Gearcase - A02ca32aa/Ab replacement parts for 2002 Polaris Trail Boss (A02CA32AA/AB)

OEM Parts Polaris 2002 Polaris Trail Boss (A02CA32AA/AB) Gearcase - A02ca32aa/Ab

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BEARING Part #: 3233018 Required per assembly: 2 Currently Not Available
2	RING, RETAINING Part #: 3233177 Required per assembly: 1 $5.99 $3.51 - + Add to cart
3	WASHER-THRUST Part #: 3233673 Required per assembly: 1 Note: Washer, Thrust Currently Not Available
4	SPROCKET-19T Part #: 3233674 Required per assembly: 1 Note: Sprocket, 19T Currently Not Available
5	WASHER Part #: 3233010 Required per assembly: 1 Currently Not Available
6	DOG, ENGAGEMENT, HIGH/REVERSE Part #: 3234237 Required per assembly: 1 Note: Dog, Engagement, High/Reverse Currently Not Available
7	SHAFT, INPUT, HYBRID Part #: 3233676 Required per assembly: 1 Note: Shaft, Input Currently Not Available
8	GEAR, 21T Part #: 3233677 Required per assembly: 1 Note: Gear, 21T Currently Not Available
9	BUSHING Part #: 3233678 Required per assembly: 1 Currently Not Available
10	WASHER Part #: 3233105 Required per assembly: 1 Currently Not Available
11	RING, SNAP Part #: 3233106 Required per assembly: 2 Currently Not Available
12	BEARING Part #: 3233019 Required per assembly: 2 Currently Not Available
13	NUT, FLEXLOC Part #: 3233961 Required per assembly: 1 Currently Not Available
14	BELLCRANK Part #: 3233547 Required per assembly: 1 Currently Not Available
15	RING, RETAINING Part #: 3233045 Required per assembly: 1 Currently Not Available
16	WASHER Part #: 3233040 Required per assembly: 1 Currently Not Available
17	O-RING Part #: 3233548 Required per assembly: 1 Currently Not Available
18	SHIFT-SHAFT Part #: 3233679 Required per assembly: 1 Note: Shaft, Shift Currently Not Available
19	SWITCH, 3, POSITION Part #: 3234002 Required per assembly: 1 Currently Not Available
20	SCREW Part #: 3233749 Required per assembly: 4 Note: Screw Tapping Currently Not Available
21	BULLET-SHIFTING Part #: 3233680 Required per assembly: 1 Note: Bullet, Shifting Currently Not Available
22	SPRING-COMPRESSION Part #: 3233681 Required per assembly: 1 Note: Spring, Compression Currently Not Available
23	WASHER Part #: 3233872 Required per assembly: 1 Currently Not Available
24	PLUG, DETENT Part #: 3233682 Required per assembly: 1 Note: Plug, Detent, Extension Currently Not Available
25	DIPSTICK Part #: 3233478 Required per assembly: 1 Currently Not Available
26	SEAL Part #: 3233788 Required per assembly: 2 Currently Not Available
27	TUBE, VENT Part #: 3233524 Required per assembly: 1 Note: Tube, Vent Currently Not Available
28	GEARCASE, RH Part #: 3234049 Required per assembly: 1 Currently Not Available
29	PIPE, KNOCK Part #: 3233529 Required per assembly: 2 Note: Pipe, Knock Sold in multiples of 5 only Currently Not Available
30	SHAFT-SHIFT Part #: 3233684 Required per assembly: 1 Note: Shaft, Shift Currently Not Available
31	SHIFT-FORK Part #: 3233685 Required per assembly: 1 Note: Fork, Shift Currently Not Available
32	GEARCASE, LH Part #: 3234048 Required per assembly: 1 Currently Not Available
33	DECAL-SWITCH Part #: 3233636 Required per assembly: 1 Currently Not Available
34	SCREW Part #: 3233252 Required per assembly: 9 Currently Not Available
35	PLUG, TORQUE, STOP Part #: 3233687 Required per assembly: 1 Note: Plug Currently Not Available
36	BUSHING, PIVOT Part #: 3233527 Required per assembly: 1 Currently Not Available
37	WASHER Part #: 3233035 Required per assembly: 1 Currently Not Available
38	CHAIN, SILENT, 60P Part #: 3233111 Required per assembly: 1 Note: CHAIN,SILENT,60P (11W) Currently Not Available
39	SUBASSEMBLY, CDS, 2X4, OUTPUT Part #: 3234266 Required per assembly: 1 Note: Sprocket, 51T and shaft (3234224) Currently Not Available
40	SHAFT, OUTPUT Part #: 3234224 Required per assembly: 1 Note: If replacing older p/n 3233689 from 1999 up to some 2004 and 2005 models, order p/n 3234266 which is packaged with this shaft and new version of the output sprocket. This shaft will not work with the older output sprocket (p/n 3233688) Currently Not Available
41	GEAR, 64T Part #: 3233690 Required per assembly: 1 Note: Gear, 64T Currently Not Available
42	ASM-GEARCASE 2X4 Part #: 1332730 Required per assembly: 1 Currently Not Available
