Fuel Tank replacement parts for 2002 Yamaha Road Star Warrior CA (XV17PCPC)

OEM Parts Yamaha 2002 Yamaha Road Star Warrior CA (XV17PCPC) Fuel Tank

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	FUEL TANK COMP Part #: 5PX-Y2410-10-03 Required per assembly: 1 Note: VRC7(VIVID RED COCKTAIL 7) Not Available
001	FUEL TANK COMP Part #: 5PX-Y2410-10-01 Required per assembly: 1 Note: DVMA(DARK VIOLET METALLIC A) Not Available
001	FUEL TANK COMP. Part #: 5PX-Y2410-10-02 Required per assembly: 1 Note: DNMA(DARK GRAY METALLIC A) Not Available
002	EMBLEM SET Part #: 5PX-24150-00-00 Required per assembly: 1 Note: FOR DNMA(DARK GRAY METALLIC A) Not Available
002	EMBLEM SET Part #: 5PX-24150-20-00 Required per assembly: 1 Note: FOR VRC7(VIVID RED COCKTAIL 7) Not Available
002	EMBLEM SET Part #: 5PX-24150-10-00 Required per assembly: 1 Note: FOR DVMA(DARK VIOLET METALLIC A) Not Available
003	CAP ASSEMBLY Part #: 5PX-24602-02-00 Required per assembly: 1 $325.99 $268.33 - + Add to cart
004	BOLT Part #: 91380-05012-00 Required per assembly: 1 $1.39 $1.15 - + Add to cart
005	NUT, FLANGE, 3GM, (BLACK) Part #: 95707-05500-00 Required per assembly: 2 $9.49 $6.06 - + Add to cart
006	BOLT, HEXAGON, SOCKET, HEAD, (1FM) Part #: 90110-05112-00 Required per assembly: 3 $10.49 $7.35 - + Add to cart
007	BOLT, HEXAGON, SOCKET, HEAD Part #: 91317-05010-00 Required per assembly: 1 $2.75 $1.65 - + Add to cart
008	FILTER ASSEMBLY Part #: 5PX-24560-00-00 Required per assembly: 1 $55.99 $47.22 - + Add to cart
009	O-RING Part #: 4X8-24512-00-00 Required per assembly: 1 $8.99 $6.58 - + Add to cart
010	WASHER, PLATE(3MB) Part #: 90202-05187-00 Required per assembly: 2 $1.70 $1.30 - + Add to cart
011	BOLT, FLANGE Part #: 95027-06014-00 Required per assembly: 2 $0.95 $0.73 - + Add to cart
012	DAMPER, LOCATING, 2 Part #: 5PX-24182-01-00 Required per assembly: 1 Not Available
013	BRACKET, TANK, FITTING Part #: 5PX-2413Y-01-00 Required per assembly: 1 $50.99 $39.87 - + Add to cart
014	DAMPER, LOCATING, 3 Part #: 5PX-24183-01-00 Required per assembly: 1 Not Available
015	WASHER, SPECIAL Part #: 5PX-24186-01-00 Required per assembly: 1 $17.98 $13.50 - + Add to cart
016	BOLT, BUTTON, HEAD Part #: 92017-08012-00 Required per assembly: 1 $9.49 $6.06 - + Add to cart
017	DAMPER, LOCATING, 1 Part #: 4H7-24181-00-00 Required per assembly: 2 $7.49 $5.38 - + Add to cart
018	DAMPER, PLATE, 3 Part #: 5PX-2414K-00-00 Required per assembly: 1 $12.99 $10.27 - + Add to cart
019	DAMPER, PLATE, 1 Part #: 5PX-2414H-00-00 Required per assembly: 1 $8.49 $6.47 - + Add to cart
020	DAMPER, PLATE, 2 Part #: 5PX-2414J-00-00 Required per assembly: 1 $8.49 $6.47 - + Add to cart
021	MOLD, FUEL, TANK Part #: 1HX-24188-01-00 Required per assembly: 1 $21.98 $17.51 - + Add to cart
022	BOLT 1 Part #: 5PX-24176-01-00 Required per assembly: 2 $19.98 $16.27 - + Add to cart
