Instruments replacement parts for Triumph Speed Triple 885cc / 955cc (EFI)

OEM Parts Triumph Speed Triple 885cc / 955cc (EFI) > 141871 Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SPEEDOMETER, GAUGE, KPH Part #: T2504005 Required per assembly: 1 Not Available
1	SPEEDOMETER, GAUGE, MPH Part #: T2504000 Required per assembly: 1 Not Available
2	BULB, INSTRUMENTS, T6.5, 1.7W Part #: 2500085T0301 Required per assembly: 1 Note: 12V, 1.7W, 6.5mm Dia Speedometer gauge $5.74 $5.22 - + Add to cart
3	BULB, INSTRUMENTS, T10, 1.7W Part #: 2500095T0301 Required per assembly: 4 Note: 12V, 1.7W, 10mm Dia Speedo, Tacho & Temp gauges $6.28 $5.71 - + Add to cart
4	HARNESS, SPEEDOMETER Part #: T2504001 Required per assembly: 1 Note: Speedometer $22.32 $7.09 - + Add to cart
5	SCREW Part #: T2505018 Required per assembly: 1 $0.91 $0.83 - + Add to cart
6	TRIP KNOB Part #: T2504002 Required per assembly: 1 Not Available
7	TACHOMETER, GAUGE, 9, 500 Part #: T2504100 Required per assembly: 1 Not Available
8	HARNESS, TACHOMETER Part #: T2504101 Required per assembly: 1 Not Available
9	TEMPERATURE GAUGE Part #: T2504200 Required per assembly: 1 Not Available
10	WARNING LIGHT UNIT Part #: T2504300 Required per assembly: 1 Not Available
11	BULB, INSTRUMENTS, T6.5, 3.0W Part #: T2500090 Required per assembly: 6 Note: 12V, 3.0W, 6.5mm Dia Warning light $6.26 $5.69 - + Add to cart
12	WARNING LIGHT UNIT Part #: T2504300 Required per assembly: 1 Note: Warning light Not Available
13	LIGHT BOX COVER Part #: T2500490 Required per assembly: 1 Note: > 89736 $19.95 $19.60 - + Add to cart
13	LIGHT BOX COVER Part #: T2500490 Required per assembly: 1 Note: 89737 > $19.95 $19.60 - + Add to cart
14	SEAL-WARNING LIGHT UNIT Part #: T2505016 Required per assembly: 1 $1.14 $1.03 - + Add to cart
15	SCREW M4 X 16 Part #: T3330262 Required per assembly: 5 Note: M4 x 16mm Not Available
16	WASHER, M4, CSK, CONE, SS Part #: T3550187 Required per assembly: 2 Note: PART NO LONGER AVAILABLE - M4 Not Available
17	RUBBER, SEAL, SPEEDO, GAUGE Part #: T2500472 Required per assembly: 1 Note: Speedometer Not Available
18	RUBBER, SEAL, TACHO, GAUGE Part #: T2500473 Required per assembly: 1 Note: Tachometer $3.39 $3.09 - + Add to cart
19	RUBBER, SEAL, TEMP, GAUGE Part #: T2500474 Required per assembly: 1 Note: Temperature gauge $2.65 $0.84 - + Add to cart
20	INSTRUMENT HOUSING COVER PLATE Part #: T2500471 Required per assembly: 1 Not Available
21	INSTRUMENT HOUSING Part #: T2500315 Required per assembly: 1 Not Available
22	GROMMET, RUBBER Part #: T3020015 Required per assembly: 3 $2.20 $2.00 - + Add to cart
23	SLEEVE Part #: T3010007 Required per assembly: 3 Note: M5 Not Available
24	SCREW, BUT/HD, M5, X, 20, SILVER Part #: T3338989 Required per assembly: 3 $6.46 $5.87 - + Add to cart
25	GROMMET Part #: T2505015 Required per assembly: 6 Note: PART NO LONGER AVAILABLE Not Available
26	NUT, AND, WASHER, ASSEMBLY, M5X0.8, SLV Part #: T2700493 Required per assembly: 6 $1.82 $1.65 - + Add to cart
27	CABLE, SPEEDOMETER, 45, DEG Part #: T2040457 Required per assembly: 1 $42.32 $41.58 - + Add to cart
28	SCREW., PHIL, CSK., M5, X, 20, SLV Part #: T3331017 Required per assembly: 1 Note: M5 x 17mm $4.34 $3.94 - + Add to cart
29	NOT SUPPLIED-SEE T2504200 Part #: T2504201 Required per assembly: 1 Note: Temperature gauge Not Available
