Fuel Tank 90-93 replacement parts for 1990 Honda VFR (VFR750F)

OEM Parts Honda 1990 Honda VFR (VFR750F) Fuel Tank 90-93

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

003	PUMP, ASSEMBLY, FUEL Part #: 16710-MT4-000 Aftermarket alternatives available Required per assembly: 1 Not Available
004	RUBBER FUEL PUMP Part #: 16711-KAF-305 Required per assembly: 1 $16.68 $13.92 - + Add to cart
005	STAY, FUEL, PUMP Part #: 16712-MT4-000 Required per assembly: 1 Not Available
006	FILTER, FUEL Part #: 16900-MG8-003 Required per assembly: 1 $27.24 $22.71 - + Add to cart
007	COCK, ASSEMBLY, FUEL Part #: 16950-MT4-P00 Required per assembly: 1 Not Available
008	TUBE, FUEL Part #: 16956-MT4-000 Required per assembly: 1 Not Available
009	TUBE, FUEL, PUMP Part #: 16957-ML7-000 Required per assembly: 1 Not Available
013	LEVER, PETCOCK Part #: 16963-MT4-670 Required per assembly: 1 Not Available
014	TRAY Part #: 17223-MN8-700 Required per assembly: 1 Not Available
015	STAY, TANK, DRAIN Part #: 17224-MT4-000 Required per assembly: 1 Not Available
015	STAY, TANK, DRAIN Part #: 17224-MT4-710 Required per assembly: 1 Not Available
016	TUBE Part #: 17225-MT4-000 Required per assembly: 1 Not Available
017	CLIP A Part #: 17316-MN1-670 Required per assembly: 3 $3.48 $3.16 - + Add to cart
018	RUBBER, TANK, TRIM Part #: 17518-MT4-300 Required per assembly: 1 Not Available
019	RUBBER, TANK, TRIM Part #: 17519-MT4-300 Required per assembly: 1 Not Available
020	TANK R157 (TYPE1) (ITALIAN RED) Part #: 17520-MT4-710ZD Required per assembly: 1 Not Available
020	TANK, SET, FUEL, R157, (TYPE1), (WL), (ITALIAN, RED) Part #: 17520-MT4-000ZH Required per assembly: 1 Not Available
021	PROTECTOR Part #: 17570-MT4-000 Required per assembly: 1 Not Available
022	CUSHION, FUEL, TANK Part #: 17611-ML7-000 Required per assembly: 2 $9.89 $8.50 - + Add to cart
023	RUB, FR., FUEL, TANK Part #: 17611-028-000 Required per assembly: 2 $5.46 $4.96 - + Add to cart
024	COLLAR Part #: 17612-MT4-000 Required per assembly: 1 Not Available
025	CAP, FUEL, FILLER Part #: 17620-MT4-040 Required per assembly: 1 Not Available
026	RUB, RR., TURN, SIGNAL Part #: 33647-443-740 Required per assembly: 2 Not Available
028	BOLT (6X12) (CT200) Part #: 90029-MT4-000 Required per assembly: 1 $3.39 - + Add to cart
029	BOLT, SOCKET, (4X6) Part #: 90073-MT4-000 Required per assembly: 4 $5.20 $4.73 - + Add to cart
030	BOLT, SOCKET, (4X21) Part #: 90074-MT4-000 Required per assembly: 3 $4.36 $3.96 - + Add to cart
031	BOLT, TANK, MOUNTING Part #: 90135-MT4-000 Required per assembly: 1 Not Available
032	WASHER (6X20) Part #: 90401-373-770 Required per assembly: 3 $5.52 - + Add to cart
033	CLAMP, CANISTER, HOSE Part #: 90682-SA0-671 Required per assembly: 1 $9.22 $8.63 - + Add to cart
034	O-RING (39.5X5) Part #: 91305-MC7-000 Required per assembly: 2 $4.64 $4.22 - + Add to cart
035	JOINT, TUBE Part #: 91463-KT0-680 Required per assembly: 1 $4.78 - + Add to cart
037	SCREW, PAN, (5X14) Part #: 93500-05014-0A Required per assembly: 8 $1.87 $1.70 - + Add to cart
038	NUT, FLANGE, (6MM) Part #: 94050-06000 Required per assembly: 2 $1.73 $1.59 - + Add to cart
039	NUT, FLANGE, (6MM) Part #: 94050-06080 Required per assembly: 7 Note: Sold in multiples of 5 only $1.73 $1.59 - + Add to cart
040	CLAMP, TUBE, (D13) Part #: 95002-41300-08 Required per assembly: 1 $4.29 $3.90 - + Add to cart
041	BOLT, FLANGE, (6X16) Part #: 96001-06016-00 Required per assembly: 4 $2.09 $1.93 - + Add to cart