023	NUT, CROWN Part #: 90176-06055-00 Required per assembly: 4 $5.59 $3.93 - + Add to cart
024	PIPE, FUEL, 1 Part #: 5PX-24311-00-00 Required per assembly: 1 $19.98 $15.98 - + Add to cart
025	SPRING Part #: 5PX-24393-00-00 Required per assembly: 1 Not Available
026	CLIP Part #: 5PX-2411M-00-00 Required per assembly: 2 $11.99 $8.69 - + Add to cart
027	FUEL PIPE JOINT COMP 2 Part #: 5PX-24305-00-00 Required per assembly: 1 $102.98 $87.45 - + Add to cart
028	FUEL PIPE JOINT COMP 1 Part #: 5PX-24304-01-00 Required per assembly: 1 $146.99 $127.05 - + Add to cart
029	BOLT Part #: 90101-05396-00 Required per assembly: 1 $8.49 $5.79 - + Add to cart
030	WASHER, PLATE Part #: 92907-05600-00 Required per assembly: 4 $1.00 $0.77 - + Add to cart
031	PIPE 2 Part #: 5PX-24312-00-00 Required per assembly: 1 $71.98 $59.24 - + Add to cart
032	CLIP Part #: 5PX-2411M-00-00 Required per assembly: 2 $11.99 $8.69 - + Add to cart
033	CLAMP Part #: 90464-16006-00 Required per assembly: 2 $10.49 $8.24 - + Add to cart
034	PIPE 3 Part #: 5PX-24313-00-00 Required per assembly: 1 $37.99 $30.18 - + Add to cart
035	CLIP Part #: 5PX-2411M-00-00 Required per assembly: 2 $11.99 $8.69 - + Add to cart
036	FUEL PIPE JOINT COMP 2 Part #: 5PX-24305-00-00 Required per assembly: 1 $102.98 $87.45 - + Add to cart
037	FUEL PIPE JOINT COMP 1 Part #: 5PX-24304-11-00 Required per assembly: 1 $147.99 $127.73 - + Add to cart
038	BOLT Part #: 90101-05396-00 Required per assembly: 1 $8.49 $5.79 - + Add to cart
039	WASHER, PLATE Part #: 92907-05600-00 Required per assembly: 4 $1.00 $0.77 - + Add to cart
040	BRACKET, CANISTOR Part #: 5PX-2419F-00-00 Required per assembly: 1 $23.98 $19.32 - + Add to cart
041	BOLT, HEXAGON Part #: 97017-05012-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
042	WASHER, PLATE Part #: 92907-05600-00 Required per assembly: 4 $1.00 $0.77 - + Add to cart
043	PIPE 4 Part #: 5PX-24314-00-00 Required per assembly: 1 Not Available
044	CLIP Part #: 5PX-2411M-00-00 Required per assembly: 2 $11.99 $8.69 - + Add to cart
045	TANK, FUEL Part #: 5PX-24280-00-00 Required per assembly: 1 Not Available
046	GROMMET Part #: 90480-18003-00 Required per assembly: 3 Not Available
047	COLLAR Part #: 90387-0614M-00 Required per assembly: 6 $12.49 $8.10 - + Add to cart
048	BOLT, FLANGE Part #: 95817-06030-00 Required per assembly: 2 $4.65 $3.84 - + Add to cart
049	BRACKET, FUEL, PUMP Part #: 5PX-24491-00-00 Required per assembly: 1 $83.98 $75.90 - + Add to cart
050	BOLT, HEX., SOCKET, BUTTON Part #: 90111-05026-00 Required per assembly: 4 $9.49 $6.67 - + Add to cart
051	O-RING Part #: 5PX-24486-00-00 Required per assembly: 1 $14.49 $11.64 - + Add to cart
052	PLATE, DAMPER Part #: 5PX-24145-00-00 Required per assembly: 1 $34.99 $25.24 - + Add to cart
053	PIPE, OVERFLOW Part #: 5PX-24318-01-00 Required per assembly: 1 $38.99 $29.48 - + Add to cart
