Cylinder Head replacement parts for 2002 Honda XR400R

OEM Parts Honda 2002 Honda XR400R Cylinder Head

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CYLINDER HEAD Part #: 12200-KCY-670 Required per assembly: 1 Not Available
002	GUIDE, VALVE Part #: 12231-KF0-305 Required per assembly: 4 $26.78 $22.33 - + Add to cart
003	GASKET, CYL, HD Part #: 12251-MBV-013 Required per assembly: 1 $29.55 $24.64 - + Add to cart
004	PLUNGER, CAM, SETTING Part #: 14125-KV2-940 Required per assembly: 1 $20.43 $17.05 - + Add to cart
005	SPRING, PLUNGER Part #: 14126-KV2-940 Required per assembly: 1 $5.26 $4.78 - + Add to cart
006	INSULATOR, CARB Part #: 16211-KCY-670 Required per assembly: 1 $87.53 $72.98 - + Add to cart
007	BAND, A, INSULATOR Part #: 16217-MW0-000 Required per assembly: 2 $12.97 $10.83 - + Add to cart
008	NUT, SQUARE, (5MM) Part #: 16222-MV4-300 Required per assembly: 1 $3.11 $2.90 - + Add to cart
009	BOLT, FLANGE, (6X25) Part #: 90004-GHB-670 Required per assembly: 3 $4.05 $3.68 - + Add to cart
010	NUT, CAP, (10MM) Part #: 90201-HA0-000 Required per assembly: 4 $7.44 $6.76 - + Add to cart
011	WASHER (10X25X4) Part #: 90453-KAS-900 Required per assembly: 1 $6.98 $6.16 - + Add to cart
012	WASHER, PLAIN, (10MM) Part #: 90453-KCY-670 Required per assembly: 4 $5.53 $5.03 - + Add to cart
013	O-RING (10X1.6) Part #: 91301-200-000 Required per assembly: 4 $4.32 $3.93 - + Add to cart
014	O-RING (45X2.5) Part #: 91303-397-000 Required per assembly: 1 $5.91 $5.37 - + Add to cart
015	BOLT, STUD, (8X22) Part #: 92900-08022-0B Required per assembly: 4 $3.10 $2.89 - + Add to cart
016	SCREW, PAN, (5X32) Part #: 93500-05032-0G Required per assembly: 1 $1.57 $1.45 - + Add to cart
017	PIN, DOWEL, (12X20) Part #: 94301-12200 Required per assembly: 1 $3.50 $3.18 - + Add to cart
018	S/PLG (X27GPR-U) Part #: 98061-59626 $4.29 - + Add to cart
018	SPARK PLUG (DPR9Z) Part #: 98061-59616 $4.13 - + Add to cart
018	S/PLG (X24GPR-U) Part #: 98061-58626 Required per assembly: 1 $4.29 - + Add to cart
018	SPARK PLUG (DPR8Z) Part #: 98061-58616 Required per assembly: 1 $4.13 - + Add to cart
