Battery replacement parts for 2021 Polaris Ranger 1000 FULL SIZE (R02)

OEM Parts Polaris 2021 Polaris Ranger 1000 FULL SIZE (R02) Battery

BATTERY Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BLOCK-TERMINAL, 3, POS Part #: 4018346 Required per assembly: 1 Currently Not Available
2	CABLE-START TO SOLENOID Part #: 4017368 Required per assembly: 1 Currently Not Available
3	CABLE-BATTERY TO SOLENOID Part #: 4017369 Required per assembly: 1 Currently Not Available
4	CABLE-BAT TO GND Part #: 4080965 Required per assembly: 1 Currently Not Available
5	STUD Part #: 7519333 Required per assembly: 1 Currently Not Available
6	NUT Part #: 7547274 Required per assembly: 1 Note: Nut, Flange Currently Not Available
7	CLIP-ROUTING Part #: 7081496 Required per assembly: 2 Currently Not Available
8	SOLENOID-STARTER, SEALED Part #: 4014655 Required per assembly: 1 Currently Not Available
9	BATTERY Part #: 4014132-P Required per assembly: 1 Currently Not Available
10	BRACKET, BATTERY, STRAP Part #: 5257827 Required per assembly: 1 Currently Not Available
11	SCREW Part #: 7518529 Required per assembly: 1 ~~$2.99~~ $1.73 - + Add to cart
12	DECAL-BATTERY DIESEL POLARIS Part #: 7177052 Required per assembly: 1 ~~$3.52~~ $2.75 - + Add to cart
13	NUT, FLANGE Part #: 7547270 Required per assembly: 2 Note: Nut, Hex Currently Not Available
14	SCR-HXFL-M8X1.25X20 TAP ZY3 Part #: 7520764 Required per assembly: 1 Currently Not Available
15	NUT, METRIC Part #: 7546703 Required per assembly: 2 ~~$1.99~~ $1.15 - + Add to cart
16	SCREW Part #: 7519731 Required per assembly: 4 Currently Not Available
