Cooling System replacement parts for 2020 Polaris Ranger 500 (R02)

OEM Parts Polaris 2020 Polaris Ranger 500 (R02) Cooling System

COOLING SYSTEM Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ASM-RADIATOR, CORE Part #: 1240956 Required per assembly: 1 Currently Not Available
2	VALVE-PLASTIC RAD/COOLER DRAIN Part #: 7052617 Required per assembly: 1 Currently Not Available
3	CAP-PRESSURE Part #: 1240899 Required per assembly: 1 Currently Not Available
4	HOSE-UPPER, RAD Part #: 5416386 Required per assembly: 1 Currently Not Available
5	HOSE-LOWER, RAD Part #: 5416387 Required per assembly: 1 Currently Not Available
6	HOSE-ENGINE, OUTLET, REAR Part #: 5416553 Required per assembly: 1 Currently Not Available
7	HOSE-LOWER, ENGINE, SHORT Part #: 5415054 Required per assembly: 1 Currently Not Available
8	TUBE-COOLANT, 1" Part #: 5141420 Required per assembly: 2 Currently Not Available
9	BRACKET-COOLANT TUBE Part #: 5451221 Required per assembly: 3 Currently Not Available
10	HOSE-BYPASS 1IN FORMED Part #: 5414162 Required per assembly: 1 Currently Not Available
11	CONNECTOR-TEE 1X1X0.5 Part #: 7052530 Required per assembly: 1 Currently Not Available
12	HOSE, BYPASS, 1/2, INCH, FORMED Part #: 5414590 Required per assembly: 1 Currently Not Available
13	CLAMP, SPRINGBAND Part #: 7080843 Required per assembly: 8 Note: Clamp, Spring Band Sold in multiples of 10 only Currently Not Available
14	CLAMP, HOSE Part #: 7080474 Required per assembly: 1 Note: Clamp, Hose $9.44 $6.81 - + Add to cart
15	SCREW Part #: 7512026 Required per assembly: 3 Note: Screw Currently Not Available
16	CLAMP, HOSE Part #: 7081192 Required per assembly: 2 Currently Not Available
17	BRKT-SURGE TANK Part #: 5254763 Required per assembly: 1 Currently Not Available
19	TANK, SURGE Part #: 5436936 Required per assembly: 1 Currently Not Available
20	FITTING, 90, DEGREE, ("J", MODEL, ONLY) Part #: 7052065 Required per assembly: 1 Note: FITTING,90 DEGREE $11.99 $6.90 - + Add to cart
21	FUEL, LINE, 1/4, ID(1525, CM.) Part #: 8450003-1525 Currently Not Available
22	CAP, PLUG9X, (GREEN), FLEX, TEMP Part #: 5433774 Required per assembly: 1 Note: INCL. 24 $4.79 $2.92 - + Add to cart
23	GASKET Part #: 5810279 Required per assembly: 1 $4.99 $2.92 - + Add to cart
24	CAP, OVERFLOW Part #: 5430743 Required per assembly: 1 Currently Not Available
25	SCREW Part #: 7512084 Required per assembly: 4 Note: Screw $2.99 $1.73 - + Add to cart
26	FAN-ASSEMBLY, SHROUD Part #: 2413196 Required per assembly: 1 Note: INCL. 27 $284.99 $162.49 - + Add to cart
28	BRKT-RAD, MNT, BLK Part #: 5260846-458 Required per assembly: 1 Currently Not Available
29	GROMMET-TANK FITTING Part #: 7052028 Required per assembly: 4 Note: Grommet Currently Not Available
30	SCREW Part #: 7519001 Required per assembly: 3 Currently Not Available
31	SCREW Part #: 7518529 Required per assembly: 3 $2.99 $1.73 - + Add to cart
32	SCREW Part #: 7516822 Required per assembly: 8 Currently Not Available
33	BRKT-COOLANT, TUBE, MNT, BLK Part #: 5265091-329 Required per assembly: 1 Currently Not Available
