Rear Brake Calipers - A10rd50aa replacement parts for 2000 Polaris RANGER (A10RD50AA)

OEM Parts Polaris 2000 Polaris RANGER (A10RD50AA) Rear Brake Calipers - A10rd50aa

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PLUNGER Part #: 5133195 Required per assembly: 1 Note: PLUNGER-BRAKE Currently Not Available
2	WASHER, FLAT, PLUNGER Part #: 7556205 Required per assembly: 1 Note: WSHR-FLAT,PLUNGER Currently Not Available
3	SPRING, COMPRESSION Part #: 1910581 Required per assembly: 1 Note: SPRING-COMPRESSION Currently Not Available
4	O-RING Part #: 5412127 Required per assembly: 2 Note: O-RING-1/16 C/SX3/8X1/2 OD Currently Not Available
5	ASSEMBLY, CALIPER, REAR, LH Part #: 1910788 Required per assembly: 1 Note: ASM-CALIPER,BRAKE,1.5,LH,W/PB (Incl. 5-25) Currently Not Available
5	ASSEMBLY, CALIPER, REAR, RH Part #: 1910789 Required per assembly: 1 Note: ASM-CALIPER,BRAKE,1.5,RH,W/PB (Incl. 5-25) Currently Not Available
6	SCREW, BLEEDER Part #: 7080352 Required per assembly: 1 $4.99 $2.88 - + Add to cart
7	SETSCREW, SKT.HD. Part #: 7515489 Required per assembly: 1 Currently Not Available
8	SCREW Part #: 7517963 Required per assembly: 3 Note: SCR-10-32X.62 PHILLIPS SIMS Currently Not Available
9	WASHER, FLAT Part #: 7556206 Required per assembly: 1 Note: WSHR-1/4" FLAT,.060 THK Currently Not Available
10	SCREW Part #: 7517964 Required per assembly: 1 Note: BOLT-1/4-20X2 1/2 LG HEX HEAD Currently Not Available
11	NUT HEX Part #: 7542105 Required per assembly: 1 Currently Not Available
12	LEVER, BRAKE, ACTUATOR Part #: 5133196 Required per assembly: 1 Note: LEVER-BRAKE ACTUATOR Currently Not Available
13	BOOT, PIN, SEAL Part #: 5412506 Required per assembly: 2 Currently Not Available
14	BRACKET, HOUSING, RH Part #: 5245794 Required per assembly: 1 Note: BRKT-HOUSING,RH Currently Not Available
14	BRACKET, HOUSING, LH Part #: 5245793 Required per assembly: 1 Note: BRKT-HOUSING,LH Currently Not Available
15	GASKET Part #: 5830214 Required per assembly: 1 Note: GASKET-RAMP Currently Not Available
16	INSERT, BALL, TRACK, RH Part #: 5133201 Required per assembly: 1 Note: INSERT-BALL TRACK,RH Currently Not Available
16	INSERT, BALL, TRACK, LH Part #: 5133199 Required per assembly: 1 Note: INSERT-BALL TRACK,LH Currently Not Available
17	ACTUATOR, RH Part #: 5133203 Required per assembly: 1 Note: BRAKE-ACTUATOR,RH Currently Not Available
18	BALL Part #: 3514375 Required per assembly: 3 Note: BALL-.187 STEEL Currently Not Available
19	SEAL, CALIPER, INNER Part #: 5412010 Required per assembly: 1 Currently Not Available
20	PISTON, BRAKE Part #: 5132829 Required per assembly: 1 Currently Not Available
21	SEAL, CALIPER, OUTER Part #: 5412011 Required per assembly: 1 Currently Not Available
22	BOOT, BUSHING Part #: 5412505 Required per assembly: 1 Currently Not Available
23	KIT, BRAKE, PAD Part #: 2202413 Required per assembly: 2 Note: Kit, Brake Pad Currently Not Available
