Handle Unit, Right replacement parts for 1981-1985 BMW R65LS (248)

OEM Parts Bmw 1981-1985 Bmw R65LS (248) Handle Unit, Right

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	HANDLE UNIT, RIGHT - D=15MM (FROM 09/81) Part #: 32722302368 Required per assembly: 1 Currently Not Available
02	HAND LEVER RIGHT Part #: 32721242555 Required per assembly: 1 Currently Not Available
03	NUT Part #: 32721238382 Required per assembly: 1 Currently Not Available
04	WAVE WASHER Part #: 32721230871 Required per assembly: 1 Currently Not Available
05	SCREW Part #: 32721238380 Required per assembly: 1 Currently Not Available
06	THROTTLE TWIST GRIP Part #: 32721454129 Required per assembly: 1 Currently Not Available
07	HANDLE RIGHT Part #: 32721237812 Required per assembly: 1 Currently Not Available
08	SCREW Part #: 32721454245 Required per assembly: 1 Currently Not Available
09	COVER (FROM 09/80) Part #: 32721457050 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
10	CAM DISC - L=33MM (FROM 09/80) Part #: 32721457080 Required per assembly: 1 Note: ONLY IN CONJUNCTION WITH Currently Not Available
11	HOUSING (FROM 09/80) Part #: 32721242563 Required per assembly: 1 Currently Not Available
12	PISTON - D=12MM (FROM 09/81) Part #: 32722302371 Required per assembly: 1 Note: FOR VEHICLES WITH AUTHORITIES DENMARK 35 KW (CODE: V005A) OR OFFICIAL VEHICLE, DENMARK (CODE: X101A) OR AUTHORITIES FRANCE R65GS (CODE: X105A) Currently Not Available
12	PISTON - D=15MM (FROM 09/81) Part #: 32722302372 Required per assembly: 1 Currently Not Available
13	LOCK RING - 17X1 Part #: 07119934620 Required per assembly: 1 Currently Not Available
14	EXPANSION TANK (FROM 09/80) Part #: 32721242623 Required per assembly: 1 Currently Not Available
15	RUBBER BOOT (FROM 09/80) Part #: 32721242547 Required per assembly: 1 Currently Not Available
16	COVER (FROM 09/80) Part #: 32721454945 Required per assembly: 1 Currently Not Available
17	COUNTERSUNK HEAD SCREW - M5X55 (FROM 09/80) Part #: 32721242544 Required per assembly: 3 Currently Not Available
18	FILLISTER-HEAD SCREW - M5X20-8.8 ZNS Part #: 07119920057 Required per assembly: 2 Note: NOT FOR VEHICLES WITH AUTHORITIES DENMARK 35 KW (CODE: V005A) AND OFFICIAL VEHICLE, DENMARK (CODE: X101A) AND AUTHORITIES FRANCE R65GS (CODE: X105A) Currently Not Available
19	SPRING WASHER - B5 Part #: 07119933060 Required per assembly: 2 $0.58 $0.49 - + Add to cart
20	PLUG (FROM 09/80) Part #: 32721242552 Required per assembly: 1 Currently Not Available
21	O-RING Part #: 32721242624 Required per assembly: 1 Currently Not Available
22	SCREW Part #: 32721242625 Required per assembly: 1 Currently Not Available
23	CYLINDER WITH PISTON - D=15MM (FROM 09/81) Part #: 32722302370 Required per assembly: 1 Currently Not Available
24	STOP LIGHT SWITCH (FROM 09/80) Part #: 61311244070 Required per assembly: 1 Currently Not Available
25	PLUG Part #: 32721236605 Required per assembly: 1 Currently Not Available
26	LOCKING BOLT (FROM 09/80) Part #: 32721230874 Required per assembly: 1 Currently Not Available
27	CUP (FROM 09/80) Part #: 32731242495 Required per assembly: 1 Currently Not Available
29	CAP (FROM 09/80) Part #: 61311244071 Required per assembly: 1 Currently Not Available
--	COVER (FROM 09/80) Part #: 32721457050 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
--	CAM DISC - L=33MM (FROM 09/80) Part #: 32721457080 Required per assembly: 1 Note: ONLY IN CONJUNCTION WITH Currently Not Available
