Instruments > 447045 **See Tech News 118** replacement parts for Triumph Scrambler EFI

OEM Parts Triumph Scrambler EFI Instruments > 447045 **See Tech News 118**

Instruments > 447045 **See Tech News 118** Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, ASSEMBLY, KMH, EFI Part #: T2503156 Required per assembly: 1 Note: All except UK, US, TW & CY ~~$853.81~~ $839.11 - + Add to cart
1	INSTRUMENT, ASSEMBLY, MPH, EFI Part #: T2503155 Required per assembly: 1 Note: UK, US, TW & CY Not Available
2	SPEEDO, GAUGE, KMH, EFI Part #: T2503139 Required per assembly: 1 Note: All except UK, US, TW & CY ~~$378.49~~ $371.97 - + Add to cart
2	SPEEDO, GAUGE, MPH, EFI Part #: T2503138 Required per assembly: 1 Note: UK, US, TW & CY ~~$378.49~~ $371.97 - + Add to cart
3	INSTRUMENT CASTING Part #: T2503102 Required per assembly: 1 ~~$38.44~~ $37.77 - + Add to cart
4	DAMPER, RUBBER, SPEEDO Part #: T2503107 Required per assembly: 1 Not Available
5	CAN, SPEEDO Part #: T2503105 Required per assembly: 1 ~~$142.58~~ $140.12 - + Add to cart
6	RESET KNOB Part #: T2503106 Required per assembly: 1 ~~$8.01~~ $7.28 - + Add to cart
7	SCREW, RESET, KNOB Part #: T2501205 Required per assembly: 1 ~~$1.47~~ $1.34 - + Add to cart
8	BULB, INSTRUMENTS, 1.7W Part #: T2502089 Required per assembly: 1 ~~$2.87~~ $2.61 - + Add to cart
9	BULB, INSTRUMENTS, T6.5, 1.7W Part #: 2500085T0301 Required per assembly: 5 ~~$5.90~~ $5.36 - + Add to cart
10	WASHER, INSTRUMENT, CAN Part #: T2501188 Required per assembly: 4 ~~$1.33~~ $1.21 - + Add to cart
11	NUT, INSTRUMENT, CAN Part #: T2501189 Required per assembly: 4 ~~$2.36~~ $2.15 - + Add to cart
12	LIGHT, UNIT, RUBBER Part #: T2501208 Required per assembly: 4 ~~$6.07~~ $5.52 - + Add to cart
13	LENS, INDICATOR Part #: T2501209 Required per assembly: 1 ~~$13.40~~ $13.17 - + Add to cart
14	LENS, HIGH, BEAM Part #: T2501210 Required per assembly: 1 ~~$10.88~~ $9.89 - + Add to cart
15	LENS, OIL, WARNING Part #: T2501211 Required per assembly: 1 ~~$10.88~~ $9.89 - + Add to cart
16	LENS, NEUTRAL Part #: T2501212 Required per assembly: 1 ~~$20.56~~ $20.20 - + Add to cart
17	PLUG, LED Part #: T2501227 Required per assembly: 1 ~~$3.10~~ $2.82 - + Add to cart
18	SUBHARNESS, INSTRUMENT Part #: T2503108 Required per assembly: 1 ~~$163.71~~ $160.89 - + Add to cart
19	SCREW, CAP/HD, M5X0.8X16, S/S Part #: T3050139 Required per assembly: 4 ~~$3.76~~ $3.42 - + Add to cart
