Front Control Arms - Z17vje57ar (49Rgrsuspfrt11rzr) replacement parts for 2017 Polaris RZR 570 S (R02)

OEM Parts Polaris 2017 Polaris RZR 570 S (R02) Front Control Arms - Z17vje57ar (49Rgrsuspfrt11rzr)

FRONT CONTROL ARMS - Z17VJE57AR (49RGRSUSPFRT11RZR) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WELD-CNTRLARM, UPR, FR, LH, LT, RED Part #: 1018209-293 Required per assembly: 1 Currently Not Available
2	WELD-CNTRLARM, UPR, FR, RH, LT, RED Part #: 1018210-293 Required per assembly: 1 Currently Not Available
3	WELD-CNTRLARM, LWR, FR, LH, LT, RED Part #: 1018211-293 Required per assembly: 1 Currently Not Available
4	WELD-CNTRLARM, LWR, FR, RH, LT, RED Part #: 1018212-293 Required per assembly: 1 Currently Not Available
5	SHAFT, PIVOT Part #: 5138791 Required per assembly: 4 Currently Not Available
5	SHAFT, PIVOT Part #: 5138791 Required per assembly: 4 Currently Not Available
6	BUSHING, A-ARM, LONG, GREY Part #: 5436973 Required per assembly: 8 Note: Bushing, A-Arm, Long ~~$10.99~~ $6.33 - + Add to cart
6	BUSHING, A-ARM, LONG, GREY Part #: 5436973 Required per assembly: 8 Note: Bushing, A-Arm, Long ~~$10.99~~ $6.33 - + Add to cart
7	FITTING, ZERK, (90, DEGREE) Part #: 7080510 Required per assembly: 4 Note: FITTING, ZERK (90o) Currently Not Available
8	SHIELD-CV FRONT BLK Part #: 5438641-070 Required per assembly: 2 Currently Not Available
8	SHIELD-CV FRONT BLK Part #: 5438641-070 Required per assembly: 2 Currently Not Available
9	SCREW Part #: 7512084 Required per assembly: 4 Note: Screw ~~$2.99~~ $1.73 - + Add to cart
10	BALL-JOINT, 8MM, 5140 Part #: 7061220 Required per assembly: 4 Currently Not Available
10	BALL-JOINT, 8MM, 5140 Part #: 7061220 Required per assembly: 4 Currently Not Available
11	RING, RETAINER Part #: 7710533 Required per assembly: 4 Currently Not Available
12	SCREW, FLANGED Part #: 7519087 Required per assembly: 4 Currently Not Available
12	SCREW, FLANGED Part #: 7519087 Required per assembly: 4 Currently Not Available
13	NUT, FLANGE Part #: 7547333 Required per assembly: 4 Note: M10 x 1.25 ~~$3.74~~ $2.23 - + Add to cart
13	NUT, FLANGE Part #: 7547333 Required per assembly: 4 Note: M10 x 1.25 ~~$3.74~~ $2.23 - + Add to cart
14	NUT, NYLOK Part #: 7547405 Required per assembly: 4 Currently Not Available
15	SCREW, FLANGE Part #: 7516733 Required per assembly: 4 Currently Not Available
16	WASHER, FLAT Part #: 7556153 Required per assembly: 4 Note: Washer ~~$3.99~~ $2.30 - + Add to cart
16	WASHER, FLAT Part #: 7556153 Required per assembly: 4 Note: Washer ~~$3.99~~ $2.30 - + Add to cart
