Front Fork replacement parts for 2026 Honda CMX500A2

OEM Parts Honda 2026 Honda CMX500A2 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 11
002	FORK ASSEMBLY, R. FR. (SHOWA) Part #: 51400-MLH-D81 Required per assembly: 1 $320.98 $255.98 - + Add to cart
003	SPRING, FR. FORK Part #: 51401-MLH-D41 Required per assembly: 2 $80.16 $63.93 - + Add to cart
004	COLLAR, SPRING Part #: 51402-K87-A31 Required per assembly: 2 $5.97 $5.43 - + Add to cart
005	PIPE, FR., FORK Part #: 51410-K87-A31 Required per assembly: 2 $219.20 $174.81 - + Add to cart
006	RING, BACK-UP Part #: 51412-MB4-003 Required per assembly: 2 $11.18 $9.55 - + Add to cart
007	BUSH, GUIDE Part #: 51414-MFJ-A51 Required per assembly: 2 $8.71 $7.55 - + Add to cart
008	BUSH, SLIDER Part #: 51415-MFJ-A51 Required per assembly: 2 $8.71 $7.55 - + Add to cart
009	SPRING, FR. REBOUND Part #: 51416-K2Y-J41 Required per assembly: 2 $38.64 $30.81 - + Add to cart
010	CASE, R., (LOWER) Part #: 51420-K87-A31 Required per assembly: 1 $202.38 $161.40 - + Add to cart
011	PIECE, OIL LOCK Part #: 51432-K0Z-901 Required per assembly: 2 $7.42 $5.92 - + Add to cart
012	RING, PISTON Part #: 51437-MM5-003 Required per assembly: 2 $6.39 $5.66 - + Add to cart
013	PIPE, SEAT Part #: 51440-K2Y-J41 Required per assembly: 2 $38.33 $30.57 - + Add to cart
014	RING Part #: 51447-KA4-711 Required per assembly: 2 $5.44 $4.89 - + Add to cart
015	BOLT, FR. FORK Part #: 51454-MLH-D81 Required per assembly: 2 $82.58 $65.86 - + Add to cart
016	SEAL, SET, FR., FORK Part #: 51490-MKL-D81 Required per assembly: 2 $29.12 $24.29 - + Add to cart
018	FORK ASSEMBLY, L. FR. (SHOWA) Part #: 51500-MLH-D81 Required per assembly: 1 $313.93 $250.36 - + Add to cart
019	CASE, L., (LOWER) Part #: 51520-K87-A31 Required per assembly: 1 $200.09 $159.57 - + Add to cart
020	BOOT, FR., FORK Part #: 51611-K87-A31 Required per assembly: 2 $34.73 $27.70 - + Add to cart
021	BAND, FR., FORK, BOOT Part #: 51612-K87-A31 Required per assembly: 2 $31.42 $28.16 - + Add to cart
022	COVER, FR., FORK Part #: 51621-K87-A30 Required per assembly: 2 $42.35 $34.63 - + Add to cart
023	RUBBER, FR., FORK, (UPPER) Part #: 51622-K87-A30 Required per assembly: 2 $8.38 $8.03 - + Add to cart
024	BOLT, SOCKET, (8X32) Part #: 90102-K87-A00 Required per assembly: 4 $1.78 $1.64 - + Add to cart
025	BOLT, SOCKET, (8MM) Part #: 90116-KV3-701 Required per assembly: 2 $5.26 $4.78 - + Add to cart
026	WASHER (8MM) Part #: 90544-283-000 Required per assembly: 2 $3.89 $3.54 - + Add to cart
027	DUST SEAL (SHOWA) Part #: 91251-MKL-D81 Required per assembly: 2 $12.36 $10.01 - + Add to cart
028	O-RING (33.2X2.4) Part #: 91356-KF0-003 Required per assembly: 2 $5.12 $4.65 - + Add to cart
