 2 $4.24 - + Add to cart
005	TUBE (OUTER) Part #: 51410-MKN-D51 Required per assembly: 2 ~~$289.49~~ $230.75 - + Add to cart
006	RING, BACK-UP Part #: 51412-MB4-003 Required per assembly: 2 $12.57 - + Add to cart
007	SPRING, R., REBOUND Part #: 51412-MKY-D51 Required per assembly: 1 $3.72 - + Add to cart
008	BUSH, GUIDE Part #: 51414-MFJ-A51 Required per assembly: 2 $10.11 - + Add to cart
009	BUSH, SLIDER Part #: 51415-MFJ-A51 Required per assembly: 2 $10.11 - + Add to cart
010	SEAT, STOPPER Part #: 51419-K94-T01 Required per assembly: 1 $11.52 - + Add to cart
011	SEAT, R., STOPPER Part #: 51419-MKY-D51 Required per assembly: 1 $8.31 - + Add to cart
012	PIPE, R. SLIDE Part #: 51425-MKY-E01 Required per assembly: 1 ~~$344.96~~ $274.97 - + Add to cart
013	ROD, PISTON Part #: 51426-MKY-E01 Required per assembly: 1 ~~$57.15~~ $45.55 - + Add to cart
014	RING, PISTON Part #: 51437-MKY-D51 Required per assembly: 1 ~~$2.44~~ $1.92 - + Add to cart
015	RING Part #: 51447-KA4-711 Required per assembly: 1 $6.56 - + Add to cart
016	CIRCLIP (INNER) Part #: 51447-MB4-003 Required per assembly: 1 $6.75 - + Add to cart
017	BOLT, FR. FORK Part #: 51450-K98-J61 Required per assembly: 2 ~~$88.98~~ $70.93 - + Add to cart
018	NUT, HEX. Part #: 51451-MKY-D51 Required per assembly: 2 $15.99 - + Add to cart
020	CASE, ROD GUIDE Part #: 51455-MKY-E01 Required per assembly: 1 ~~$55.53~~ $44.26 - + Add to cart
021	RING, STOPPER Part #: 51456-K94-T01 Required per assembly: 2 ~~$3.26~~ $3.05 - + Add to cart
022	SEAL, SET, FR., FORK Part #: 51490-MKL-D81 Required per assembly: 2 ~~$30.45~~ $25.10 - + Add to cart
023	FORK ASSEMBLY, L. FR. Part #: 51500-MKY-E21 Required per assembly: 1 ~~$532.00~~ $436.61 - + Add to cart
024	SPRING, L. FR. FORK Part #: 51501-MKY-E01 Required per assembly: 1 ~~$29.45~~ $24.67 - + Add to cart
025	COLLAR B, SPRING Part #: 51502-MKY-E01 Required per assembly: 1 $6.81 - + Add to cart
026	SPRING, L., REBOUND Part #: 51512-MKY-D51 Required per assembly: 1 $6.00 - + Add to cart
027	PIPE, L. SLIDE Part #: 51525-MKY-E01 Required per assembly: 1 ~~$347.00~~ $276.60 - + Add to cart
028	ROD Part #: 51526-MKY-D51 Required per assembly: 1 $16.18 - + Add to cart
029	BOLT, FLANGE, (8X40) Part #: 90107-MGE-000 Required per assembly: 4 ~~$3.69~~ $3.62 - + Add to cart
030	DUST SEAL (SHOWA) Part #: 91251-MKL-D81 Required per assembly: 2 $13.69 - + Add to cart
031	O-RING (39.7X2.4) Part #: 91258-MEE-D01 Required per assembly: 2 ~~$3.09~~ $2.90 - + Add to cart
032	O-RING (33.2X2.4) Part #: 91356-KF0-003 Required per assembly: 1 $5.52 - + Add to cart
