Variotop Case replacement parts for 2008-2012 BMW R1200GS 10+ (K25)

OEM Parts Bmw 2008-2012 Bmw R1200GS 10+ (K25) Variotop Case

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	VARIOTOP CASE Part #: 77438527849 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
01	TOP CASE WITHOUT CYLINDER, VARIABLE Part #: 71608527849 Required per assembly: 1 Not Available
02	LOCK CYLINDER WITH VIN CODE Part #: 51257681199 Required per assembly: 1 Note: ONLY FOR REPAIR AT THE DEALERS FOR TANK CAP Not Available
03	LOCK CYLINDER WITH KEY Part #: 51257688568 Required per assembly: 1 Note: ONLY APPL.TO UNIFORM LOCK.SYST.,BOXES Currently Not Available
04	CASE LOCK CYLINDER/TOP CASE W KEY CODE Part #: 51257692176 Required per assembly: 1 Not Available
05	IGNITION KEY (CODE) Part #: 51257681202 Required per assembly: 1 Not Available
05	GENERAL KEY (BLANK) WITHOUT TRANSPONDER Part #: 51257688674 Required per assembly: 1 Currently Not Available
05	GENERAL KEY (BLANK) WITHOUT TRANSPONDER Part #: 51257688674 Required per assembly: 1 Currently Not Available
06	SET: SET BACKREST CUSHION TOP CASE Part #: 71607688877 Required per assembly: 1 Currently Not Available
07	SET: REPAIR KIT F TOPCASE LOCKING MECHANISM Part #: 71607697712 Required per assembly: 1 Not Available
07	SET: REPAIR KIT F TOPCASE LOCKING MECHANISM Part #: 71607707728 Required per assembly: 1 Currently Not Available
07	SET: SET, TOPCASE ENDURO SECURING EQUIPMENT Part #: 71607697847 Required per assembly: 1 Currently Not Available
08	SET: RETROFIT KIT (TO 09/06) Part #: 71607707246 Required per assembly: 1 Currently Not Available
09	INSTRUCTION NOTICE, SAFETY INSTRUCTIONS Part #: 51147716218 Required per assembly: 1 Not Available
--	SET: SET,SUPPORTING PLATES F TOPCASE Part #: 71607707239 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
--	ADAPTER PLATE Part #: 71607707240 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
--	LOCK CYLINDER WITH KEY Part #: 51257688568 Required per assembly: 1 Note: ONLY APPL.TO UNIFORM LOCK.SYST.,BOXES Currently Not Available
--	SET: SET OF LOCKS CASE/TOP CASE Part #: 51257688567 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
