Case, Lower Part replacement parts for 2008-2012 BMW R1200RT 10+ (K26)

OEM Parts Bmw 2008-2012 Bmw R1200RT 10+ (K26) Case, Lower Part

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	CASE BOTTOM, LEFT Part #: 46547714437 Required per assembly: 1 Currently Not Available
01	CASE BOTTOM, RIGHT Part #: 46547714438 Required per assembly: 1 Note: ONLY APPLIES TO Currently Not Available
02	LINKAGE FOR CARRIER HANDLE Part #: 46547694161 Required per assembly: 2 Currently Not Available
03	LOCK RIGHT Part #: 46547720292 Required per assembly: 1 Currently Not Available
03	LOCK LEFT Part #: 46547720291 Required per assembly: 1 Currently Not Available
03	LOCK - LEFT Part #: 46547675047 Required per assembly: 1 Currently Not Available
03	LOCK - RIGHT Part #: 71607675048 Required per assembly: 1 Not Available
04	CAP FOR LOCK, LEFT Part #: 46547720297 Required per assembly: 1 Not Available
04	CAP FOR LOCK, RIGHT Part #: 46547720298 Required per assembly: 1 Not Available
05	FLAP LEFT Part #: 71607685883 Required per assembly: 1 Currently Not Available
05	FLAP RIGHT Part #: 71607685884 Required per assembly: 1 Currently Not Available
06	HANDLE, LEFT Part #: 46547685885 Required per assembly: 1 Currently Not Available
06	HANDLE, RIGHT Part #: 71607685886 Required per assembly: 1 Currently Not Available
07	HINGE Part #: 46547693120 Required per assembly: 4 Currently Not Available
08	BUMP STOP Part #: 46547683293 Required per assembly: 6 Currently Not Available
09	COVER SUPPORT LEFT Part #: 46547685965 Required per assembly: 1 Currently Not Available
09	COVER HOLDER, RIGHT Part #: 71607685966 Required per assembly: 1 Currently Not Available
10	LOCK Part #: 46547671783 Required per assembly: 2 Currently Not Available
11	PLASTIC WASHER Part #: 46547693122 Required per assembly: 5 Currently Not Available
12	FILLISTER HEAD SCREW - 4,0X14 Part #: 52537653614 Required per assembly: 9 Currently Not Available
13	FILLISTER HEAD SCREW - M5X16MK Part #: 06327657949 Required per assembly: 8 Note: ONLY IN CONJUNCTION WITH Currently Not Available
14	WASHER-GASKET Part #: 46547683296 Required per assembly: 11 Currently Not Available
15	FILLISTER HEAD SCREW - K50X16 Part #: 46547694877 Required per assembly: 11 Currently Not Available
16	FILLISTER HEAD SCREW - K50X24 Part #: 46547694878 Required per assembly: 2 Currently Not Available
17	LINKAGE FOR LID Part #: 46547693716 Required per assembly: 1 Currently Not Available
18	SET: WARNING STICKER, LEFT Part #: 71607653015 Required per assembly: 1 Currently Not Available
18	SET: WARNING STICKER, RIGHT Part #: 71607653016 Required per assembly: 1 Currently Not Available
19	SET: FASTENING ELEMENTS, CARRIER HANDLE Part #: 71607653002 Required per assembly: 1 Currently Not Available
20	LOCK CYLINDER WITH VIN CODE Part #: 51257681200 Required per assembly: 1 Note: ONLY APPLIES TO Not Available
21	RUBBER-FASTENER Part #: 46547704244 Required per assembly: 2 Currently Not Available
22	SUPPORT Part #: 46547699847 Required per assembly: 2 Currently Not Available
22	SET: SET OF CLAMPS WITH BRACKET Part #: 46547712002 Required per assembly: 1 Currently Not Available
--	LOCK CYLINDER WITH VIN CODE Part #: 51257681200 Required per assembly: 1 Note: ONLY APPLIES TO Not Available
--	INSTANT GLUE - 5 G Part #: 81229407143 Required per assembly: 1 Note: ONLY APPLIES TO Not Available
