Cooling System replacement parts for Triumph Tiger 955i 198875 >

OEM Parts Triumph Tiger 955i 198875 > Cooling System

Cooling System Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	THERMOSTAT HOUSING ASSEMBLY Part #: T2100195 Required per assembly: 1 Not Available
2	SENSOR, ENGINE, COOLANT Part #: T2100808 Required per assembly: 1 $48.56 $47.72 - + Add to cart
3	THERMOSTAT Part #: T2102131 Required per assembly: 1 Not Available
4	O, RING, FAN, SWITCH Part #: T3600210 Required per assembly: 1 $1.42 $1.29 - + Add to cart
5	CLIP, FAN, SWITCH Part #: T2100272 Required per assembly: 1 Not Available
6	BOLT, HHF, M6, X, 25, S/S Part #: T3331102 Required per assembly: 2 Not Available
7	O, RING, THERMOSTAT, HOUSING Part #: T3600200 Required per assembly: 1 $3.76 $3.42 - + Add to cart
8	WASHER, CU, OD12.5, ID6.4, 0.8 Part #: T3550542 Required per assembly: 1 $1.00 $0.91 - + Add to cart
9	BOLT, HHF, LGHTD, M6X1.0X8, SLV Part #: T3205077 Required per assembly: 1 $4.99 $4.53 - + Add to cart
10	SCREW, TX, PAN/HD, M6X1.0X16, SLV Part #: T3330334 Required per assembly: 1 $2.68 $2.43 - + Add to cart
11	CAP RADIATOR Part #: T2100074 Required per assembly: 1 $23.93 $23.51 - + Add to cart
12	TANK, COOLANT, EXPANSION Part #: T2100470 Required per assembly: 1 Note: For expansion tank cover see Instruments Section Not Available
13	PIPE, COOLANT, O/D, 10X120 Part #: T3620318 Required per assembly: 1 Not Available
14	GROMMET-DIA8, DIA12.5, 3 Part #: T3450035 Required per assembly: 1 $2.13 $1.94 - + Add to cart
15	ELBOW, I.D., 8.0, TUBE Part #: T2100405 Required per assembly: 2 $1.42 $1.29 - + Add to cart
16	CLIP, HOSE, 11.0-12.5MM Part #: T3700440 Required per assembly: 1 $5.53 $5.03 - + Add to cart
17	PIPE, ASSEMBLY, EXPANSION, TANK Part #: T3620309 Required per assembly: 1 $9.92 $3.15 - + Add to cart
18	CLIP, 10.5, GER, OETIKER Part #: T3700077 Required per assembly: 1 $4.09 $3.72 - + Add to cart
19	GROMMET, DIA, 14.0, X, 4.0, PANEL Part #: T3021200 Required per assembly: 1 $3.22 $2.93 - + Add to cart
20	PIPE, COOLANT, NOM, O/D, 10X770 Part #: T3620345 Required per assembly: 1 $10.40 $10.22 - + Add to cart
21	SCREW, BUT/HD, M6X1.0X20, SLV Part #: T3330727 Required per assembly: 2 $3.46 $3.15 - + Add to cart
22	SCREW, PAN/HD, TX, M6X1.0X12, SLV Part #: T3331043 Required per assembly: 3 $0.98 $0.89 - + Add to cart
23	PUMP, WATER, ELLIPTICAL Part #: T2100680 Required per assembly: 1 $169.20 $166.29 - + Add to cart
24	BOLT, HHF, LGHTD, M6X1.0X65, SLV Part #: T3205075 Required per assembly: 2 $3.85 $3.50 - + Add to cart
25	O RING WATER PUMP Part #: 3600160T0301 Required per assembly: 1 $9.22 $8.38 - + Add to cart
27	KIT, WATER, ELBOW, BLACK Part #: T2107010 Required per assembly: 1 $80.32 $78.93 - + Add to cart
