2021 Polaris RZR XP 1000 Trails & Rocks (R02) Z21NAR99AN/BN - Winch

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1
Polaris 4015095 Contactor-Winch, Pol, Lif, Cap

CONTACTOR-WINCH, POL, LIF, CAP

Part #: 4015095 Required per assembly: 1
Currently Not Available
2
Polaris 4013466 Remote, Switch, Winch

REMOTE, SWITCH, WINCH

Part #: 4013466 Required per assembly: 1 Note: Matching socket part number 4013467
Currently Not Available
3

CABLE-CONTACTOR, TO, WINCH, BLUE

Part #: 4016059 Required per assembly: 1
Currently Not Available
3
Polaris 4016103 Cable-Contactor, To, Winch, Y

CABLE-CONTACTOR, TO, WINCH, Y

Part #: 4016103 Required per assembly: 1
Currently Not Available
4

CABLE-POWER, WINCH, BLK, 6, GA

Part #: 4016115 Required per assembly: 1
Currently Not Available
5

CABLE-POWER, WINCH, RED, 6, GA

Part #: 4016116 Required per assembly: 1
Currently Not Available
6
Polaris 4015090 Socket-Winch, Remote, Hc

SOCKET-WINCH, REMOTE, HC

Part #: 4015090 Required per assembly: 1
Currently Not Available
7
Polaris 7516607 Screw

SCREW

Part #: 7516607 Required per assembly: 2
Currently Not Available
8
Polaris 7558201 Washer, Flat

WASHER, FLAT

Part #: 7558201 Required per assembly: 2
Currently Not Available
9
Polaris 7546601 Nut, Nylok

NUT, NYLOK

Part #: 7546601 Required per assembly: 2 Note: Nut, Nylok
Sold in multiples of 10 only
Currently Not Available
