Front Shock - Z146t1eam/Eaw replacement parts for 2014 Polaris RZR XP 4 1000/PS

OEM Parts Polaris 2014 Polaris RZR XP 4 1000/PS Front Shock - Z146t1eam/Eaw

Front Shock - Z146T1EAM/EAW Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SHOCK, FRONT, RH, PASSENGER Part #: 7044117 Required per assembly: 1 Currently Not Available
1	SHOCK, FRONT, LH, DRIVER Part #: 7044116 Required per assembly: 1 Currently Not Available
2	BODY, RESERVOIR Part #: 1800575 Required per assembly: 1 Currently Not Available
3	CAP, END, RESERVOIR Part #: 1800574 Required per assembly: 1 Currently Not Available
4	O-RING Part #: 1800184 Required per assembly: 2 Currently Not Available
4	O-RING Part #: 1800184 Required per assembly: 2 Currently Not Available
5	VALVE Part #: 1800021 Required per assembly: 1 Currently Not Available
6	KNOB Part #: 1800418 Required per assembly: 1 Currently Not Available
7	RETAINER, SPRING Part #: 1501007 Required per assembly: 1 Currently Not Available
8	SEAL Part #: 1800596 Required per assembly: 1 Currently Not Available
9	SHAFT Part #: 1800597 Required per assembly: 1 Currently Not Available
10	PISTON, RESERVOIR Part #: 1800355 Required per assembly: 1 Currently Not Available
11	BAND-PISTON Part #: 1800185 Required per assembly: 2 Currently Not Available
12	O-RING-BLEED SCREW Part #: 1800210 Required per assembly: 1 Currently Not Available
13	SCREW, BLEED Part #: 1800043 Required per assembly: 1 Note: Sold in multiples of 10 only Currently Not Available
14	RING, SNAP Part #: 1800159 Required per assembly: 1 Currently Not Available
15	BALL, DETENT Part #: 1800127 Required per assembly: 4 Note: Sold in multiples of 10 only Currently Not Available
16	SPRING, DETENT Part #: 1800128 Required per assembly: 1 Note: Sold in multiples of 10 only Currently Not Available
17	SCREW Part #: 1800357 Required per assembly: 1 Currently Not Available
18	RING, SNAP Part #: 1800041 Required per assembly: 4 ~~$5.99~~ $3.51 - + Add to cart
18	RING, SNAP Part #: 1800041 Required per assembly: 4 ~~$5.99~~ $3.51 - + Add to cart
19	O-RING BODY Part #: 1800030 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
19	O-RING BODY Part #: 1800030 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
19	O-RING BODY Part #: 1800030 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
20	O-RING Part #: 1800037 Required per assembly: 1 Note: Sold in multiples of 10 only Currently Not Available
21	NUT, CRIMP Part #: 1800164 Required per assembly: 1 Currently Not Available
22	NEEDLE Part #: 1800300 Required per assembly: 1 Currently Not Available
23	SCREW, BLEED, W/O, RING Part #: 1800299 Required per assembly: 1 Currently Not Available
24	SEAL Part #: 1800323 Required per assembly: 1 Currently Not Available
25	PISTON Part #: 1800217 Required per assembly: 1 Currently Not Available
26	SCREW Part #: 1800219 Required per assembly: 2 Currently Not Available
26	SCREW Part #: 1800219 Required per assembly: 2 Currently Not Available
27	WASHER Part #: 1800050 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
27	WASHER Part #: 1800050 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
28	SPACER Part #: 1800598 Required per assembly: 1 Currently Not Available
29	PIGGY, BACK, LH Part #: 1800595 Required per assembly: 1 Currently Not Available
29	PIGGY, BACK, RH Part #: 1800594 Required per assembly: 1 Currently Not Available
30	WIPER D/TYPE Part #: 1800322 Required per assembly: 1 Currently Not Available
31	PLUG, PIPE Part #: 1800599 Required per assembly: 1 Currently Not Available
32	LOOP, SHAFT Part #: 1800600 Required per assembly: 1 Currently Not Available
33	BOLT, NEEDLE Part #: 1800601 Required per assembly: 1 Currently Not Available
34	BODY Part #: 1800602 Required per assembly: 1 Currently Not Available
35	BUMP STOP Part #: 1800603 Required per assembly: 1 Currently Not Available
36	STUD Part #: 1800352 Required per assembly: 1 Currently Not Available
37	O-RING Part #: 1800215 Required per assembly: 1 Currently Not Available
38	BEARING, SPHERICAL Part #: 1800616 Required per assembly: 2 Currently Not Available
38	BEARING, SPHERICAL Part #: 1800616 Required per assembly: 2 Currently Not Available
39	PISTON, NO, BLEEED Part #: 1800604 Required per assembly: 1 Currently Not Available
40	WASHER Part #: 1800187 Required per assembly: 1 Currently Not Available
41	SHAFT BUSHING Part #: 1800038 Required per assembly: 1 Currently Not Available
42	NUT, SPRING Part #: 1800514 Required per assembly: 1 Currently Not Available