28	O, RING, 24X1.5 Part #: T3600190 Required per assembly: 1 $1.15 $1.05 - + Add to cart
29	BOLT, HHF, M6, X, 20, S/S Part #: T3331101 Required per assembly: 2 Not Available
30	BOTTOM, HOSE, COOLANT Part #: T2102393 Required per assembly: 1 $51.27 $50.38 - + Add to cart
31	HOSE, CLIP, 30-38 Part #: T3707590 Required per assembly: 4 $8.88 $8.72 - + Add to cart
32	KIT, WATER, ELBOW, BLACK Part #: T2107010 Required per assembly: 1 Note: 231370 > $80.32 $78.93 - + Add to cart
32	HOSE, WATER, PUMP, OUTLET Part #: T2100112 Required per assembly: 1 Note: > 231369 $61.50 $60.43 - + Add to cart
33	PIPE, COOLANT, CYL, HEAD/T'STAT Part #: T2102376 Required per assembly: 1 $23.58 $7.49 - + Add to cart
34	HOSE CLIP Part #: T2102242 Required per assembly: 2 $7.89 $7.17 - + Add to cart
35	PIPE, COOLANT, BYPASS Part #: T2102566 Required per assembly: 1 $20.60 $20.25 - + Add to cart
36	HOSE CLIP Part #: T2102242 Required per assembly: 1 $7.89 $7.17 - + Add to cart
37	PIPE, COOLANT, T/STAT, TO, RAD Part #: T2102386 Required per assembly: 1 $17.67 $5.61 - + Add to cart
38	RADIATOR, 232, X, 195, X, 23, CORE Part #: T2100431 Required per assembly: 1 Not Available
39	GROMMET; DIA 19.5 X 4.0 PANEL Part #: T3020300 Required per assembly: 4 $3.46 $3.15 - + Add to cart
40	SCREW, CAP/HD, M8X1.25X30, SLV Part #: T3050323 Required per assembly: 2 $4.83 $4.39 - + Add to cart
41	WASHER, 8.4, X, 24, X, 2 Part #: T3555033 Required per assembly: 2 $2.78 $2.53 - + Add to cart
42	FLANGED, SLEEVE, M8, PLATED Part #: T3010262 Required per assembly: 2 Not Available
43	BRACKET, RADIATOR, LH Part #: T2100441 Required per assembly: 1 Not Available
44	BRACKET, RADIATOR, RH Part #: T2100442 Required per assembly: 1 $8.54 $7.76 - + Add to cart
45	FAN ASSEMBLY DIA 190MM Part #: T2101241 Required per assembly: 1 $452.89 $445.09 - + Add to cart
48	GUIDE, HOSE Part #: T2101655 Required per assembly: 1 $6.68 $6.08 - + Add to cart
52	BOLT, FLANGE, M6X25 Part #: T3330804 Required per assembly: 1 $1.15 $1.05 - + Add to cart
53	BOLT, HHF, M6112, SLV Part #: T3203222 Required per assembly: 1 $1.75 $1.59 - + Add to cart
54	HOSE, CLIP, DIA, 20-32 Part #: T3707580 Required per assembly: 3 $9.78 $8.89 - + Add to cart
55	WASHER, 6.4, X, 14, X, 1.6 Part #: T3555004 Required per assembly: 3 $1.42 $1.29 - + Add to cart
56	CLIP, HOSE, DIA, 27-35 Part #: T3707585 Required per assembly: 2 $4.74 $4.31 - + Add to cart
57	COOLANT, OAT, PREMIX, D2053, 12, X, 1L Part #: T4007777 Required per assembly: Note: Not Illustrated Not Available
58	SEAL, WATER, PUMP Part #: T3600230 Required per assembly: 1 $5.90 $5.36 - + Add to cart
59	WASHER, CU, OD12.5, ID6.4, 0.8 Part #: T3550542 Required per assembly: 1 $1.00 $0.91 - + Add to cart
