Oil Pump replacement parts for 1990 Honda Elite 250 (CH250)

OEM Parts Honda 1990 Honda Elite 250 (CH250) Oil Pump

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	PUMP, ASSEMBLY, OIL Part #: 15100-KAB-000 Required per assembly: 1 Not Available
002	BODY, OIL, PUMP Part #: 15101-KAB-000 Required per assembly: 1 Not Available
003	PLATE, OIL, PUMP Part #: 15116-KAB-000 Required per assembly: 1 Not Available
004	SHAFT, OIL, PUMP Part #: 15132-KAB-000 Required per assembly: 1 Not Available
005	SPROCKET Part #: 15133-KAB-000 Required per assembly: 1 Not Available
006	CHAIN, OIL, PUMP Part #: 15141-KAB-003 Required per assembly: 1 Not Available
007	ROTOR, OIL, PUMP Part #: 15331-KAB-000 Required per assembly: 1 $20.98 $16.98 - + Add to cart
008	ROTOR, OIL, PUMP Part #: 15332-921-003 Required per assembly: 1 Not Available
009	SEPARATOR, OIL Part #: 15711-KAB-000 Required per assembly: 1 Not Available
010	SEPARATOR, OIL Part #: 15712-KAB-000 Required per assembly: 1 Not Available
011	CIRCLIP (8MM) Part #: 90604-HA0-000 Required per assembly: 1 $2.92 $2.71 - + Add to cart
012	SCREW, PAN, (3X12) Part #: 93500-03012-0A Required per assembly: 1 $1.87 $1.73 - + Add to cart
013	PIN, C, DOWEL, (4X6.5) Part #: 94303-04065 Required per assembly: 1 $3.21 $2.99 - + Add to cart
014	BOLT, FLANGE, (6X14) Part #: 95701-06014-00 Required per assembly: 1 $2.04 $1.88 - + Add to cart
015	BOLT, FLANGE, (6X28) Part #: 96001-06028-00 Required per assembly: 4 $3.14 $2.91 - + Add to cart
