MAG COVER MOUNT - R17RVU99AV/BV (701111) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ASM, COVER-HVAC, MOUNT Part #: 3023041 Required per assembly: 1 Note: INCL. 2-4 Currently Not Available
2	BEARING-BALL 9X24X7 Part #: 3514717 Required per assembly: 1 Currently Not Available
3	ASM-COVER, HVAC, MOUNT Part #: 3023966 Required per assembly: 1 Currently Not Available
4	RING-SNAP DIN472 24X1.2MM Part #: 7710654 Required per assembly: 1 Currently Not Available
5	ADAPTER HUB Part #: 3022843 Required per assembly: 1 Note: INCL. 6 Currently Not Available
6	PIN, DOWEL Part #: 7663002 Required per assembly: 1 Currently Not Available
7	SENSOR-CRANK POSITION Part #: 2411719 Required per assembly: 1 Currently Not Available
8	SEAL-FLANGE LUBE VITON Part #: 3610176 Required per assembly: 1 Currently Not Available
9	PULLEY-6, RIB, 72.0MM, DRIVE Part #: 5142907 Required per assembly: 1 Currently Not Available
10	O-RING, -123 Part #: 5415584 Required per assembly: 1 Currently Not Available
11	GAKSET-COVER, MAG Part #: 5814160 Required per assembly: 1 Currently Not Available
12	SCREW Part #: 7518576 Required per assembly: 1 Currently Not Available
13	SCR-M6X20MM, HXSOC, FHCS Part #: 7518861 Required per assembly: 3 Currently Not Available
14	SCREW Part #: 7519297 Required per assembly: 13 Currently Not Available
15	BOLT-HXFLG, M12X1.25X90, 12.9 Part #: 7520410 Required per assembly: 1 Currently Not Available
16	WASHER-FRICTION, 28.0MM Part #: 7556915 Required per assembly: 1 Currently Not Available
17	K-HVAC TIMING WHEEL Part #: 2207164 Required per assembly: 1 Currently Not Available
