Engine, Cooling System replacement parts for 2012 Polaris RANGER CREW 800 (R12WH76AG/AR/EAH/EAV)

OEM Parts Polaris 2012 Polaris RANGER CREW 800 (R12WH76AG/AR/EAH/EAV) Engine, Cooling System

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLAMP, HOSE Part #: 7080474 Required per assembly: 2 Note: Clamp, Hose $9.44 $6.81 - + Add to cart
2	TUBE-COOLANT INLET 1" Part #: 5335940 Required per assembly: 2 Currently Not Available
3	STRAP PANDUIT Part #: 7080138 Required per assembly: 1 $1.99 $1.15 - + Add to cart
4	MOUNT, CABLE, TIE Part #: 7080965 Required per assembly: 2 Currently Not Available
5	CLAMP, SPRINGBAND Part #: 7080843 Required per assembly: 4 Note: Clamp, Spring Band Sold in multiples of 10 only Currently Not Available
6	HOSE, ENGINE, OUTLET, REAR Part #: 5414509 Required per assembly: 1 Currently Not Available
7	HOSE, RADIATOR, LOWER Part #: 5413853 Required per assembly: 1 Currently Not Available
8	HOSE, RADIATOR, UPPER Part #: 5413745 Required per assembly: 1 Currently Not Available
9	TRIM, EDGE, 6FT, BLACK Part #: 5521131 Required per assembly: 1 Currently Not Available
10	CAP, PRESSURE Part #: 1240300 Required per assembly: 1 Currently Not Available
11	ASM-RADIATOR Part #: 1240721 Required per assembly: 1 Currently Not Available
12	BUSHING, MT, LOW, RED Part #: 5410584 Required per assembly: 2 Currently Not Available
13	HOSE-ENG INLET REAR Part #: 5413954 Required per assembly: 1 Currently Not Available
14	ASSEMBLY, GROMMET, AND, INSERT Part #: 5413155 Required per assembly: 2 Currently Not Available
15	SCREW Part #: 7517685 Required per assembly: 2 Note: Screw Currently Not Available
16	VALVE, PLASTIC, RADIATOR/COOLER, DRAIN Part #: 7052410 Required per assembly: 1 Currently Not Available
17	HOSE-BYPASS 3/8IN FORMED Part #: 5413949 Required per assembly: 1 Currently Not Available
18	SCREW Part #: 7516822 Required per assembly: 4 Currently Not Available
19	HOSE-BYPASS FORMED Part #: 5414207 Required per assembly: 1 Currently Not Available
19	CONDUIT, FLEX Part #: 5521287-20 Required per assembly: 1 Currently Not Available
20	STRAP, PANDUIT, 14" Part #: 7080761 Required per assembly: 8 Note: Cable Tie Currently Not Available
21	FUEL, LINE, 1/4, ID(1525, CM.) Part #: 8450003-1525 Currently Not Available
22	FITTING, 90, DEGREE, ("J", MODEL, ONLY) Part #: 7052065 Required per assembly: 1 Note: FITTING,90 DEGREE $11.99 $6.90 - + Add to cart
23	SCREW Part #: 7512084 Required per assembly: 4 Note: Screw $2.99 $1.73 - + Add to cart
24	BRACKET, SURGE, TANK, BLACK Part #: 5252305-329 Required per assembly: 1 Currently Not Available
25	TANK, SURGE Part #: 5436936 Required per assembly: 1 Currently Not Available
26	CAP, PLUG9X, (GREEN), FLEX, TEMP Part #: 5433774 Required per assembly: 1 Note: Plug, Cap $4.79 $2.92 - + Add to cart
27	CAP, OVERFLOW Part #: 5430743 Required per assembly: 1 Currently Not Available
28	GASKET Part #: 5810279 Required per assembly: 1 $4.99 $2.92 - + Add to cart
29	ASM-FAN RANGER Part #: 2411732 Required per assembly: 1 Currently Not Available
30	CLAMP, HOSE Part #: 7081174 Required per assembly: 6 Currently Not Available
31	SCREW Part #: 7517685 Required per assembly: 3 Note: Screw Currently Not Available
32	CLIP, ROUTING Part #: 5438331 Required per assembly: 3 Currently Not Available
33	CONNECTOR-TEE 1X1X3/8 Part #: 7052494 Required per assembly: 1 Currently Not Available
