Front Fork replacement parts for 2026 Honda NT1100D

OEM Parts Honda 2026 Honda NT1100D Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 11
001	FORK ASSEMBLY, R. FR. (SHOWA) Part #: 51400-MLF-E81 Required per assembly: 1 $939.24 $774.04 - + Add to cart
002	SPRING, R. FR. FORK Part #: 51401-MLF-E71 Required per assembly: 1 $95.17 $86.52 - + Add to cart
003	COLLAR, R. SPRING Part #: 51402-MLF-E71 Required per assembly: 1 $6.20 $4.94 - + Add to cart
004	COLLAR, SPRING Part #: 51404-MKJ-D01 Required per assembly: 1 $20.34 $16.47 - + Add to cart
005	TUBE (OUTER) Part #: 51410-MLF-E71 Required per assembly: 2 $426.36 $340.03 - + Add to cart
006	RING, BACK-UP Part #: 51412-KA4-711 Required per assembly: 2 $11.18 $9.55 - + Add to cart
007	SPRING, R. REBOUND Part #: 51412-MLF-E71 Required per assembly: 1 $7.95 $6.34 - + Add to cart
008	BUSH, GUIDE Part #: 51414-MFN-D01 Required per assembly: 2 $8.51 $7.39 - + Add to cart
009	BUSH, SLIDER Part #: 51415-MFN-D01 Required per assembly: 2 $36.52 $29.57 - + Add to cart
010	SEAT, STOPPER Part #: 51419-MLF-E71 Required per assembly: 2 $6.33 $5.05 - + Add to cart
011	PIPE, R. SLIDE Part #: 51425-MLF-E71 Required per assembly: 1 $321.24 $271.19 - + Add to cart
012	ROD, PISTON Part #: 51426-MLF-E81 Required per assembly: 1 $94.51 $75.37 - + Add to cart
013	RING, PISTON Part #: 51437-MLF-E71 Required per assembly: 1 $4.82 $3.84 - + Add to cart
014	RING Part #: 51447-KA4-711 Required per assembly: 1 $5.44 $4.89 - + Add to cart
015	CIRCLIP (INNER) Part #: 51447-MB4-003 Required per assembly: 1 $5.59 $5.04 - + Add to cart
016	BOLT, FR. FORK Part #: 51450-MLF-E71 Required per assembly: 1 $70.42 $56.16 - + Add to cart
017	NUT, HEX. Part #: 51451-MGP-D01 Required per assembly: 1 $2.90 $2.70 - + Add to cart
018	NUT, HEX. Part #: 51451-MKY-D51 Required per assembly: 1 $15.63 $12.47 - + Add to cart
019	CASE, ROD GUIDE Part #: 51455-MLF-E81 Required per assembly: 1 $56.95 $45.41 - + Add to cart
020	RING, STOPPER Part #: 51456-KZZ-901 Required per assembly: 2 $10.65 $10.07 - + Add to cart
021	SEAL, SET, FR., FORK Part #: 51490-MFL-003 Required per assembly: 2 $22.99 $19.18 - + Add to cart
022	FORK ASSEMBLY, L. FR. (SHOWA) Part #: 51500-MLF-E71 Required per assembly: 1 $913.80 $753.76 - + Add to cart
023	SPRING, L. FR. FORK Part #: 51501-MLF-E71 Required per assembly: 1 $82.29 $65.63 - + Add to cart
024	SPRING, L. REBOUND Part #: 51512-MLF-E71 Required per assembly: 1 $7.95 $6.34 - + Add to cart
025	PIPE, L. SLIDE Part #: 51525-MLF-E71 Required per assembly: 1 $321.24 $271.19 - + Add to cart
026	ROD Part #: 51526-MLF-E71 Required per assembly: 1 $95.65 $76.28 - + Add to cart
027	ROD C, PUSH Part #: 51527-MLF-E71 Required per assembly: 1 $23.92 $19.07 - + Add to cart
028	BOLT, FR., FORK Part #: 51550-MKJ-D01 Required per assembly: 1 $101.43 $82.10 - + Add to cart
029	BOLT, FLANGE, (8X45) Part #: 90109-MR7-000 Required per assembly: 4 $5.92 $5.30 - + Add to cart
030	DUST SEAL Part #: 91254-MEJ-013 Required per assembly: 2 $14.99 $12.12 - + Add to cart
031	O-RING (42.2X2.4) Part #: 91258-GF4-003 Required per assembly: 2 $7.09 $6.24 - + Add to cart
032	O-RING (35.2X2.4) Part #: 91356-KA4-711 Required per assembly: 1 $5.12 $4.65 - + Add to cart