054	CLIP Part #: 90467-090A2-00 Required per assembly: 2 $4.75 $2.45 - + Add to cart
055	WAY 3 Part #: 90413-07007-00 Required per assembly: 1 $10.49 $8.12 - + Add to cart
056	PIPE 10 Part #: 5PX-24321-01-00 Required per assembly: 1 Not Available
057	CLIP Part #: 90467-090A2-00 Required per assembly: 2 $4.75 $2.45 - + Add to cart
058	PIPE 11 Part #: 5PX-24322-20-00 Required per assembly: 1 Not Available
059	CLIP Part #: 90467-090A2-00 Required per assembly: 2 $4.75 $2.45 - + Add to cart
060	CLIP Part #: 90467-09001-00 Required per assembly: 1 $2.60 $1.71 - + Add to cart
061	ROLL OVER VALVE ASSEMBLY Part #: 5PX-24180-00-00 Required per assembly: 1 $62.99 $49.99 - + Add to cart
062	CLAMP 2 Part #: 5PX-24136-00-00 Required per assembly: 1 $5.49 $4.69 - + Add to cart
063	NUT, CROWN Part #: 90176-05054-00 Required per assembly: 1 $8.49 $5.67 - + Add to cart
064	PIPE 12 Part #: 5PX-24323-01-00 Required per assembly: 1 $61.99 $54.11 - + Add to cart
065	CLIP Part #: 90467-09001-00 Required per assembly: 1 $2.60 $1.71 - + Add to cart
066	PIPE 11 Part #: 5PX-24322-20-00 Required per assembly: 1 Not Available
067	CLIP Part #: 90467-090A2-00 Required per assembly: 2 $4.75 $2.45 - + Add to cart
068	CLIP Part #: 90467-09001-00 Required per assembly: 1 $2.60 $1.71 - + Add to cart
069	ROLL OVER VALVE ASSEMBLY Part #: 5PX-24180-00-00 Required per assembly: 1 $62.99 $49.99 - + Add to cart
070	CLAMP 2 Part #: 5PX-24136-00-00 Required per assembly: 1 $5.49 $4.69 - + Add to cart
071	NUT, CROWN Part #: 90176-05054-00 Required per assembly: 1 $8.49 $5.67 - + Add to cart
072	PIPE 12 Part #: 5PX-24323-20-00 Required per assembly: 1 $49.99 $43.06 - + Add to cart
073	CLIP Part #: 90467-09001-00 Required per assembly: 1 $2.60 $1.71 - + Add to cart
074	CLIP Part #: 90467-090A2-00 Required per assembly: 2 $4.75 $2.45 - + Add to cart
075	CANISTER ASSEMBLY Part #: 5PX-24170-00-00 Required per assembly: 1 $289.99 $282.53 - + Add to cart
076	BOLT, HEX, SOCKET, BUTTON Part #: 92017-06016-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
077	PIPE 14 Part #: 5PX-24325-00-00 Required per assembly: 1 Not Available
079	CLIP Part #: 90467-090A2-00 Required per assembly: 2 $4.75 $2.45 - + Add to cart
080	STAY Part #: 5PX-24364-01-00 Required per assembly: 1 Note: FROM VP19E-000666~ AND VP19Y-000122~ $40.99 $35.64 - + Add to cart
081	CLAMP Part #: 90464-25267-00 Required per assembly: 2 $7.49 $4.68 - + Add to cart
082	CLAMP (6M7) Part #: 90464-10M32-00 Required per assembly: 1 $4.59 $4.46 - + Add to cart
083	STAY, SIDE, COVER, 1 Part #: 5PX-2172E-00-00 Required per assembly: 1 $38.99 $33.40 - + Add to cart
084	BOLT, BUTTON, HEAD Part #: 92017-08025-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
085	FUEL PUMP COMP. Part #: 5PX-13907-01-00 Required per assembly: 1 $974.99 $882.93 - + Add to cart
