Windshield replacement parts for 2008-2012 BMW R1200GS 10+ (K25)

OEM Parts Bmw 2008-2012 Bmw R1200GS 10+ (K25) Windshield

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	WINDSHIELD Part #: 46637668783 Required per assembly: 1 Currently Not Available
02	CLAMPING BOLT Part #: 46637694397 Required per assembly: 2 Not Available
03	EXTERIOR BUSH Part #: 46637676997 Required per assembly: 2 Not Available
04	BUSHING, INSIDE - M6 Part #: 46637676996 Required per assembly: 2 Not Available
05	LOCKING DISC LEFT Part #: 46637707221 Required per assembly: 1 Currently Not Available
05	LOCKING DISC RIGHT Part #: 46637707222 Required per assembly: 1 Currently Not Available
06	COVERING LEFT Part #: 46637673913 Required per assembly: 1 Currently Not Available
06	COVERING RIGHT Part #: 46637673914 Required per assembly: 1 Currently Not Available
07	HEX NUT - M6 Part #: 07129904882 Required per assembly: 2 Note: FOR VEHICLES WITH HP COMPONENTS (CODE: X189A) Currently Not Available
08	WINDSHIELD BRACKET, RIGHT Part #: 46637694710 Required per assembly: 1 Currently Not Available
08	WINDSHIELD BRACKET, LEFT Part #: 46637694709 Required per assembly: 1 Note: IMPORTANT! SEE TORQUE FIGURES! 2,5 NM Currently Not Available
09	FILLISTER HEAD SCREW - M5X16MK Part #: 06327657949 Required per assembly: 2 Note: ONLY IN CONJUNCTION WITH Currently Not Available
10	GROMMET Part #: 46638555101 Required per assembly: 2 Note: ONLY APPLIES TO Currently Not Available
11	FLANGE SLEEVE, STEEL Part #: 46637724481 Required per assembly: 2 Currently Not Available
12	HEX NUT - M5 SW Part #: 07129900645 Required per assembly: 2 Currently Not Available
13	LABEL Part #: 71212346071 Required per assembly: 1 Not Available
14	FILLISTER HEAD SCREW - M5X16MK Part #: 06327657949 Required per assembly: 2 Note: ONLY IN CONJUNCTION WITH Currently Not Available
15	NUT - M5 Part #: 46637658638 Required per assembly: 4 Note: ONLY IN CONJUNCTION WITH Currently Not Available
16	FLANGED CAP SCREW - 5X16 Part #: 46637686286 Required per assembly: 4 Currently Not Available
17	SUPPORT F HEADLIGHT Part #: 46637702712 Required per assembly: 1 Currently Not Available
18	O-RING - 6X1,8 Part #: 07119906348 Required per assembly: 2 Currently Not Available
