Footpeg System replacement parts for 2006-2012 BMW F800GS (K72)

OEM Parts Bmw 2006-2012 Bmw F800GS (K72) Footpeg System

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	FOOTREST, LEFT Part #: 46717701199 Required per assembly: 1 Currently Not Available
01	FOOTREST, RIGHT Part #: 46717701200 Required per assembly: 1 Currently Not Available
02	SPACER TUBE Part #: 46711242019 Required per assembly: 2 Note: NOT FOR VEHICLES WITH AUTHORITIES FRANCE R65GS (CODE: X105A) Currently Not Available
03	RETAINER SPRING Part #: 46717673821 Required per assembly: 2 Currently Not Available
04	WASHER - D=8MM Part #: 07119906667 Required per assembly: 4 Currently Not Available
05	FOOTREST PIN - D=8MM/L=41MM Part #: 46717717832 Required per assembly: 1 Note: RIGHT Currently Not Available
05	PIN - D=8MM/L=45MM Part #: 46717717830 Required per assembly: 1 Note: LEFT Currently Not Available
06	FOOTREST, REAR LEFT Part #: 46717705653 Required per assembly: 1 Currently Not Available
06	FOOTREST, REAR RIGHT Part #: 46717705654 Required per assembly: 1 Currently Not Available
07	FOOTREST RUBBER Part #: 46717664225 Required per assembly: 2 Currently Not Available
08	THRUST WASHER, LEFT Part #: 46717716151 Required per assembly: 1 Currently Not Available
08	THRUST WASHER, RIGHT Part #: 46717716152 Required per assembly: 1 Currently Not Available
09	SPLIT PIN - 2X16 Part #: 07119905230 Required per assembly: 4 Currently Not Available
10	PIN - D=8MM/L=36MM Part #: 46717717831 Required per assembly: 2 Note: FG R65/20 KW 643 11 35/ R65/35 KW 6 11 80 22/ R65 RT BEHÖRDE 646 07 42/ R80 644 62 35/ R80 RT 647 64 23 4 23/R65 USA 35 KW 612 85 16/ R80 USA 648 11 18/R80 RT USA 649 14 51* Currently Not Available
11	FILLISTER HEAD SCREW - M6X40 Part #: 63127699141 Required per assembly: 1 Currently Not Available
12	SHIM FOR TWO FOOT PEGS, FRONT RIGHT Part #: 46717708009 Required per assembly: 1 Currently Not Available
13	SHIM FOR FOOT PEG, FRONT RIGHT Part #: 46717708008 Required per assembly: 1 Currently Not Available
14	HEX NUT - M6-8-ZNS3 Part #: 07119905128 Required per assembly: 1 Currently Not Available
15	SET OF FOOT PEG RUBBER COVERS, FRONT Part #: 46717716028 Required per assembly: 1 Currently Not Available
