Ignition System replacement parts for 1992-1997 BMW K1100LT (89V2)

OEM Parts Bmw 1992-1997 Bmw K1100LT (89V2) Ignition System

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	SPARK PLUG - XR7LDC Part #: 12121465104 Required per assembly: 4 Currently Not Available
02	IGNITION WIRE 1 - BERU Part #: 12122305041 Required per assembly: 1 Currently Not Available
02	IGNITION WIRE 2 - BERU Part #: 12122305042 Required per assembly: 1 Currently Not Available
02	IGNITION WIRE 3 - BERU Part #: 12122305043 Required per assembly: 1 Currently Not Available
02	IGNITION WIRE 4 - BERU Part #: 12122305044 Required per assembly: 1 Currently Not Available
03	CIRCULAR CONNECTOR Part #: 12121705656 Required per assembly: 4 Currently Not Available
04	SUPPRESSING SOCKET - 1000-OHM Part #: 12121289840 Required per assembly: 4 Not Available
05	IGNITION COIL Part #: 12131459890 Required per assembly: 2 Currently Not Available
06	LABEL - ZYL.1+4 Part #: 71212305187 Required per assembly: 1 Currently Not Available
06	LABEL - ZYL.2+3 Part #: 71212305188 Required per assembly: 1 Currently Not Available
07	HEX BOLT - M6X85 Part #: 07119912364 Required per assembly: 2 Currently Not Available
08	RUBBER GROMMET Part #: 31421235615 Required per assembly: 4 Currently Not Available
09	BUSH Part #: 12131459053 Required per assembly: 8 Currently Not Available
10	SELF-LOCKING HEX NUT - M6 (TO 01/97) Part #: 07129922705 Required per assembly: 2 Note: FOR VEHICLES WITH OFFICIAL VEHICLES $0.69 $0.58 - + Add to cart
11	COVER Part #: 12131459795 Required per assembly: 1 Currently Not Available
12	FILLISTER HEAD SCREW - M5X12-Z1 Part #: 07119907582 Required per assembly: 4 Note: ONLY IN CONJUNCTION WITH Currently Not Available
13	BRACKET Part #: 61132305184 Required per assembly: 1 Currently Not Available
14	PLUG-IN SOCKET Part #: 61131391630 Required per assembly: 1 Note: FOR VEHICLES WITH PLUG-IN SOCKET (CODE: X764A) Currently Not Available
16	PLUG Part #: 12131459529 Required per assembly: 1 Note: FOR VEHICLES WITH OFFICIAL VEHICLE DEVIATION FROM STANDARD (CODE: X369A) Currently Not Available
17	CONTROL UNIT (TO 07/93) Part #: 12141461441 Required per assembly: 1 Currently Not Available
18	COUNTERSUNK HEAD SCREW - M 4 X 25 (TO 07/93) Part #: 07119928108 Required per assembly: 2 Currently Not Available
19	WAVE WASHER - B4 Part #: 07119932033 Required per assembly: 2 Currently Not Available
20	HEX NUT - M4 Part #: 07119922028 Required per assembly: 2 $0.58 $0.49 - + Add to cart
21	GROUND CABLE Part #: 12311358130 Required per assembly: 1 Currently Not Available
22	HEX BOLT - M5X10 Part #: 07119913218 Required per assembly: 1 Currently Not Available
23	WAVE WASHER - B5 Part #: 07119932098 Required per assembly: 1 Currently Not Available
24	HEX NUT - M5 Part #: 07119922038 Required per assembly: 1 $0.58 $0.49 - + Add to cart
