Front replacement parts for 2013 Polaris RZR 4 XP JAGGED X

OEM Parts Polaris 2013 Polaris RZR 4 XP JAGGED X Front

FRONT Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	NUT, WHEEL Part #: 7547309 Required per assembly: 8 Note: Nut, Wheel [AK] Sold in multiples of 10 only Currently Not Available
2	RIM-FRONT, 12X6, WE, 26.2, OFST, BK Part #: 1522058-067 Required per assembly: 2 Currently Not Available
3	VALVE-RIM Part #: 1522123 Required per assembly: 2 Currently Not Available
4	NUT, CASTLE, [4X4] Part #: 7547337 Required per assembly: 2 Note: Nut, Castle ~~$3.99~~ $2.30 - + Add to cart
5	PIN, COTTER Part #: 7661404 Required per assembly: 2 Currently Not Available
6	WASHER, CONE Part #: 7555796 Required per assembly: 4 Currently Not Available
7	HUB-WHEEL FRONT (MACH) BLK Part #: 5137659-067 Required per assembly: 2 Currently Not Available
8	STUD [DA] Part #: 7517871 Required per assembly: 8 Note: Stud ~~$2.99~~ $1.98 - + Add to cart
9	DISC-BRAKE FRONT Part #: 5254999 Required per assembly: 2 Currently Not Available
10	TIRE-FRONT 26X9-12 BHORN EMARK Part #: 5414379 Required per assembly: 2 Currently Not Available
11	RING, RETAINING Part #: 7710440 Required per assembly: 2 Note: Ring, Retaining Currently Not Available
12	BEARING-BALL SEALED 44X72X33.1 Part #: 3514699 Required per assembly: 2 Currently Not Available
13	CARRIER, BEARING, FRONT, LH Part #: 5139988 Required per assembly: 1 Currently Not Available
13	CARRIER, BEARING, FRONT, RH Part #: 5139989 Required per assembly: 1 Currently Not Available
14	RING-12IN, WE, BEADLOCK, V, BLUE Part #: 1522062-619 Required per assembly: 2 Currently Not Available
15	SCREW Part #: 7518978 Required per assembly: 8 Currently Not Available
16	SCREW Part #: 7518925 Required per assembly: 40 Currently Not Available
17	WASHER Part #: 7555827 Required per assembly: 40 ~~$3.99~~ $2.30 - + Add to cart
