Fuel Tank, Fuel Pump & Fittings replacement parts for Triumph Speed Triple 885cc / 955cc (EFI)

OEM Parts Triumph Speed Triple 885cc / 955cc (EFI) > 141871 Fuel Tank, Fuel Pump & Fittings

Fuel Tank, Fuel Pump & Fittings Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL, TANK, &, INSUL, ASSEMBLY, RED Part #: T2402725CM Required per assembly: 1 Note: 955cc Engine, Tornado Red; Includes heat pad, item 24 Not Available
1	FUEL, TANK, &, INSUL, ASSEMBLY, BLACK Part #: T2402715PG Required per assembly: 1 Note: 89736 > 955cc Engine, Jet Black; Includes heat pad, item 24 Not Available
1	FUEL, TANK, &, INSUL, ASSEMBLY, GREEN Part #: T2402715HG Required per assembly: 1 Note: > 89736 955cc Engine, Roulette Green; Includes heat pad, item 24 ~~$768.54~~ $755.32 - + Add to cart
1	FUEL, TANK, ASSEMBLY, JET, BLACK Part #: T2402515PG Required per assembly: 1 Note: 89737 > 955cc Engine, Jet Black; Includes heat pad, item 24 Not Available
1	TANK, PNT, DEC, LAQ, H/PAD, BLUE Part #: T2402515JO Required per assembly: 1 Note: 955cc Engine, Neon Blue; Includes heat pad, item 24 Not Available
1	FUEL, TANK, &, HEAT, PAD, ASSEMBLY, D, GN Part #: T2402515HH Required per assembly: 1 Note: 955cc Engine, Aston Green; Includes heat pad, item 24 Not Available
1	FUEL, TANK, ASSEMBLY, ROULETTE, GREEN Part #: T2402515HG Required per assembly: 1 Note: 89737 > 955cc Engine, Roulette Green; Includes heat pad, item 24 Not Available
1	FUEL, TANK, &, HEAT, PAD, ASSEMBLY, YELO Part #: T2402515FA Required per assembly: 1 Note: 955cc Engine, Racing Yellow; Includes heat pad, item 24 Not Available
1	TANK, PNT, DEC, LAQ, H/PAD, RED Part #: T2402515CQ Required per assembly: 1 Note: 955cc Engine, Nuclear Red; Includes heat pad, item 24 ~~$762.09~~ $748.97 - + Add to cart
1	FUEL, TANK, SPARES, ASSEMBLY, GREEN Part #: T2402502HG Required per assembly: 1 Note: 885cc Engine, Roulette Green; Includes heat pad, item 24 Not Available
1	FUEL, TANK, ASSEMBLY, ORANGE, T500 Part #: T2402502ED Required per assembly: 1 Note: 885cc Engine, Lucifer Orange; Includes heat pad, item 24 ~~$2,529.81~~ $2,299.83 - + Add to cart
1	FUEL, TANK, PNT/DEC/LAQ, RED Part #: T2402506CM Required per assembly: 1 Note: 885cc Engine, Tornado Red; Includes heat pad, item 24 Not Available
1	FUEL, TANK, PNT, DEC, LAQ, JET, BLK Part #: T2402502PG Required per assembly: 1 Note: 885cc Engine, Jet Black; Includes heat pad, item 24 Not Available
2	TANK, PANEL, PNT, DEC, LAQ, RED Part #: T2402512CQ Required per assembly: 1 Note: Nuclear Red Not Available
2	TANK, COVER, JET, BLACK Part #: T2402512PG Required per assembly: 1 Note: 89737 > Jet Black Not Available
2	TANK, PANEL, PNTDEC, LAQ, BLUE Part #: T2402512JO Required per assembly: 1 Note: Neon Blue Not Available
2	TANK, PANEL, PNT, DEC, &, LAQ, D.GRN Part #: T2402512HH Required per assembly: 1 Note: Aston Green Not Available
2	TANK, COVER, ROULETTE, GREEN Part #: T2402512HG Required per assembly: 1 Note: 89737 > Roulette Green Not Available
2	TANK, PANEL, PNT, DEC, &, LAQ, YELLO Part #: T2402512FA Required per assembly: 1 Note: Racing Yellow Not Available
2	F/TANK, CVR, PNL, PNT/LAQ, GREEN Part #: T2402501HG Required per assembly: 1 Note: > 89736 Roulette Green Not Available
2	COVER, FUEL, TANK Part #: T2402501ED Required per assembly: 1 Note: Lucifer Orange Not Available
2	TANK, COVER, PNL, P&L, JET, BLACK Part #: T2402501PG Required per assembly: 1 Note: > 89736 Jet Black Not Available
