Collapsible Stand/Side Stand replacement parts for 1982-1984 BMW R80RT (2477)

OEM Parts Bmw 1982-1984 Bmw R80RT (2477) Collapsible Stand/Side Stand

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

*FG 09/80
01	HEX NUT - M12X1,5 Part #: 07119922940 Required per assembly: 4 Note: NOT FOR VEHICLES WITH AUTHORITIES DENMARK 35 KW (CODE: V005A) AND OFFICIAL VEHICLE, DENMARK (CODE: X101A) AND AUTHORITIES FRANCE R65GS (CODE: X105A) Currently Not Available
02	WASHER - 13 Part #: 07119936442 Required per assembly: 4 Currently Not Available
03	SHACKLE Part #: 46521241597 Required per assembly: 1 Note: ONLY IN CONJUNCTION WITH Currently Not Available
04	PIN - 306MM Part #: 46711230762 Required per assembly: 1 Currently Not Available
05	BEARING BOLT Part #: 46511231233 Required per assembly: 1 Currently Not Available
06	SHACKLE - RIGHT Part #: 46521230409 Required per assembly: 1 Currently Not Available
07	TENSION SPRING Part #: 46521234514 Required per assembly: 2 Currently Not Available
08	HEX BOLT Part #: 07119904152 Required per assembly: 2 Currently Not Available
09	WAVE WASHER - B10-ZN Part #: 07119932112 Required per assembly: 2 Currently Not Available
10	SPACER Part #: 46521233087 Required per assembly: 2 Currently Not Available
11	CENTER STAND Part #: 46521234757 Required per assembly: 1 Currently Not Available
12	STOP BUFFER Part #: 46521231815 Required per assembly: 1 Currently Not Available
13	SIDE STAND Part #: 46531241598 Required per assembly: 1 Currently Not Available
14	TENSION SPRING (FROM 09/71) Part #: 46531231646 Required per assembly: 1 Currently Not Available
15	CAP Part #: 46521236522 Required per assembly: 1 Currently Not Available
16	SUPPORT SHACKLE Part #: 46531236859 Required per assembly: 1 Currently Not Available
17	RUBBER GROMMET Part #: 46521237786 Required per assembly: 1 Currently Not Available
18	RUBBER GROMMET Part #: 46521237787 Required per assembly: 1 Currently Not Available
--	SHACKLE Part #: 46521241597 Required per assembly: 1 Note: ONLY IN CONJUNCTION WITH Currently Not Available
