Honda Power Equipment EX800 - Panel

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
01

HOLDER, CONNECTOR

Part #: 32301-ZA7-003 Required per assembly: 1 Note: (Honda Code 1410943)
Not Available
03

COLLAR, PANEL

Part #: 32344-892-000 Required per assembly: 3 Note: (Honda Code 0865774)
Not Available
04

MARK, PANEL

Part #: 32345-ZA7-631 Required per assembly: 1 Note: (Honda Code 1410968)
$13.62
$9.87
-
+
Add to cart
05

BRKT, ENGINE, SWITCH

Part #: 32375-ZA7-000 Required per assembly: 1 Note: (Honda Code 1410984)
Not Available
07

WIRE, ASSEMBLY, CHARGE

Part #: 32650-825-015
$17.50
$12.69
-
+
Add to cart
07

WIRE, ASSEMBLY, CHARGE

Part #: 32650-825-015
$17.50
$12.69
-
+
Add to cart
08

GROMMET

Part #: 32901-892-003 Required per assembly: 1 Note: (Honda Code 0947440)
Not Available
09

BAND

Part #: 32902-892-003 Required per assembly: 2
$4.38
$4.22
-
+
Add to cart
10

BULB, DASH, (6V, 3W)

Part #: 34902-202-000 Required per assembly: 1 Note: Sold in multiples of 10 only
$3.99
-
+
Add to cart
11

SWITCH, ASSEMBLY, STOP

Part #: 36100-ZA7-000 Required per assembly: 1 Note: (Honda Code 1411008)
Not Available
12

BRACKET ASSEMBLY

Part #: 36110-ZA7-000 Required per assembly: 1 Note: (Honda Code 1411016)
Not Available
13

KNOB, ENGINE, SWITCH

Part #: 36112-ZA7-000 Required per assembly: 1 Note: (Honda Code 1411024)
$13.26
$9.76
-
+
Add to cart
14

LEVER, PETCOCK

Part #: 36115-ZA7-000 Required per assembly: 1 Note: (Honda Code 1411032)
Not Available
15

METER, FREQUENCY

Part #: 37500-ZA7-003 Required per assembly: 1 Note: (Honda Code 1411065)
Not Available
16

LENS, LAMP

Part #: 37901-ZA7-013 Required per assembly: 1 Note: (Honda Code 1411073)
Not Available
17

PROTECTOR (12A)

Part #: 38240-ZA7-000 Required per assembly: 1 Note: (12A) (Honda Code 1411081)
Not Available
21

CAP, BREAKER

Part #: 38251-892-003 Required per assembly: 2 Note: (Honda Code 1437235)
Not Available
24

HOLDER, BREAKER

Part #: 38254-ZA7-003 Required per assembly: 2 Note: (Honda Code 1425578)
Not Available
26

CLIP (2X50)

Part #: 90105-727-000 Required per assembly: 1
$3.80
-
+
Add to cart
27

NUT, SPECIAL, (6MM)

Part #: 90381-812-710 Required per assembly: 1 Note: (6MM) (Honda Code 0239814)
$2.95
$2.74
-
+
Add to cart
28

SCREW, PAN, (3X8)

Part #: 93500-03008-0H Required per assembly: 2
$1.79
$1.65
-
+
Add to cart
29

SCREW-WASHER (5X16)

Part #: 93891-05016-08 Required per assembly: 4
$2.18
$2.02
-
+
Add to cart
30

SCREW-WASHER (5X12)

Part #: 93894-05012-08 Required per assembly: 3
$2.01
$1.86
-
+
Add to cart
31

SCREW, TAPPING, (3X8)

Part #: 93901-22120 Required per assembly: 6
$5.13
$4.97
-
+
Add to cart
32

SCREW, TAP, (4X10)

Part #: 93901-24220 Required per assembly: 2
$3.93
-
+
Add to cart
33

SCREW, TAPPING, (3X8)

Part #: 93901-32120 Required per assembly: 2
$1.87
$1.73
-
+
Add to cart
34

WASHER, PLAIN, (3MM)

Part #: 94101-03800 Required per assembly: 2
$2.02
$1.87
-
+
Add to cart
35

WASHER, PLAIN, (6MM)

Part #: 94101-06800 Required per assembly: 1
Not Available