2	TANK, COVER, PNT/DEC/LAQ, RED Part #: T2402501CM Required per assembly: 1 Note: Tornado Red ~~$336.75~~ $330.95 - + Add to cart
3	BOLT, BUT/HD, M5, X, 11, SHLD, SLV Part #: T3331061 Required per assembly: 5 Note: > 61845 M5 x 11mm ~~$5.28~~ $4.80 - + Add to cart
3	BOLT, BUT/HD, M5, X, 11, SHLD, SLV Part #: T3331061 Required per assembly: 5 Note: 61846 > M5 x 11mm ~~$5.28~~ $4.80 - + Add to cart
4	WASHER, NYLON, 12.45, X, 7.14X0.76 Part #: T3550094 Required per assembly: 5 ~~$1.15~~ $1.05 - + Add to cart
5	SEAL, BASE, FUEL, FILLER Part #: T2500468 Required per assembly: 1 ~~$7.51~~ $6.82 - + Add to cart
6	NECK, FUEL, FILLER Part #: T2500469 Required per assembly: 1 ~~$17.13~~ $16.83 - + Add to cart
7	SEAL, CAP, FUEL, FILLER Part #: T2500464 Required per assembly: 1 ~~$8.41~~ $7.65 - + Add to cart
8	CAP, FUEL, FILLER, NON, VENTED Part #: T2501012 Required per assembly: 1 ~~$197.17~~ $193.78 - + Add to cart
9	SCREW, CAP, /, HD, M5, X, 10, SILVER Part #: T3050341 Required per assembly: 3 Note: 459486 > ~~$3.99~~ $3.63 - + Add to cart
10	SCREW, CAP/HD, M5X0.8X30, S/S Part #: T3050144 Required per assembly: 3 ~~$2.36~~ $2.15 - + Add to cart
11	SCREW, CAP/HD, M5X0.8X16, SLV Part #: T3050342 Required per assembly: 1 ~~$2.99~~ $2.72 - + Add to cart
12	BOLT, M8, X, 20 Part #: T3330770 Required per assembly: 1 Note: M8 x 20mm Not Available
13	WASHER, 6.4, X, 14, X, 1.6 Part #: T3555004 Required per assembly: 2 ~~$1.47~~ $1.34 - + Add to cart
14	WASHER, RUBBER, 24X14X4 Part #: T3550064 Required per assembly: 3 Note: PART NO LONGER AVAILABLE Not Available
15	FLANGED, LOCK, NUT, M6 Part #: T3350003 Required per assembly: 2 Note: M6 ~~$0.70~~ $0.64 - + Add to cart
16	GROMMET, RUBBER Part #: T3020060 Required per assembly: 2 Note: PART NO LONGER AVAILABLE Not Available
17	FLANGED, SLEEVE, M6, X, 25.8 Part #: T3010029 Required per assembly: 2 Note: M6 x 29mm Not Available
18	BOLTM6 X 45 Part #: 3200035T0301 Required per assembly: 2 Note: M6 x 45mm Not Available
19	GROMMET, RUBBER Part #: T3020070 Required per assembly: 1 Note: PART NO LONGER AVAILABLE Not Available
20	GASKET, FUEL, PUMP, MNTG, PLATE, (10, HOLE, PLATE) Part #: T1240864 Required per assembly: 1 Note: 10 hole plate ~~$18.12~~ $17.80 - + Add to cart
20	SEAL, MNTG, PLATE, FUEL, PUMP, (14, HOLE, PLATE) Part #: T1241054 Required per assembly: 1 Note: 14 hole plate ~~$56.36~~ $55.38 - + Add to cart
21	SEALING, WASHER, FUEL, SENSOR Part #: 2400071T0301 Required per assembly: 1 ~~$3.76~~ $3.42 - + Add to cart
22	LOW FUEL WARNING SENSOR Part #: 2400070T0301 Required per assembly: 1 Note: Low fuel ~~$165.48~~ $162.63 - + Add to cart
23	PAD, FOAM, FUEL, TANK Part #: T2309519 Required per assembly: 1 ~~$12.51~~ $12.29 - + Add to cart
24	INSULATION, FUEL, TANK Part #: T2402407 Required per assembly: 1 ~~$13.50~~ $13.26 - + Add to cart
25	WASHER, 8.4, X, 24, X, 2 Part #: T3555033 Required per assembly: 1 ~~$2.87~~ $2.61 - + Add to cart
26	LABEL, FUEL, TANK, DIAG, UNFRD Part #: T3900194 Required per assembly: 1 ~~$5.98~~ $5.44 - + Add to cart
27	PIPE, FUEL, TANK, OVERFLOW Part #: T3620221 Required per assembly: 2 ~~$2.10~~ $1.91 - + Add to cart
28	FOAM, PAD, FUEL, TANK Part #: T3660106 Required per assembly: 4 ~~$3.41~~ $3.10 - + Add to cart
29	WASHER, RUBBER Part #: 3550063T0301 Required per assembly: 2 ~~$1.26~~ $1.15 - + Add to cart
30	CONNECTOR Part #: 2400043T0301 Required per assembly: 2 ~~$8.50~~ $7.73 - + Add to cart
