Taillight replacement parts for 2002 Yamaha Road Star Warrior CA (XV17PCPC)

OEM Parts Yamaha 2002 Yamaha Road Star Warrior CA (XV17PCPC) Taillight

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	BASE, TAILLIGHT Part #: 5PX-84711-00-00 Required per assembly: 1 $58.99 $58.51 - + Add to cart
002	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 $5.59 $4.65 - + Add to cart
003	TAILLIGHT UNIT ASSEMBLY Part #: 5PX-84710-00-00 Required per assembly: 1 $221.99 $200.39 - + Add to cart
004	DAMPER Part #: 5PX-84553-00-00 Required per assembly: 3 $3.95 $3.30 - + Add to cart
005	COLLAR Part #: 5PX-84557-00-00 Required per assembly: 3 $4.04 $3.39 - + Add to cart
006	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 2 $4.62 $3.18 - + Add to cart
007	COVER, TAILLIGHT Part #: 5PX-84716-00-00 Required per assembly: 1 Not Available
008	LICENCE LIGHT UNIT ASSEMBLY Part #: 5PX-84745-00-00 Required per assembly: 1 $196.99 $171.48 - + Add to cart
009	BULB (12V-2CP) Part #: 5PX-84744-00-00 Required per assembly: 2 $4.59 $3.39 - + Add to cart
010	BODY, LICENCE, LIGHT Part #: 5PX-84749-00-00 Required per assembly: 1 $90.98 $76.11 - + Add to cart
014	NUT, SPECIAL Part #: 5PX-84748-00-00 Required per assembly: 2 $3.64 $3.02 - + Add to cart
015	SEAT, BASE Part #: 5PX-84742-00-00 Required per assembly: 1 $8.49 $6.74 - + Add to cart
016	DAMPER Part #: 3F9-84553-00-00 Required per assembly: 2 $24.98 $19.64 - + Add to cart
017	COLLAR Part #: 90387-06241-00 Required per assembly: 2 $9.49 $6.06 - + Add to cart
018	WASHER, PLATE Part #: 90201-05033-00 Required per assembly: 2 $11.49 $6.97 - + Add to cart
019	NUT, FLANGE, 3GM, (BLACK) Part #: 95707-05500-00 Required per assembly: 2 $9.49 $6.06 - + Add to cart
020	REAR FLASHER LIGHT ASSEMBLY 1 Part #: 5PX-83330-01-00 Required per assembly: 1 $112.98 $97.52 - + Add to cart
021	BULB (12V-23/8W) Part #: 137-84714-61-XX Required per assembly: 1 Note: Sold in multiples of 10 only Not Available
023	GASKET, FLASHER, LENS Part #: 5PX-83313-00-00 Required per assembly: 1 $7.49 $6.27 - + Add to cart
024	SCREW, SPECIAL Part #: 5PX-83358-00-00 Required per assembly: 2 Not Available
025	WASHER Part #: 5PX-83348-00-00 Required per assembly: 2 $7.49 $6.27 - + Add to cart
026	REAR FLASHER LIGHT ASSEMBLY 2 Part #: 5PX-83340-01-00 Required per assembly: 1 $112.98 $97.52 - + Add to cart
027	BULB (12V-23/8W) Part #: 137-84714-61-XX Required per assembly: 1 Note: Sold in multiples of 10 only Not Available
028	LENS, FLASHER, 2 Part #: 5PX-83342-00-00 Required per assembly: 1 Not Available
029	GASKET, FLASHER, LENS Part #: 5PX-83313-00-00 Required per assembly: 1 $7.49 $6.27 - + Add to cart
030	SCREW, SPECIAL Part #: 5PX-83358-00-00 Required per assembly: 2 Not Available
031	WASHER Part #: 5PX-83348-00-00 Required per assembly: 2 $7.49 $6.27 - + Add to cart
032	NUT, SPEC'L, SHAPE Part #: 90179-12657-00 Required per assembly: 1 $6.49 $5.22 - + Add to cart
033	BRACKET, LICENSE Part #: 5PX-84751-00-00 Required per assembly: 1 $58.99 $46.19 - + Add to cart
034	BOLT, FLANGE Part #: 95027-06014-00 Required per assembly: 2 $0.95 $0.73 - + Add to cart
035	WASHER, PLATE Part #: 90201-06020-00 Required per assembly: 1 $10.49 $6.17 - + Add to cart
036	NUT, SELF-LOCKING Part #: 95617-06100-00 Required per assembly: 2 $2.89 $2.28 - + Add to cart
037	REFLECTOR, REAR, 1 Part #: 449-85131-02-00 Required per assembly: 2 $33.99 $25.30 - + Add to cart
038	NUT, U Part #: 5PX-84548-00-00 Required per assembly: 2 $4.45 $3.70 - + Add to cart
039	WASHER, PLATE Part #: 5PX-84754-00-00 Required per assembly: 2 $3.75 $3.08 - + Add to cart
040	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 2 $8.49 $5.58 - + Add to cart
041	CORD, TAILLIGHT Part #: 5PX-84717-00-00 Required per assembly: 1 Not Available
042	DAMPER Part #: 5PX-84753-00-00 Required per assembly: 4 $4.45 $3.70 - + Add to cart
043	COLLAR Part #: 90387-06648-00 Required per assembly: 2 Note: (USA) $9.49 $6.97 - + Add to cart
044	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
045	NUT, U, FLANGE Part #: 95604-06200-00 Required per assembly: 2 $2.95 $2.31 - + Add to cart
