Shift Drum - Shift Fork replacement parts for 2026 Honda GL1800B

OEM Parts Honda 2026 Honda GL1800B Shift Drum - Shift Fork

SHIFT DRUM - SHIFT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

E 20
001	HOLDER, TRANSMISSION Part #: 11130-MKC-A20 Required per assembly: 1 ~~$203.66~~ $164.78 - + Add to cart
002	GASKET, TRANSMISSION, HOLDER Part #: 11135-MKC-A01 Required per assembly: 1 ~~$19.78~~ $19.33 - + Add to cart
003	FORK, MAINSHAFT, GEARSHIFT Part #: 24211-MKC-A20 Required per assembly: 2 ~~$68.56~~ $55.48 - + Add to cart
004	FORK, COUNTERSHAFT, GEARSHIFT Part #: 24212-MKC-A20 Required per assembly: 2 ~~$71.66~~ $57.97 - + Add to cart
005	SHAFT, ASSEMBLY, SHIFT, FORK Part #: 24250-MKC-A00 Required per assembly: 2 ~~$37.92~~ $30.68 - + Add to cart
006	DRUM, GEARSHIFT Part #: 24310-MKC-A20 Required per assembly: 1 ~~$397.07~~ $321.26 - + Add to cart
007	CAM, GEARSHIFT, DRUM, LOCK Part #: 24312-MKC-A20 Required per assembly: 1 ~~$44.59~~ $36.07 - + Add to cart
008	STOPPER, DRUM Part #: 24430-MKC-A20 Required per assembly: 1 ~~$28.29~~ $24.33 - + Add to cart
009	SPRING, SHIFT, DRUM, STOPPER Part #: 24436-MKC-A20 Required per assembly: 1 $6.20 - + Add to cart
010	SPINDLE, GEARSHIFT Part #: 24610-MKC-A20 Required per assembly: 1 ~~$235.30~~ $190.36 - + Add to cart
011	SPINDLE, GEARSHIFT Part #: 24620-MKC-A20 Required per assembly: 1 ~~$55.40~~ $44.83 - + Add to cart
012	PIN, RETURN, SPRING Part #: 24652-MKC-A00 Required per assembly: 1 $8.38 - + Add to cart
013	PLATE, SHIFT, DRUM, BEARING, SETTING Part #: 24656-MKC-A00 Required per assembly: 1 $6.91 - + Add to cart
014	PIVOT, SHIFT, DRUM, STOPPER, ARM Part #: 90022-MKC-A00 Required per assembly: 1 $4.45 - + Add to cart
015	BOLT, FLANGE, (8X30) Part #: 90078-MKC-A00 Required per assembly: 5 $3.81 - + Add to cart
016	WASHER (14MM) Part #: 90402-HA0-000 Required per assembly: 1 $5.52 - + Add to cart
017	WASHER, DRUM, STOPPER Part #: 90417-360-000 Required per assembly: 1 ~~$2.73~~ $2.39 - + Add to cart
018	BEARING (607ZZ) Part #: 91026-MGS-D21 Required per assembly: 1 $12.08 - + Add to cart
019	BEARING, RADIAL, BALL, (20X37X9) Part #: 91028-MKC-A21 Required per assembly: 1 $15.89 - + Add to cart
020	BEARING (14MM) Part #: 91101-121-691 Required per assembly: 2 ~~$31.48~~ $26.25 - + Add to cart
021	OIL SEAL (14X28X7) Part #: 91202-965-003 Required per assembly: 1 $9.05 - + Add to cart
022	PIN, DOWEL, (10X16) Part #: 94303-10160 Required per assembly: 2 $3.26 - + Add to cart
023	CIRCLIP (14MM) Part #: 94510-14000 Required per assembly: 1 ~~$2.06~~ $1.50 - + Add to cart
024	BOLT, FLANGE, (6X16) Part #: 95701-06016-00 Required per assembly: 2 Note: 95701-06016-08* ~~$2.63~~ $2.24 - + Add to cart
025	BOLT, FLANGE, (6X22) Part #: 95701-06022-00 Required per assembly: 1 ~~$2.79~~ $2.54 - + Add to cart
026	ROLLER (4X14.8) Part #: 96220-40148 Required per assembly: 1 ~~$1.60~~ $0.73 - + Add to cart
