Fork Slider/Lower Fork Bridge replacement parts for 2008-2012 BMW R1200RT 10+ (K26)

OEM Parts Bmw 2008-2012 Bmw R1200RT 10+ (K26) Fork Slider/Lower Fork Bridge

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	LEFT FORK SLIDER (TO 08/06) Part #: 31427698909 Required per assembly: 1 Currently Not Available
01	RIGHT FORK SLIDER Part #: 31427685536 Required per assembly: 1 Not Available
02	BUSH Part #: 31422311986 Required per assembly: 2 Note: RECOMMENDED TO PREVENT COLOR DIFFERENCES IN INNER SLIDE TUBES. RECOMMENDED TO PREVENT COLOR DIFFERENCES IN INNER SLIDE TUBES. Currently Not Available
03	RING Part #: 31422314630 Required per assembly: 2 Currently Not Available
04	SHAFT SEAL Part #: 31422311988 Required per assembly: 2 Currently Not Available
06	LOCK RING Part #: 31422311989 Required per assembly: 2 Currently Not Available
07	CUP Part #: 31422311980 Required per assembly: 2 Currently Not Available
10	O-RING (FROM 08/91) Part #: 31422312714 Required per assembly: 2 Currently Not Available
11	FORK BRIDGE, BOTTOM, WITH MOUNTING Part #: 31427707541 Required per assembly: 1 Not Available
12	ISA SCREW - M8X35 MK 10.9 Part #: 07129906038 Required per assembly: 4 Currently Not Available
13	BALL JOINT Part #: 31427652644 Required per assembly: 1 Currently Not Available
14	COLLAR NUT - M14X1,5 Part #: 31422330996 Required per assembly: 1 Currently Not Available
15	COVER, BLACK Part #: 31422314711 Required per assembly: 1 Note: FOR VEHICLES WITH PACKAGE AVANTGARDE (CODE: X592A) Currently Not Available
