Carburetor - A02ca32aa/Ab replacement parts for 2002 Polaris Trail Boss (A02CA32AA/AB)

OEM Parts Polaris 2002 Polaris Trail Boss (A02CA32AA/AB) Carburetor - A02ca32aa/Ab

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	RING Part #: 3130507 Required per assembly: 1 Currently Not Available
2	E-RING Part #: 3130508 Required per assembly: 1 Note: Sold in multiples of 10 only Currently Not Available
3	JET, NEEDLE, (J8-5F14), (5F81-3) Part #: 3130730 Required per assembly: 1 Note: JET NEEDLE,(J8-5F14) Currently Not Available
4	RING Part #: 3130752 Required per assembly: 1 Currently Not Available
5	DIAPHRAGM ASM. Part #: 3130732 Required per assembly: 1 Currently Not Available
6	DESC NOT_AVAILABLE (AB)(AC) Part #: 3131329 Required per assembly: 1 Currently Not Available
7	SCREW Part #: 3130541 Required per assembly: 2 Currently Not Available
8	WASHER, SPRING Part #: 3130540 Required per assembly: 2 Currently Not Available
9	JET, BLOCK, ASM. Part #: 3131128 Required per assembly: 1 Currently Not Available
10	WASHER Part #: 3130014 Required per assembly: 1 $2.99 $1.73 - + Add to cart
11	JET, MAIN, #120 Part #: 3130557 Required per assembly: 1 Currently Not Available
12	SEAL Part #: 3130515 Required per assembly: 2 Currently Not Available
14	E-RING Part #: 3130518 Required per assembly: 1 Currently Not Available
15	CAP Part #: 3130519 Required per assembly: 1 Currently Not Available
16	PIN, FLOAT Part #: 3130361 Required per assembly: 1 Currently Not Available
17	PLATE Part #: 3130594 Required per assembly: 1 $24.99 $14.38 - + Add to cart
18	O-RING Part #: 3130532 Required per assembly: 1 Currently Not Available
19	SCREW Part #: 3130520 Required per assembly: 4 Currently Not Available
20	FLOATBODY ASM. Part #: 3130590 Required per assembly: 1 Currently Not Available
21	SCREW Part #: 3130521 Required per assembly: 1 Currently Not Available
22	FLOAT ASM. Part #: 3130529 Required per assembly: 1 Note: Asm., Float Currently Not Available
23	SCREW Part #: 3130591 Required per assembly: 2 Currently Not Available
24	VALVE, NEEDLE, (1.5), (1.5) Part #: 3131360 Required per assembly: 1 Note: VALVE,NEEDLE (1.5) Currently Not Available
25	O-RING Part #: 3130533 Required per assembly: 1 Currently Not Available
26	JET, PILOT(#50), (#50) Part #: 3131132 Required per assembly: 1 Currently Not Available
27	O-RING Part #: 3130522 Required per assembly: 1 Currently Not Available
28	WASHER Part #: 3130523 Required per assembly: 1 $3.99 $2.30 - + Add to cart
29	SPRING Part #: 3130525 Required per assembly: 1 Currently Not Available
30	ADJUSTER Part #: 3131131 Required per assembly: 1 Currently Not Available
31	SCREW, ADJ. Part #: 3130546 Required per assembly: 1 Currently Not Available
32	RING Part #: 3130545 Required per assembly: 1 Currently Not Available
33	SPRING Part #: 3130544 Required per assembly: 1 Currently Not Available
34	VALVE-THROTTLE(120) (120) Part #: 3131126 Required per assembly: 1 Currently Not Available
35	SPRING Part #: 3130589 Required per assembly: 1 Currently Not Available
36	RING Part #: 3130514 Required per assembly: 1 Note: Shaft Currently Not Available
37	SCREW Part #: 3130501 Required per assembly: 2 Currently Not Available
38	SHAFT, ASM, THROTTLE Part #: 3130513 Required per assembly: 1 Note: Asm., Throttle Shaft Currently Not Available
39	GUIDE, CABLE Part #: 3130543 Required per assembly: 1 Note: Guide, Cable Currently Not Available
40	SCREW Part #: 3130535 Required per assembly: 4 Currently Not Available
41	COVER Part #: 3130511 Required per assembly: 1 Currently Not Available
42	O-RING Part #: 3130512 Required per assembly: 1 Currently Not Available
43	HOLDER, GUIDE Part #: 3130199 Required per assembly: 1 Currently Not Available
44	SPRING Part #: 3130538 Required per assembly: 1 Currently Not Available
45	ASSEMBLY, PLUNGER, [AB] Part #: 3130539 Required per assembly: 1 Note: Asm., Plunger Currently Not Available
46	JET, AIR(#175), (#175) Part #: 3131133 Required per assembly: 1 Currently Not Available
47	ASSEMBLY, CARBURETOR Part #: 3131383 Required per assembly: 1 Note: CARBURETOR,ASM. (Incl. 1-38,43-51) Currently Not Available
48	SCREW & WASHER Part #: 3084205 Required per assembly: 2 $2.99 $1.73 - + Add to cart
49	SPRING Part #: 3131129 Required per assembly: 1 Currently Not Available
50	COVER, ASM. Part #: 3131127 Required per assembly: 1 Currently Not Available
51	SCREW Part #: 3130924 Required per assembly: 4 Currently Not Available
